Page 1: Quick Setup Guide
ALTAI B5 WIRELESS PTP/PTMP BRIDGE QUICK SETUP GUIDE Version 1.0 Date: October, 2013 Altai Technologies Ltd. All rights reserved... - Page 2 100 meters. ODU: IDU: Service cable RJ-45 connector Figure 2. Ind Grounding clamp/damping Console port system window DO NOT BLOCK! ALWAYS LOOKS DOWN! Figure 1. Outdoor Unit oor Unit Figure 2. Iutdoor Unit Altai Technologies Ltd. All rights reserved...
- Page 3 Stick rubber filler – 5 on the Part 4, previously having removed protective white layer from rubber filler -5. Insert Part 2 inside part 4 up to the stop. Part 2 must be entirely within Part 4. Altai Technologies Ltd. All rights reserved...
- Page 4 Put Part 4 on the attached in the previous step RJ-45 connector. Step 5. Screw Part 2 on Part 4. This fixes the “RJ-45” connector on the cable. Check that the connector is properly fixed on the cable. Altai Technologies Ltd. All rights reserved...
- Page 5 Figure 3. RJ-45 cable connector soldering scheme Power on Plug the power cord into the IDU Power supply connector and to the Power supply socket (220V 50 Hz or 110V 60 Hz depending on the country of residence). Altai Technologies Ltd. All rights reserved...
-
Page 6: Accessing The Unit
TPS13-010_rev1.0 Accessing the Unit: To access the unit via console: Using Altai Console Cable please connect the unit’s console port (see Fig. 1) to COM-port of your PC/Laptop. In order to accomplish the steps described in this section your PC/Laptop must be equipped with a... - Page 7 If you connected everything properly, selected the right port and made its configuration right, After pressing enter on the white blank screen (after step 8) you should see WANFleX OS prompt as shown on Figure 7 Altai Technologies Ltd. All rights reserved...
- Page 8 B5 Quick Installation Guide TPS13-010_rev1.0 Figure 7. WANFleX OS prompt 10. Your device has a factory configuration. Default login is altai, default password is wag. Once this is done, you will see CLI (Command Line Interface). See Figure 8 Figure 8. “Login” screen 11.
- Page 9 Connect the unit to LAN/PC/Laptop using UTP cable with RJ-45 connectors. The procedure is the following: 1. Open the Control Panel in Windows. See Figure 10 Figure 10. Open Control Panel 2. Open “Network connections” icon. See Figure 11 Figure 11. “Network connections” Altai Technologies Ltd. All rights reserved...
- Page 10 Ethernet adaptor to some address from 192.168.1.0/24 network (e.g. change “IP-address” field to “192.168.1.23” and “Subnet mask” to “255.255.255.0”). After that click OK and move to step 7. See Figure 14 Altai Technologies Ltd. All rights reserved...
- Page 11 “Advanced…” button (Figure 14). In “Advanced TCP/IP Settings” click “Add” and put alias IP-address and mask (e.g. “192.168.1.2” and “255.255.255.0” correspondingly). See Figure 15. Click OK in all windows opened in the described procedure. Figure 15. Create alias Altai Technologies Ltd. All rights reserved...
-
Page 12: Check Connectivity
To connect to the device via Web-browser type: http://<device IP-address> (by default: http://192.168.1.20). You can also make an SSL-secured connection: https://<device IP-address> (by default: https://192.168.1.20). For complete Web-interface configuration and user guide please see B5 Wireless Bridge Configuration Manual. To configure via command line: For simplest configuration in... - Page 13 In this case link quality can be improved by such actions as antenna alignment, cable connectivity testing and so on. Muffer utility Type: muffer stat Muffer can be used for statistics gathering for estimating link load intensity and per client. Altai Technologies Ltd. All rights reserved...
-
Page 14: Load Meter
Load meter. Type: loadm –l <IFNAME> (for example, loadm –l rf4.0) Load meter is a tool to perform the channel load monitoring. It allows estimating the load of a system interfaces specified by interface parameter. Altai Technologies Ltd. All rights reserved... - Page 15 XX seconds (this is very helpful when there is a risk of loosing a remote unit while performing risky manipulations with configuration). “restart 0” cancels postponed reboot. “quit” – closes current telnet session Altai Technologies Ltd. All rights reserved...
-
Page 16: Mounting Kit (Mount-Kit-85)
The direct lightning strike to the STP service cable (ODU- IDU) is partially terminated on the grounded IDU case. Partial termination means that the direct lightning strike will probably destroy an STP cable. The service cable pickups Altai Technologies Ltd. All rights reserved... - Page 17 A special attention should be paid if antenna used is not DC-shorted. In this case additional lightning arrestor should be used between the antenna and ODU. Suggested grounding diagram is shown on the picture below. Figure 20. Grounding Altai Technologies Ltd. All rights reserved...
