Winmate W07FA3S-PCM1AC-PoE User Manual

7"s-series hmi freescale cortex a9 i.mx6 dual core 1 ghz
Hide thumbs Also See for W07FA3S-PCM1AC-PoE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
7"S-Series HMI
Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz
W07FA3S-PCM1AC-PoE (with LED Light Bar)
W07FA3S-PCM1-PoE (without LED Light Bar)
Slim-line

User Manual

Version 1.1
Document Part Number: 9171111I102D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W07FA3S-PCM1AC-PoE and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate W07FA3S-PCM1AC-PoE

Summary of Contents for Winmate W07FA3S-PCM1AC-PoE

  • Page 1: User Manual

    7"S-Series HMI Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz W07FA3S-PCM1AC-PoE (with LED Light Bar) W07FA3S-PCM1-PoE (without LED Light Bar) Slim-line User Manual Version 1.1 Document Part Number: 9171111I102D...
  • Page 2 Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.

  • Page 3: Customer Service

    Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
  • Page 4 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...

  • Page 5: Safety Information

    Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 6 CAUTION/ATTENTION Do not cover the openings! Ne pas couvrir les ouvertures!  Before connecting the equipment to the power outlet make sure the voltage of the power source is correct.  Position the power cord so that people cannot step on it. Do not place anything over the power cord.
  • Page 7 WARNING!/ AVERTISSEMENT! Always ground yourself against electrostatic damage to the device. Toujours vérifier votre mise à la terre afin que l’équipement ne se décharge pas sur vous.  Cover workstations with approved anti-static material. Use a wrist strap connected to a work surface and properly grounded tools and equipment. ...

  • Page 8: Important Information

    Important Information Countries/ Area Symbol This equipment complies with essential requirements of: Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous European Union substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
  • Page 9 European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU)  EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014...

  • Page 10: About This User Manual

    About This User Manual This User Manual provides information about using the Winmate® 7” S-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz (Optional Quad Core) processor. This User Manual applies to the 7” S-Series HMI – W07FA3S-PCM1AC-PoE and W07FA3S-PCM1-PoE.

  • Page 11: Table Of Contents

    Contents Preface ......................... ii About This User Manual ....................x Chapter 1: Introduction ....................1 1.1 Product Features ....................1 1.2 Package Content ....................2 1.3 Schematic and Dimensions .................. 4 Chapter 2: Getting Started .................... 6 2.1 Powering On ......................6 2.1.1 AC Adapter Components ................
  • Page 12 3.4.2 Checking Ethernet ................... 20 3.5 Testing LED Light Bar ..................21 3.6 Reading NFC Tag ....................22 3.7 Winmate® Home Manager (WHM) ..............24 3.7.1 How to Lock Applications ................ 24 3.7.2 How to Unlock Applications ..............26 3.7.3 How to Change Password ................ 28 3.8 Using Front Camera ...................
  • Page 13 Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. 7” S-Series HMI...

  • Page 15: Chapter 1: Introduction

    P-Cap touch-screen. These models sealed with front IP65 dust and water proof, and full IP22. The W07FA3S-PCM1AC-PoE model supports an exceptional feature - LED Light Bar. With the help of red, green and blue LED indicators you can see the status of the machine or processes afar.

  • Page 16: Package Content

    User Manual Chapter 1 Introduction 1.2 Package Content Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.
  • Page 17 User Manual Chapter 1 Introduction Package may include optional accessories based on your order VESA Desk Stand VESA Desk Stand VESA Wall Mount Bracket PCVS-V1 LA-100 LA-106 9B0000000128 9B0000000412 99KK00A0000E For installation instructions and dimensions of optional accessories refer to Ch.5, “Mounting Guide”.

  • Page 18: Schematic And Dimensions

    2MP Front Camera (Optional) ④ USB OTG ⑨ 1W Speaker ⑤ RS-232/422/485 ⑩ LED Status Light Bar** *Power Device (PD): follows IEEE 802.3at (25 W), IEEE 802.3af (15 W) **RGB LED light bar only available for the model number W07FA3S-PCM1AC-PoE 7” S-Series HMI...

  • Page 19: Getting Started

    Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. 7” S-Series HMI...

  • Page 20: Chapter 2: Getting Started

    User Manual Chapter 2 Getting Started Chapter 2: Getting Started This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On 2.1.1 AC Adapter Components AC Adapter Power Cable...

  • Page 21: Power Considerations

    User Manual Chapter 2 Getting Started 2.1.2 Power Considerations HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package . Using other AC adapters may damage the device. Utiliser seulement le convertisseur AC inclu avec votre appareil.

  • Page 22: Connector Pinouts

    User Manual Chapter 2 Getting Started 2.2 Connector Pinouts This section contains I/O connector pinouts. 2.2.1 Power Input Connector The DC power source input of the 7” S-Series HMI is a 2 pin terminal block connector that supports 12V DC power input. Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A...

  • Page 23: Usb Otg Connector

    User Manual Chapter 2 Getting Started 2.2.4 USB OTG Connector Use USB OTG connector to connect the HMI device to other USB On-The-Go compliant devices such as flash drives, digital cameras, mice or keyboards. Use USB OTG cable to install software on the HMI device. Pin №...

  • Page 24: Configuring Serial Port Settings

    Chapter 2 Getting Started 2.3 Configuring Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. To configure serial port settings: 1. Go to Settings > Accessibility.
  • Page 25 User Manual Chapter 2 Getting Started 3. Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings 7” S-Series HMI...

  • Page 26: Turning On And Off

    User Manual Chapter 2 Getting Started 2.4 Turning On and Off This section describes how to turn on / off the HMI device. To turn on the HMI device: 1. Connect the HMI device to the source of power/ 2. The unit is configured to Power ON when is connected to the power source. Refer to Ch.2, “Powering On”...
  • Page 27 Operating the HMI Device This chapter provides detailed information on how to operate the device. If you have been using Android touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. 7” S-Series HMI...

  • Page 28: Chapter 3: Operating The Hmi Device

    User Manual Chapter 3 Operating the HMI Device Chapter 3: Operating the HMI Device This chapter provides detailed information on how to operate the device. If you have been using Android touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters.

  • Page 29: Multi-Touch

    User Manual Chapter 3 Operating the HMI Device 3.2 Multi-Touch The touchpad supports the core gestures for Android. Gesture Action Description Touch To select or activate something Touch & Hold Touch and hold an item on the screen by touching it and not lifting your finger until it respond Touch, Hold &...

  • Page 30: System Settings

    User Manual Chapter 3 Operating the HMI Device 3.3 System Settings 3.3.1 Setting up the Device When you first turn on your HMI device, you’ll see a Welcome screen. Choose the language you want and touch Start or the Start icon. When prompted, you can sign in with your Google Account or create one at that time.

  • Page 31: Quick Settings

    User Manual Chapter 3 Operating the HMI Device 3.3.3 Quick Settings To open Settings, Swipe down from the top right of the screen and touch the Settings icon.  You can open your device’s Settings app from the All Apps screen or from Quick Settings. For example, to change notification sounds, and volume go to Settings >...

  • Page 32: Brightness Adjustment

    User Manual Chapter 3 Operating the HMI Device 3.3.4 Brightness Adjustment In the Android user can adjust the screen brightness. Pull down from the top of the screen to get the notifications area. You can also access display settings in settings: Go to Settings >...

  • Page 33: Ethernet

    User Manual Chapter 3 Operating the HMI Device 3.4 Ethernet 1. Connect Ethernet Cable to the HMI device. 2. Go to APPS > Ethernet. 3. Ethernet APP main menu appears Setting Description Check Ethernet Check Ethernet connection parameters: IP mode, IP address, DNS address and others Configure Ethernet Enable Ethernet connection and configure its such as connection...

  • Page 34: Configuring Ethernet

    User Manual Chapter 3 Operating the HMI Device 3.4.1 Configuring Ethernet To configure Ethernet settings go to Apps > Ethernet > Configure Ethernet *Default settings: Ethernet OFF. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway 3.4.2 Checking Ethernet...

  • Page 35: Testing Led Light Bar

    User Manual Chapter 3 Operating the HMI Device 3.5 Testing LED Light Bar To test LED Light Bar go to APPS > Light BarDemo (This application is for demonstration purposes only). Adjust the intensity of Red, Green and Blue light. 7”...

  • Page 36: Reading Nfc Tag

    User Manual Chapter 3 Operating the HMI Device 3.6 Reading NFC Tag Notice that NFC Reader is an optional feature for 7” S-Series HMI and may not be present in your device. Refer to Appendix A of this user manual for more details of supported NFC card type. Follow instructions below to test NFC feature.
  • Page 37 User Manual Chapter 3 Operating the HMI Device Step 4 Go back to NFC Tag Info application. Now you can scan NFC tag. Locate the card to the NFC tag. Don’t remove tag, reading may take up to a minute. Step 5 The information written on the card displays on the screen.

  • Page 38: Winmate® Home Manager (Whm)

    Operating the HMI Device 3.7 Winmate® Home Manager (WHM) Winmate® S-Series HMI running on Android OS comes with preinstalled APP named Winmate Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager.
  • Page 39 Password Manager Set the WHM password (Default password is “0000”). About Displays information about Winmate® Home Manager Step 2 Go to “Application Selector”, and choose the app which you want to run up automatically after booting. Step 3 Go back to “Home Selector” and press “Clear and Reset Default Home”.

  • Page 40: How To Unlock Applications

    User Manual Chapter 3 Operating the HMI Device Step 4 Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Any time user presses home key or back key; the system will go back to the same application which you have selected.
  • Page 41 User Manual Chapter 3 Operating the HMI Device Step 2 System will request the password to login. Default password is “0000”. Step 3 Restart the system and you will go back to the normal Launcher. 7” S-Series HMI...

  • Page 42: How To Change Password

    User Manual Chapter 3 Operating the HMI Device 3.7.3 How to Change Password Step 1 Go to Password Manager and set your own password for this APP. Step 2 The default password is “0000”. Enter a new password in New Password field, and then tap Change Password.

  • Page 43: Using Front Camera

    User Manual Chapter 3 Operating the HMI Device 3.8 Using Front Camera Your device has a built in 2MP front camera. 3.8.1 Camera Menu To open the camera, open All APPS , and then tap on camera icon Item Icon Description Action Location setting...

  • Page 44: Shooting Photos

    User Manual Chapter 3 Operating the HMI Device 3.8.2 Shooting Photos 1 Open the Camera 2 Focus on the object 3 Tap to capture the object 4 By default, the photo preview is displayed briefly on the screen The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: Icon Description...

  • Page 45: Shooting Videos

    User Manual Chapter 3 Operating the HMI Device 3.8.2.2 Camera Settings to open camera settings. Item Icon Description Action Zoom in/ Zoom out Tap to zoom in or zoom out the picture. Exposure Tap to change exposure settings. 3.8.3 Shooting Videos Short tap >...

  • Page 46: Software Installation

    Software Installation This chapter contains software installation and update guide. 7” S-Series HMI...

  • Page 47: Chapter 4: Software Update

    User Manual Chapter 4 Software Installation Chapter 4: Software Update This chapter contains software installation and update guides. All the programming guides can be found in the driver CD included in the package. 4.1 Android Debug Bridge (ADB) Driver Installation IMPORTANT: ...

  • Page 48: Disabling Driver Signature On Windows 8

    User Manual Chapter 4 Software Installation 4.1.1 Disabling Driver Signature on Windows 8 Step 1 Hold down the Windows key on your keyboard and press the letter C to open the Charm menu, and then click the gear icon (Settings). Step 2 Click Change PC Settings.
  • Page 49 User Manual Chapter 4 Software Installation NOTE: In Windows 8.1, the ‘Restart Now’ button has moved to ‘PC Setting -> Update & Recovery -> Recovery.’ Step 5 After restarting, click Troubleshoot. Step 6 Click Advanced Options. 7” S-Series HMI...
  • Page 50 User Manual Chapter 4 Software Installation Step 7 Click Windows Startup Settings. 7” S-Series HMI...
  • Page 51 User Manual Chapter 4 Software Installation Step 8 Click Restart. Step 9 After restarting your computer a second time, choose Disable driver signature enforcement from the list by typing the number 7 on your keyboard. Your computer will restart automatically. 7”...
  • Page 52 User Manual Chapter 4 Software Installation Step 10 After restarting, you will be able to install the ADB drivers normally; however, Windows will display a warning message. When the warning appears, click Install this driver software anyway. If you are unfamiliar with installing drivers, check out our Installing ADB driver tutorial for a step by step guide.

  • Page 53: Adb Driver Installation

    User Manual Chapter 4 Software Installation 4.1.2 ADB Driver Installation Step 1 Confirm whether the USB device was found by the system. Device Manager > 120A > Other devices > FA30-200 > Update Driver Software Step 2 In the Update Driver Software window choose Browse my computer for driver software.
  • Page 54 User Manual Chapter 4 Software Installation Step 3 Select Let me pick from a list of device drivers on my computer. Click Next. Step 4 Select from your computer. Step 5 In the Update driver software window, click show All Devices and then click Next. 7”...
  • Page 55 User Manual Chapter 4 Software Installation Step 6 The system is looking for the driver folder. Click Browse. Step 7 Select the driver for your OS system. Click Open. 7” S-Series HMI...
  • Page 56 User Manual Chapter 4 Software Installation Step 8 Windows Security window will pop up. This message is used to confirm whether the user wants to install the driver. Select Install this driver software anyway to continue. Step 9 When the installation is successfully completed you will see Android ADB Interface driver in the Update Driver Software window.

  • Page 57: Installing Android Debug Bridge (Adb)

    User Manual Chapter 4 Software Installation 4.2 Installing Android Debug Bridge (ADB) For detailed Android Debug Bridge (ADB) information refer to Android Developers Platform: http://developer.android.com/tools/help/adb.html Step 1 Decompress adb.zip. Open ADB terminal and move into the adb archive. ADB Terminal window Step 2 Connect the HMI device to the computer via USB.

  • Page 58: Ota Update Guide

    User Manual Chapter 4 Software Installation 4.3 OTA Update Guide OTA is a tool which can help you to update OS image. To receive Android OS image file contact our sales representatives. Once you get the image file follow the guideline below.
  • Page 59 User Manual Chapter 4 Software Installation Step 4 Tap Update Image Step 5 Make sure the file founded by the system is image update file. Tap OK. Step 6 Tap OK. Make sure the battery level is at least 50%. 7”...
  • Page 60 User Manual Chapter 4 Software Installation Step 7 Tap OK. IMPORTANT: Do not disconnect the power source! Do not remove the battery! Step 8 After update the system will automatically restart. 7” S-Series HMI...

  • Page 61: Os Image Update Guide

    User Manual Chapter 4 Software Installation 4.4 OS Image Update Guide Download OS Image update guide from Winmate Download Center or Winmate File Share. Winmate Download Center: http://www.winmate.com/DownCenter/DownLoadCenter.asp?DownType=3018 Winmate File Share: https://winmate.box.com/v/FA34-OS-Image-Update-Guide 7” S-Series HMI...
  • Page 62 Mounting Solutions This chapter provides step-by-step mounting guide for all available mounting options. 7” S-Series HMI...

  • Page 63: Chapter 5: Mounting Solutions

    User ManuaI Chapter 5 Mounting Solutions Chapter 5: Mounting Solutions This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. 5.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the HMI device.

  • Page 64: Mounting Guide

    5.3 Mounting Guide S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. The main mounting approach is chassis - very user-friendly in terms of installation. Refer to sub-sections below for more details. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury.

  • Page 65: Vesa Mounting

    User ManuaI Chapter 5 Mounting Solutions 5.3.2 VESA Mounting 5.3.2.1 VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: PCVS-V1 Part Number: 99KK00A0000E Mounting Instruction ...
  • Page 66 5.3.2.2 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part Number: 9B0000000128 Mounting Instruction  Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 67 User ManuaI Chapter 5 Mounting Solutions 5.3.2.3 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction 7”...
  • Page 68 Accessories Dimensions 7” S-Series HMI...

  • Page 69: Technical Support

    Technical Support This chapter includes the directory for technical support. 7” S-Series HMI...

  • Page 70: Chapter 6: Technical Support

    Download OS Image Tool Guide To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center or Winmate File Share. 6.1.1 Winmate Download Center Go to http://www.winmate.com/...

  • Page 71: Problem Report Form

    User Manual Chapter 6 Technical Support 6.2 Problem Report Form 7" S-Series HMI (Slim-line) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.

  • Page 72: Product Specifications

    Product Specifications This section includes product specifications. Appendix 7” S-Series HMI...

  • Page 73: Appendix A: Product Specifications

    SD Card 1 x Micro SD Card Slot CAN Bus 1 x CAN Bus Peripheral Built-in LED Status Bar RGB LED Light Status Bar (only for W07FA3S-PCM1AC-PoE) Camera 2 MP Front Camera (Optional) Audio Output 1 Watt Speaker Mechanical Specification Dimensions 189.4 x 145.4 x 37.7 mm...
  • Page 74 Environmental Consideration Operating 0°C ~ +55°C Temperature Operating Humidity 10% ~ 90% (non-condensing, RH) IP Rating Front IP65 Power Specifications Power Input 12V DC Power Consumption Power Device (PD): Power over Ethernet IEEE 802.3at (25 W) IEEE 802.3af (15 W) Standards and Certification Certification CE, FCC...
  • Page 75 Supported NFC Tag This section includes the list of supported NFC tags. Appendix 7” S-Series HMI...

  • Page 76: Appendix B: Supported Nfc Tag

    User Manual Appendix B Supported NFC Tag Appendix B: Supported NFC Tag The NFC Reader of this device supports the following card type. Supported Card Type (13.56MHz) NFC Forum Platform Type 1, Type 2, Type 3, Type 4 ISO 15693 TI HF-I Plus, TI HF-I Pro, NXPI-Code SLI ISO 14443-A...
  • Page 77 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...

This manual is also suitable for:

W07fa3s-pcm1-poe
