Peavey DTH 218b Specification Sheet

S P E
®
DTH 218b
Low-Frequency
Loudspeaker

SPECIFICATIONS

Frequency Response, 1 Meter
On-Axis, Swept Sine in Anechoic
Environment:
45 Hz to 250 Hz
Low-Frequency Cut-Off (-3 dB point):
45 Hz
Usable Low-Frequency Limit
(-10 dB point):
35 Hz
Power Handling:
:
Speakers Parallel
1,000 W continuous (63.2 V RMS)
2,000 W program
4,000 W peak
C I F I
Speakers Independent:
500 W continuous (63.2 V RMS)
2 x 1,000 W program
2000 W peak
Sound Pressure Level, 2.0 V (1 watt)
• 1 meter in anechoic environment:
100 dB
Maximum Sound Pressure Level:
128 dB continuous
134 dB peak
Transducer Complement:
Two BW X 1888 HP Black Widow
Woofers
Box Tuning Frequency:
47 Hz
Recommended Crossover
Frequency:
150 Hz to 250 Hz range
Impedance (Z):
:
Speakers Parallel
4 ohms nominal
3.2 ohms minimum
C A T I
Speakers Independent:
8 ohms nominal
2 x 6.4 ohms minimum
Input Connections:
One Neutrik
(NL4MP)
One Neutrik
(NL8MP with four-conductor NL4MP
output)
Enclosure Materials and Finish:
3/4" plywood with black polyurethane
coating, black powder coat, metal grill
and polyester foam overlay grille
®
X
Dimensions (H x W x D):
47 1/4" x 22 3/4" x 29 3/4"
(120 cm x 57.8 cm x 75.6 cm)
Net Weight:
145 lbs. (64 kg)
O N S
® four-conductor Speakon
® eight-conductor Speakon
®
®
®
