Perception Digital PD-205 User Manual

Perception digital mp3 player user manual pd-205

Advertisement

Quick Links

PD-205
MP3 Player
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD-205 and is the answer not in the manual?

Questions and answers

Summary of Contents for Perception Digital PD-205

  • Page 1 PD-205 MP3 Player USER MANUAL...
  • Page 2 For Customers in U.S.A. or Canada If you have any questions about this product, you can email to ustechnical@perceptiondigital.com Regulatory Information: This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 For Customers in Europe This product conforms to the following European Directives: 89/336/EEC (EMC Directive) This product complies with EN55022/A1:2000 and EN 55024/A1:2001 for use in the following areas: residential, commercial and light industrial.
  • Page 4: Table Of Contents

    Contents Preface...04 Liability exemption statement...05 Important...06 Safety precaution...07 Features of the product...08 A list of accessories...09 Product drawing and function keys...10 Description of LCD display...11 Operation instruction...12 Operation instructions of function keys...13 - Play music...13 - Pause mode...14 - Stop mode...14 - Lyric mode...14 - A-B repeat...14 - Volume adjustment...14...
  • Page 5: Preface

    To make copies or publish this manual in whatever means or in whatever forms without the written authorization from Perception Digital is forbidden. Perception Digital reserves all rights. Perception Digital is not responsible for data loss, revision of the device or other indirect losses resulting from mal-operation, maintenance, battery overflow or other accidents. Perception Digital will not be responsible for restoration of the personal data lost in th card.
  • Page 6: Liability Exemption Statement

    3. Perception Digital will be responsible only for the inherent problem of the device, but not for data loss, revision of the device or other indirect losses resulting from mal-operation of software, maintenance or other accidents.
  • Page 7: Important

    Important 1. Do not drop the player or give a hard impact, it could cause malfunction. 2. Do not subject the player to high temperature or direct sunlight. 3. Keep it far away from humid place. 4. Do not disassemble it. 5.
  • Page 8: Safety Precaution

    In this case, please do not hesitate to contact Perception Digital customer service center for technical support and help from Perception Digital professional servicemen. But Perception Digital shall take no liability for damages resulting from battery liquid leakage.
  • Page 9: Features Of The Product

    Features of the product This device is a new generation of multi-functional MP3 player, which can play music (MP3 and WMA) files stored in MMC/SD card. It can also serve as a MMC/SD card reader. This multi-functional MP3 player is practical and innovative. We list some major functions and...
  • Page 10: A List Of Accessories

    A list of accessories 1. Stereo earphone 2. Mini - USB cable 3. User manual...
  • Page 11: Product Drawing And Function Keys

    HOLD...
  • Page 12: Description Of Lcd Display

    Description of LCD display Repeat All Repeat one A to B Play status Elapse time Hard icons A to B Repeat one Note: The movement of signal strength represents the volume level of each beat within a song. The wider the frequency band, the higher the volume level. Repeat shuffle Key lock Battery indicator...
  • Page 13: Operation Instruction

    Open the battery Place one AAA battery door in this into the battery direction. compartment. Pay attention to the polarity. Close the battery door Place & push your The card will be MMC/SD card in this protruded a little bit. direction until you hear This is normal.
  • Page 14: Operation Instructions Of Function Keys

    Operation instructions of function keys Note: Short press-----press the key for less than one second Long press-----press the key for more than one second Under Stop mode Menu Long Power off Press Enter the Short setting Press mode Note: In stop mode, there is an icon " " in front of the song name in the display. Play music Short press "Play"...
  • Page 15: Pause Mode

    Pause mode Play mode Stop mode Play mode Lyric mode After long pressing "Menu" key to enter "setting mode", short press "Left" / "Right" key to select "Lyric mode" to display lyric. To go back to Play menu, long pressing "Menu" again to enter the lyric mode, and select "No"...
  • Page 16: Connected To The Computer

    Connected to computer Computer system requirement 1. Microsoft Windows 98/Me/2000/XP 2. CD-ROM driver above 2X 3. Pentium CPU above 233MHz 4. With RAM memory above 32MB (if the operating system is Windows XP, the RAM should be above 64MB) 5. Hard disk space should be above 20MB 6.
  • Page 17: Usb Connection

    2. If you want to download files to the device from your computer, just drag the desired files to "removable disk", which represents your MP3 player. 3. You can also upload the files in your MP3 player to your computer. 4. During uploading / downloading, keep the USB cable connected to the computer. Plug it out from USB port when the uploading / downloading is completed.
  • Page 18: Introduction To Basic Functions

    1) If no card is inserted into the device, there will be a prompt "No Card!" after it powers on as below: 2) Only insert or remove the card when the player is power off, otherwise, the data may be crashed or damaged. Perception Digital will not be responsible for data lost or card damage. Power off Long press"Menu"...
  • Page 19: System Setting

    System setting Play function setting Various settings are available under stop, play/pause mode. Under the STOP status, short press "Menu" key to enter menu, including EQ, Repeat, Lyric, Contrast, Power off, Backlight, Upgrade OS and Version etc. Under play/ pause mode, press "Menu" key to enter menu settings. Note: The setting will get back to the default setting after the device is powered off.
  • Page 20: Contrast Setting

    Contrast setting You can set the contrast of LCD. Short press "Up" / "Down" key to increase/decrease the contrast of LCD. Short press "Play" key to save change and return. Power off setting When the device is playing, the time (in minutes) for auto power off (1m, 5m, 10m, and Off) or sleep off (15m, 30m, 60m and Off) can be preset.
  • Page 21: Firmware Upgrade

    Firmware upgrade Firmware upgrade file and upgrade procedures are available from the below website. www.perceptiondigital.com You are recommended to check the availability of new firmware release version to perform upgrade periodically to enhance the performance of the player. Notes: 1) Disconnection during firmware upgrading may cause failure to the device. 2) Do not change the file name or extension of the upgraded files.
  • Page 22: Main Menu Tree Diagram

    Main menu display EQ mode Normal Classic Rock Live Repeat setting Normal Repeat one Repeat all Repeat Shuffle Lyric setting Contrast setting 1 - 6 Power off setting Power off Sleep off Backlight setting Allways On Upgrade OS Upgrade Cancel Version...
  • Page 23: Customer Support

    Customer Support Trouble Shooting The device does not work or LCD does not work. 1) Check if there is enough battery power. 2) Check if the polarities of battery are correct. The device does not respond to key press 1) Check if it is in the status of "Key lock" 2) If it is in "Key lock", all the keys can not work.
  • Page 24 The song skips or does not play at all, but the song title shows. What is the cause? There are several reasons why a song (file) can not play. 1) The file may be corrupted when it was converted from the CD or when it was copied over to the player during the transfer process.
