OptiFlo
Plastic Pump
®
for Aboveground Pools
Installation, Operation & Service Manual
Listed
PUMP IS DESIGNED AND INTENDED FOR USE TO CIRCULATE
WATER IN ABOVEGROUND SWIMMING POOLS.
WARNING
READ AND FOLLOW ALL INSTRUCTIONS
Pentair Water Pool and Spa, Inc.
1620 Hawkins Ave., Sanford, NC 27330 • 800-831-7133 or (919) 566-8000
10951 West Los Angeles Ave., Moorpark, CA 93021 • 800-831-7133 or (805) 553-5000
Visit us on the Internet at: www.pentairpool.com or www.staritepool.com
P/N 350039 Rev. C 8-24-06
1
Advertisement
Table of Contents
Related Manuals for Pentair Pool Products 4HP-VD - 3' STD
Summary of Contents for Pentair Pool Products 4HP-VD - 3' STD
- Page 1 WATER IN ABOVEGROUND SWIMMING POOLS. WARNING READ AND FOLLOW ALL INSTRUCTIONS Pentair Water Pool and Spa, Inc. 1620 Hawkins Ave., Sanford, NC 27330 • 800-831-7133 or (919) 566-8000 10951 West Los Angeles Ave., Moorpark, CA 93021 • 800-831-7133 or (805) 553-5000 Visit us on the Internet at: www.pentairpool.com or www.staritepool.com...
-
Page 2: Table Of Contents
® Engineered Plastic Pump Installation, Operation & Service Manual SECTION I. HOW YOUR PUMP WORKS ... 3 SECTION II. INSTALLATION ... 3-6 SECTION III. PUMP OPERATION AND MAINTENANCE ... 6 SECTION IV. SEAL REPLACEMENT PROCEDURE ... 6-7 SECTION V. WINTERIZING PROCEDURE ... 7 SECTION VI. -
Page 3: Section I. How Your Pump Works
READ AND FOLLOW ALL SAFETY INSTRUCTIONS SECTION I. HOW YOUR PUMP WORKS Your centrifugal pump is designed to operate for years with proper maintenance. The pump housing, seal plate, hair and lint pot and impeller are made from high quality thermoplastic materials. These materials have been selected for their corrosion resistance nature. - Page 4 4. Provide space and lighting for routine maintenance access. Do not mount electrical controls directly over pump. 5. The pump should be installed as near to the pool or spa as practical. Avoid installing the pump above the water level. Suction lifts of more than 1/2 foot will cause very long priming times, and potentially damage the pump. 6.
- Page 5 17. The pump motor must be wired for the proper voltage in accordance with the wiring diagram supplied with the motor. Wiring the motor with the incorrect supply voltage will cause damage to the motor and void the warranty. 18. The wiring to the motor should be kept as short as possible and large enough NOT to cause an excessive voltage drop.
-
Page 6: Initial Start-Up
INITIAL START-UP: 1. Relieve all system pressure and open all air bleeders on total hydraulic system prior to starting the pump. See filter owner's manual. 2. Ensure that all fittings, clamps, closures and couplings are tight and in accordance with equipment manufacturer's recommendations. -
Page 7: Section V. Winterizing Procedure
4. Use extreme care when handling the mechanical seal. The mating seal surfaces are polished and are easily damaged. 5. The mechanical seal can be changed without disconnecting piping by removing 4 bolts (see item 14 on page 9) and pulling the motor with pump seal plate and impeller assembly away from front pump housing body. -
Page 8: Section Vi. Troubleshooting Guide
SECTION VI. TROUBLESHOOTING GUIDE The following are some common causes of problems that may arise. PROBLEM CAUSE REMEDY P/N 350039 Rev. C 8-24-06... -
Page 9: Section Vii. Technical Data
SECTION VII. TECHNICAL DATA REPLACEMENT PARTS Item No. Part No. Description P/N 350039 Rev. C 8-24-06... -
Page 10: Replacement Parts
REPLACEMENT PARTS (BASE MOUNTED UNITS) For cord and plug connected units, the base should be mounted as shown. DIMENSIONAL DATA Suction 10.00" 7.26" 3.50" P/N 350039 Rev. C 8-24-06 Item No. Part No. 9.33" Vertical Discharge 4.09" Description 7.75"... -
Page 11: Pump Curves
PUMP CURVES P/N 350039 Rev. C 8-24-06 Pentair Pool Products ® OptiFlo Series 50 Hz Pump Curves Flow Rate in US GPM CUBIC METERS PER HOUR Pentair Pool Products ® OptiFlo Series 60 Hz Pump Curves Flow Rate in U.S GPM CUBIC METERS PER HOUR ®... -
Page 12: Save These Instructions
Trademarks and Disclaimers. The Pentair Pool Products logo and OptiFlo are registered trademarks of Pentair Water Pool and Spa, Inc. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Pentair Water Pool and Spa, Inc.
