Hirschmann GigaLION-24TP User Manual

Gigabit ethernet workgroup switch
Hide thumbs Also See for GigaLION-24TP:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User-Guide
Installation
Gigabit ETHERNET Workgroup Switch
GigaLION-24TP
GigaLION-24TP
Technical Support
Release 1.0 06/05
HAC-Support@hirschmann.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GigaLION-24TP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hirschmann GigaLION-24TP

Summary of Contents for Hirschmann GigaLION-24TP

  • Page 1 User-Guide Installation Gigabit ETHERNET Workgroup Switch GigaLION-24TP GigaLION-24TP Technical Support Release 1.0 06/05 HAC-Support@hirschmann.de...
  • Page 3 User-Guide Installation Gigabit ETHERNET Workgroup Switch GigaLION-24TP GigaLION-24TP Technical Support Release 1.0 06/05 HAC-Support@hirschmann.de...
  • Page 4 This manual has been created by Hirschmann Automation and Control GmbH according to the best of our knowledge. Hirschmann reserves the right to change the contents of this manual without prior notice. Hirschmann can give no guarantee in respect of the correctness or accuracy of the details in this manual.

  • Page 5: Japan Vcci Class A

    Compliances and Safety Warnings FCC - Class A This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
  • Page 6 CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC.

  • Page 7: Safety Compliance

    Safety Compliance Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable CLASS I LASER DEVICE ends when they are powered on.
  • Page 8 Power Cord Set U.S.A. and Canada The cord set must be UL-approved and CSA certified. The minimum specifications for the flexible cord are: - No. 18 AWG - not longer than 2 meters, or 16 AWG. - Type SV or SJ - 3-conductor The cord set must have a rated current capacity of at least 10 A The attachment plug must be an earth-grounding type with NEMA...
  • Page 9 France et Pérou uniquement: Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un transformateur d’isolement à rapport 1:1, avec un point secondaire de connexion portant l’appellation Neutre et avec raccordement direct à...

  • Page 10: Warnings And Cautionary Messages

    Stromkabel . Dies muss von dem Land, in dem es benutzt wird geprüft werden: Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen einhalt- Europe Das Netzkabel muß vom Typ HO3VVF3GO.75 (Mindestanforderung) sein und die Aufschrift <HAR> oder <BASEC> tragen. Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”). Warnings and Cautionary Messages Warning: This product does not contain any serviceable user parts.

  • Page 11: Manufacturing Materials

    All printed documentation for this product uses biodegradable paper that originates from sustained and managed forests. The inks used in the printing process are non-toxic. Purpose This guide details the hardware features of the Hirschmann GigaLION-24TP switch, including its physical and performance-related characteristics, and how to install the switch.
  • Page 12 viii...

  • Page 13: Table Of Contents

    Contents Chapter 1: Introduction Overview Switch Architecture Network Management Options Description of Hardware 10/100/1000BASE-T Ports SFP Slots Status LEDs Optional Redundant Power Unit Power Supply Receptacles Features and Benefits Connectivity Expandability Performance Management Chapter 2: Network Planning Introduction to Switching Application Examples Collapsed Backbone Network Aggregation Plan...
  • Page 14 Contents Chapter 4: Making Network Connections Connecting Network Devices Twisted-Pair Devices Cabling Guidelines Connecting to PCs, Servers, Hubs and Switches Network Wiring Connections Fiber Optic SFP Devices Connectivity Rules 1000BASE-T Cable Requirements 1000 Mbps Gigabit Ethernet Collision Domain 100 Mbps Fast Ethernet Collision Domain 10 Mbps Ethernet Collision Domain Cable Labeling and Connection Records Appendix A: Troubleshooting...
  • Page 15 Tables Table 1-1. Port Link and Activity LEDs Table 1-2. System Status LEDs Table 3-1. Serial Cable Wiring Table 4-1. Maximum 1000BASE-T Gigabit Ethernet Cable Length Table 4-2. Maximum 1000BASE-SX Gigabit Ethernet Cable Length Table 4-3. Maximum 1000BASE-LX Gigabit Ethernet Cable Length Table 4-4.
  • Page 16 Figures Figure 1-1. Hirschmann GigaLION-24TP Front and Rear Panels Figure 1-2. Hirschmann GigaLION-24TP Port LEDs Figure 1-3. Hirschmann GigaLION-24TP System LEDs Figure 1-4. Hirschmann GigaLION-24TP Power Supply Receptacles Figure 2-1. Collapsed Backbone Figure 2-2. Network Aggregation Plan Figure 2-3. Remote Connection with Fiber Cable Figure 2-4.

  • Page 17: Chapter 1: Introduction

    Chapter 1: Introduction Overview The Hirschmann GigaLION-24TP Gigabit Ethernet Switch is an intelligent switch with 24 10/100/1000BASE-T ports, four of which are combination ports that are shared with four SFP transceiver slots. There is also an SNMP-based management agent embedded on the main board. This agent supports both in-band and out-of-band access for managing the switch.

  • Page 18: Switch Architecture

    Description of Hardware 10/100/1000BASE-T Ports The Hirschmann GigaLION-24TP switch contain 24 RJ-45 ports that operate at 10 Mbps or 100 Mbps, half or full duplex, or at 1000 Mbps, full duplex. Because all ports on the switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 19: Status Leds

    Link /Act 1000=Green 10/100=Yellow ES4524C Full Duplex Operation SFP Port Enabled Figure 1-2. Hirschmann GigaLION-24TP Port LEDs Table 1-1. Port Link and Activity LEDs Condition Status RJ-45 Ports Link/Act On/Flashing Yellow The port has a valid 10 or 100 Mbps link. Flashing indicates activity.

  • Page 20: Optional Redundant Power Unit

    There are two power receptacles on the rear panel of each switch. The standard power receptacle is for the AC power cord. The receptacle labeled “RPU” is for the optional Redundant Power Unit (RPU). Power Socket Redundant Power Socket 100-240V~, 50-60Hz 2A DC IN 12V 8.5A Figure 1-4. Hirschmann GigaLION-24TP Power Supply Receptacles...

  • Page 21: Features And Benefits

    Features and Benefits Features and Benefits Connectivity • 24 or 48 dual-speed ports for easy Gigabit Ethernet integration and for protection of your investment in legacy LAN equipment. • Auto-negotiation enables each RJ-45 port to automatically select the optimum communication mode (half or full duplex) if this feature is supported by the attached device;...
  • Page 22 Introduction...

  • Page 23: Chapter 2: Network Planning

    Chapter 2: Network Planning Introduction to Switching A network switch allows simultaneous transmission of multiple packets via non-crossbar switching. This means that it can partition a network more efficiently than bridges or routers. The switch has, therefore, been recognized as one of the most important building blocks for today’s networking technology.

  • Page 24: Application Examples

    Ethernet ports built into the front panel or a Gigabit Ethernet port on a plug-in SFP transceiver. In the figure below, the Hirschmann GigaLION-24TP is operating as a collapsed backbone for a small LAN. It is providing dedicated 100 Mbps full-duplex connections to workstations and 1000 Mbps full-duplex connections to power users and servers.

  • Page 25: Network Aggregation Plan

    Network Aggregation Plan With 24 parallel bridging ports (i.e., 24 distinct collision domains), the Hirschmann GigaLION-24TP can collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput. In the figure below, the 10/100/1000BASE-T ports on the Hirschmann GigaLION-24TP are providing 1000 Mbps connectivity for up to 24 segments through layer 2 switches.

  • Page 26: Remote Connection With Fiber Cable

    Network Planning Remote Connection with Fiber Cable Fiber optic technology allows for longer cabling than any other media type. A 1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-LH link up to 70 km. This allows a Gigabit Ethernet Switch to serve as a collapsed backbone, providing direct connectivity for a widespread LAN.

  • Page 27: Making Vlan Connections

    Application Examples Making VLAN Connections The switch supports VLANs which can be used to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment.

  • Page 28: Application Notes

    Network Planning Application Notes Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode. Avoid using flow control on a port connected to a hub unless it is actually required to solve a problem.

  • Page 29: Chapter 3: Installing The Switch

    Chapter 3: Installing the Switch Selecting a Site The switch can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. • The site should: • be at the center of all the devices you want to link and near a power outlet. •...

  • Page 30: Equipment Checklist

    Then, before beginning the installation, be sure you have all other necessary installation equipment. Package Contents • Gigabit Ethernet Switch (Hirschmann GigaLION-24TP) • Four adhesive foot pads • Bracket Mounting Kit containing two brackets and four screws for attaching the brackets to the switch •...

  • Page 31: Mounting

    Mounting Mounting A switch unit can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. Rack Mounting Before rack mounting the switch, pay particular attention to the following factors: •...

  • Page 32: Desktop Or Shelf Mounting

    Installing the Switch Mount the device in the rack, using four rack-mounting screws (not provided). E S 4 5 2 4 Figure 3-3. Installing the Switch in a Rack If installing a single switch only, turn to “Connecting to a Power Source” at the end of this chapter.

  • Page 33: Installing An Optional Sfp Transceiver

    Installing an Optional SFP Transceiver If installing a single switch only, go to “Connecting to a Power Source” at the end of this chapter. If installing multiple switches, attach four adhesive feet to each one. Place each device squarely on top of the one below, in any order. Installing an Optional SFP Transceiver 1 0 0 0 = Y e ll o w...

  • Page 34: Connecting To A Power Source

    Installing the Switch Connecting to a Power Source To connect a device to a power source: Insert the power cable plug directly into the receptacle located at the back of the device. 100-240V~,50-60HZ 2A Figure 3-6. Power Receptacle Plug the other end of the cable into a grounded, 3-pin socket. Note: For International use, you may need to change the AC line cord.

  • Page 35: Connecting To The Console Port

    Connecting to the Console Port Connecting to the Console Port The DB-9 serial port on the switch’s front panel is used to connect to the switch for out-of-band console configuration. The on-board configuration program can be accessed from a terminal or a PC running a terminal emulation program. The pin assignments used to connect to the serial port are provided in the following tables.
  • Page 36 Installing the Switch...

  • Page 37: Chapter 4: Making Network Connections

    Chapter 4: Making Network Connections Connecting Network Devices The Hirschmann GigaLION-24TP switch is designed to interconnect multiple segments (or collision domains). It can be connected to network cards in PCs and servers, as well as to hubs, switches or routers. It may also be connected to devices using optional SFP transceivers.

  • Page 38: Network Wiring Connections

    Making Network Connections If the device is a PC card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet. (See “Network Wiring Connections” on page 4-2.) Otherwise, attach the other end to an available port on the switch.

  • Page 39: Fiber Optic Sfp Devices

    Fiber Optic SFP Devices Fiber Optic SFP Devices An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX or 1000BASE-LH) can be used for a backbone connection between switches, or for connecting to a high-speed server. Each multimode fiber optic port requires 50/125 or 62.5/125 micron multimode fiber optic cabling with an LC connector at both ends.

  • Page 40: Connectivity Rules

    Making Network Connections Connectivity Rules When adding hubs (repeaters) to your network, please follow the connectivity rules listed in the manuals for these products. However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

  • Page 41: 100 Mbps Fast Ethernet Collision Domain

    Cable Labeling and Connection Records 100 Mbps Fast Ethernet Collision Domain Table 4-5. Maximum Fast Ethernet Cable Length Type Cable Type Max. Cable Length Connector 100BASE-TX Category 5 or better 100-ohm UTP or STP 100 m (328 ft) RJ-45 10 Mbps Ethernet Collision Domain Table 4-6.
  • Page 42 Making Network Connections...

  • Page 43: Appendix A: Troubleshooting

    Appendix A: Troubleshooting Diagnosing Switch Indicators Table A-1. Troubleshooting Chart Symptom Action Power LED is Off • Power supply is disconnected. • Check connections between the switch, the power cord, and the wall outlet. • Contact your dealer for assistance. Power LED is Amber •...

  • Page 44: Installation

    Troubleshooting Installation Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly.

  • Page 45: Appendix B: Cables

    Appendix B: Cables Twisted-Pair Cable and Pin Assignments For 10/100BASE-TX connections, a twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes.

  • Page 46: Straight-Through Wiring

    Cables Table B-1. 10/100BASE-TX MDI and MDI-X Port Pinouts MDI Signal Name MDI-X Signal Name Transmit Data plus (TD+) Receive Data plus (RD+) Transmit Data minus (TD-) Receive Data minus (RD-) Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-) Not used Not used...

  • Page 47: 1000Base-T Pin Assignments

    Twisted-Pair Cable and Pin Assignments 10/100BASE-TX Crossover Cable White/Orange Stripe Orange White/Green Stripe End A End B Green Figure B-3. Crossover Wiring 1000BASE-T Pin Assignments All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 48: Fiber Standards

    Cables Cable Testing for Existing Category 5 Cable Installed Category 5 cabling must pass tests for Attenuation, Near-End Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This cable testing information is specified in the ANSI/TIA/EIA-TSB-67 standard. Additionally, cables must also pass test parameters for Return Loss and Equal-Level Far-End Crosstalk (ELFEXT).

  • Page 49: Appendix C: Specifications

    Weight Hirschmann GigaLION-24TP: 3.24 kg (7.17 lbs) Size Hirschmann GigaLION-24TP: 44.0 x 31 x 4.4 cm (17.4 x 12.2 x 1.8 in.) Temperature Hirschmann GigaLION-24TP: Operating: 0 to 50 °C (32 to 121 °F) Storage: -40 to 70 °C (-40 to 158 °F)

  • Page 50: Switch Features

    Internal, auto-ranging transformer: 90 to 240 VAC, 47 to 63 Hz External, supports connection for 14-pin redundant power unit Power Consumption Hirschmann GigaLION-24TP: 70 Watts maximum Maximum Current Hirschmann GigaLION-24TP: 0.7 A @ 110 VAC 0.3 A @ 240 VAC Switch Features Forwarding Mode Store-and-forward...

  • Page 51: Compliances

    Compliances IEEE 802.1D (Bridging) IEEE 802.3x full-duplex flow control ISO/IEC 8802-3 Compliances CE Mark Emissions FCC Class A Industry Canada Class A EN55022 (CISPR 22) Class A EN 61000-3-2/3 VCCI Class A C-Tick - AS/NZS 3548 (1995) Class A Immunity EN 61000-4-2/3/4/5/6/8/11 Safety CSA/CUS (CSA 22.2 NO60950-00 &...
  • Page 52 Specifications...

  • Page 53: Glossary

    Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable. 1000BASE-LH Specification for long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable.
  • Page 54 Glossary CSMA/CD CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, or Gigabit Ethernet. End Station A workstation, server, or other device that does not forward traffic. Ethernet A network communication system developed and standardized by DEC, Intel, and Xerox, using baseband transmission, CSMA/CD access, logical bus topology, and coaxial cable.
  • Page 55 Glossary IEEE 802.3z Defines CSMA/CD access method and physical layer specifications for 1000BASE Gigabit Ethernet. LAN Segment Separate LAN or collision domain. Light emitting diode used for monitoring a device or network condition. Local Area Network (LAN) A group of interconnected computer and support devices. Media Access Control (MAC) A portion of the networking protocol that governs access to the transmission medium, facilitating the exchange of data between network nodes.
  • Page 56 Glossary Unshielded twisted-pair cable. Virtual LAN (VLAN) A Virtual LAN is a collection of network nodes that share the same collision domain regardless of their physical location or connection point in the network. A VLAN serves as a logical workgroup with no physical barriers, allowing users to share information and resources as though located on the same LAN.

  • Page 57: Index

    Index Numerics 10 Mbps connectivity rules 4-5 DC input 1-4 100 Mbps connectivity rules 4-5 desktop mounting 3-4 1000 Mbps connectivity rules 4-4 device connections 4-1 1000BASE-T pin assignments B-3 ports 1-2 electrical interference, avoiding 3-1 100BASE-TX equipment checklist 3-2 pin assignments B-1 Ethernet connectivity rules 4-5 ports 1-2...
  • Page 58 Index Link 1-3 Power 1-4 rack mounting 3-3 RPU 1-4 rear panel receptacles 1-4 location requirements 3-1 redundant power unit 1-4 RJ-45 port 1-2 connections 4-1 management pinouts B-3 agent 1-2 features 1-5, C-2, C-3 optional redundant power unit 1-4 out-of-band 1-2 rubber foot pads, attaching 3-4 SNMP 1-2...
  • Page 60 Hirschmann GigaLION-24TP E062005-R01 150200051900A...
