- Page 1 1840 East 27th Street Vernon, CA 90058 USA http://www.pelicanperformance.com http://www.pelicanacc.com Pelican and its logo are registered trademarks. Eclipse RF Xbox™ is a registered trademark of Microsoft Corporation. PL-2006 This product is not designed, manufactured, sponsored or Ref#081803 endorsed by Microsoft Corporation.
-
Page 2: Table Of Contents
ENGLISH TABLE OF CONTENTS Gamers Guarantee ... 1 Console Protection Guarantee... 1 Product Layout ... 2 Product Overviews ... 3 Instructions ... 4-7 Trouble Shooting ... 8 Warranty Information ... 9 FCC Notice ... 10... -
Page 3: Gamers Guarantee
CD/DVD load and read mechanism, internal operating system, nor the cabinet of the video game system. This warranty will not apply if the Pelican controller is not used as directed in the product manual enclosed. -
Page 4: Product Layout
ENGLISH Eclipse Wireless Controller White Button L Button Analog Stick Power On/Off- Rumble Off Switch D-Pad Back Button Eclipse Wireless Receiver Memory Card Slots Signal LED (Red) Link LED (Red) Product Layout Channel Switch CHANNEL 1 2 3 4 OFF ON RUMBLE BACK START BAND... -
Page 5: Product Overviews
PRODUCT OVERVIEW Eclipse Wireless Controller uses advance technology which gives you the ability to play without the limitations of a typical corded controller, hence there are a few switches and LED (lights) not found on your basic Xbox™ Controller. • Channel Switch (Receiver and Controller): This switch selects the broadcast channel of the radio frequency. -
Page 6: Instructions
ENGLISH 1.Insert Batteries: Remove the battery lid and place the two AA batteries (included) into the Eclipse Wireless Controller. Make sure they are inserted as shown in the battery compartment. The batteries included are not long life. 2.Plug in the Receiver: With the Xbox™... - Page 7 3.Check Band setting: Confirm that the Band Switch is set to A on both the controller and the receiver. Note: the only time you would ever change this switch is if you experienced a drop off in the signal, causing game play to be suspended. If this happens repeatedly we suggest you switch to Band B on both the Controller and Receiver.
- Page 8 ENGLISH 4.Select a Channel on the Controller: You may select any channel you desire 1, 2, 3 or 4. 5.Select a Channel on the Receiver: This must match the channel selected on the Controller. Note: If using more then one controller you must use different channel settings, i.e., the first controller and receiver are set to Channel 1, the second controller and receiver are set to...
- Page 9 6.Turn ON the Controller Turn the power switch located on the Controller to the ON position - You will see the following: On the Controller the LED will come on, lit green Note: If the LED on the pad comes on and goes to Red this is your low battery indicator meaning your battery has less then 20% power capacity.
-
Page 10: Trouble Shooting
ENGLISH TROUBLE SHOOTING If you are having difficulties with your new Eclipse Wireless Controller please refer below: My system turns on but I don’t see anything on the TV. 1.Check to verify that your A/V cable is properly connected to your system. 2.Check to verify that your A/V cable is properly plugged into your television set. -
Page 11: Warranty Information
120 days from the date of purchase. If a defect covered by this warranty occurs during this period, Pelican Accessories at its option will repair or replace, at no charge, any part that Pelican Accessories determines to be defective. -
Page 12: Important Notice
Pelican and its logo are registered trademarks. Xbox™ is a registered trademark of Microsoft Corporation. This product is not designed, manufactured, sponsored or endorsed by Microsoft Corporation.
