Summary of Contents for Perception Digital PD-200
-
Page 2: Table Of Contents
Table of Contents Introduction...2 Copyright notice...3 Safety information...3 Precautions...5 In the Package...6 Specifications...7 Knowing Your Portable MP3 Player...8 Name of parts...8 Inserting battery...9 Turn on MP3 player...10 Turn off MP3 player...10 Multiple Language Support...10 PC Connection...11 Operating Controls...15 Operating in music mode...15 Operating in radio mode...17... -
Page 3: Introduction
Introduction Thank you for purchasing PDHercules portable MP3 player! With this MP3 player you can enjoy digital music in a more convenient way. You can directly encode your music from any audio source and record your voice into voice format, all of this WITHOUT the use of a computer. You can also transfer songs you enjoy from your computer to your player. -
Page 4: Copyright Notice
Introduction Copyright Notice You must be aware that distribution of MP3 files without the permission from the content owner is against the copyright laws. Perception Digital Ltd. and its associating companies will not be liable against such actions. Safety information... - Page 5 Introduction Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. Keep in mind, modifications not authorized by the manufacturer may void users authority to operate this device.
-
Page 6: Precautions
Use a soft towel to clean the surface of your player. Remove the battery from the player when you are not using the MP3 player. This is to avoid needless battery wear. Avoid keeping or operating the unit in places with strong magnetic field, direct sunlight, or heat exposure for extended periods of time. -
Page 7: In The Package
In the Package Stereo Earphone Main Unit Mini USB Cable User Manual Neck String Carrying Pouch Warranty Card (Optional) Battery Line-in Cable MMC/SD Card (Optional) CD-Rom (Optional) -
Page 8: Specifications
Specifications Size (HxWxD) Net Weight Internal Flash Memory Power Supply PC Interface Radio Function Digital Music Format Playback Record Digital Voice Format Built-in Microphone Signal to Noise Ratio Frequency Range Battery Life Support External Memory Equalizer Play Mode All specifications are subject to change without notice. 88x41x15mm 42g (without battery) 32MB or 64MB(depending on product version) -
Page 9: Knowing Your Portable Mp3 Player
Knowing your Portable MP3 Player Name of parts LCD: Display Window... -
Page 10: Inserting Battery
Knowing your Portable MP3 Player Inserting battery Open the battery door according to this direction Inserting MMC/SD card Insert the MMC/SD card in a correct direction, you will see an arrow in the card right hand corner. Put the battery into the compartment. -
Page 11: Turn On Mp3 Player
Knowing your Portable MP3 Player Remarks : Make sure the card is facing the correct direction when inserting into the slot. When inserting the card, make sure the logo of the MMC/SD card is facing upwards. There is a locking device on the SD card. You cannot format, delete or download any files when the SD card is locked. -
Page 12: Pc Connection
3. If the player is connected to your PC, you will see “USB Connected” on the player’s screen. 4. To download music files to your MP3 player, simply drag the files from the Windows File Explorer and drop them to the newly opened drive. You can also... - Page 13 Do not unplug the USB cable when the LCD is still displaying “USB writing” as doing so may corrupt the files stored in the player and you will need to re-format the MP3 player. If the player encounters abnormal interruption during recording such as battery removal, you may also need to re-format it.
- Page 14 PC Connection Add on functions: The MP3 player can also be used as an external drive for storage of non- music files. The MP3 player is compatiable with Music Match. You can directly rip your audio CDs to WMA or MP3 format using Music Match software and directly download to the player.
- Page 15 PC Connection * Please make sure when you format the player, the "file system" is calling FAT or FAT16. Otherwise, the player will appear "Error please reformat". To solve the problem, user is suggested to reformat the player by choosing FAT/FAT16 when the format windows pop-up.
-
Page 16: Operating Controls
Operating controls There are three modes which you can operate your portable MP3 player; music mode, radio mode, and voice mode. Operating in Music Mode The following tables show all key responses under different operations in music mode. Music Playing Mode... - Page 17 Operating controls Music Recording Mode Key Action Short Long Short / Long Short / Long MENU VOL + VOL - —> Hold On/Off Recording Pause / Resume recording Power off No response No response No response No response No response Stop recording All keys are locked...
-
Page 18: Operating In Radio Mode
Operating controls Operating in Radio Mode The following tables show all key responses under different operations in radio mode. FM Radio Playing Mode Key Action Short Long Short Long Short Long MENU VOL + VOL - On / Off —>Hold Normal Mode No response Power off... - Page 19 Operating controls FM Radio Recording Mode Key Action Short Long Short / Long Short / Long MENU VOL + VOL - —>Hold On / Off Recording Pause / Resume recording Power off No response No response No response No response No response Stop recording All keys are locked...
-
Page 20: Operating In Voice Mode
Operating controls Operating in Voice Mode The following tables show all key responses under different operations in voice mode. Voice Playing Mode Key Action Short Long Short Long Short Long MENU VOL + VOL - On / Off —>Hold Browsing Play current track Power off Move to next track... - Page 21 Operating controls Voice Recording Mode Key Action Short Long Short / Long Short / Long MENU Short / Long VOL + VOL - —>Hold On / Off Recording Pause/Resume current track Power off No response No response No response No response No response Stop recording (Go back to previous screen)
-
Page 22: Detailed Controls
To stop the track, press the again. Selecting tracks When the MP3 player is playing a file, move towards the quickly to play the next track and move towards the to play the previous track. When the player is stopped, moving with through the tracks stored in memory. -
Page 23: Music Recording In Voice Mode
After recording,press play button to play the recorded file and it will be displayed as V001,V002...V003.wav. The recording music files are only playable on the MP3 player and not on the PC. to select track or voice file you wish... -
Page 24: Voice Recording In Voice Mode
Detailed Controls Voice recording in voice mode. This feature offers high quality one touch voice recording an ADPCM format. Select SET (System setting) at any mode,Choose source as MIC, Press play button to confirm the source. You should start at the stop mode of voice mode. Press REC button to start recording. -
Page 25: Menu Settings
Menu Settings To change the settings, use the button to enter into the sub-menu and use the the desired settings. Press the setting in different modes you need to press the MENU button. The following table shows all key responses for menu settings in different modes: MENU Others Menu settings in Music Mode... - Page 26 Menu Settings Playmode Normal: Repeat One: Repeat All: Random: Rpt Random: Continuously repeat all tracks randomly. Equalizers Select Normal, Rock, Classic, Jazz, Pop and User default Bass: Treble: Recording Bit Rates There are various choices of recording bit rates in MP3 recording: 48kbps, 96kbps, and 128kbps.
-
Page 27: Menu Setting In Radio Mode
Radio Mode Channel Preset Your MP3 player can store up to 30 preset programme frequencies. These programmes can be quickly tuned when the radio is in the PRESET MODE. This section gives instructions for saving programme presets. The next section explains... - Page 28 Menu Settings Enter the RADIO mode as described previously. In NORMAL MODE tune the radio to the programme you wish to preset. Press the MENU button. Use the Press Use the Press Mono/Stereo Mode Set FM radio output to stereo or mono Preset Mode Switching to Radio Mode.
- Page 29 Menu Settings Using the preset mode Enter the RADIO mode as described previously. Press the MENU button. Use the Press . The radio is now operating in preset mode. Use the you require is selected. Deleting Program preset Deleting programme presets Enter the RADIO PRESET MODE as described above.
-
Page 30: Menu Setting In Voice Mode
Menu Settings Mono/Stereo Mode Set FM radio output to ste Menu setting in Voice Mode Switching to Voice Mode Deleting Files Go to file you want to delete. Press Menu Press the play button to confirm deletion reo or mono... -
Page 31: System Settings
System Settings To change system settings, use sub-menu and press desired settings. Press Source: You can select the recording source in this menu. Selecting LINE- IN means you will be recording from line-in and selecting MIC-IN means you will be recording from the internal microphone. Sleep preset: Choose the time in minutes that you want the device to automatically power off. - Page 32 System Settings Backlit time: There are 4 backlit time levels; 10, 30, 60, and permanent. These refer to the length of time in seconds the backlight will remain on after pressing a button. Contrast level: Set the display contrast from level 1 to 10. Default setting: You may choose to resume your settings to default by pressing either “Yes”...
-
Page 33: Troubleshooting
Check if the memory contains any MP3 files. Check if the player is in Music Mode. Check if the MP3 player supports the format of the stored files. 4. Unable to play ADPCM Check if the memory contains any VOC files Check if the player is in Voice Mode. - Page 34 Make sure USB device is installed. You may check this in the “Device manager” in your PC. 9.How to reset MP3 Player to factory settings. Choose default setting in system settings. Choosing “YES” allows you to reset the player to factory default settings.
-
Page 35: Company Contacts
Company Contacts For International Inquiry: technical@perceptiondigital.com...
