Peavey 810 TX Specifications

Bass Enclosure

SPECIFICATIONS

Frequency Response, 1 meter
on-axis, swept sine in anechoic
environment:
Power Handling:
400 W continuous (40 V RMS)
800 W program
Transducer Complement:
Eight 10" KevlaKB impregnated woofers
One phenolic dome horn tweeter
Box Tuning Frequency:
35 Hz
Crossover Frequency:
3.5 kHz
Impedance, Z:
4 ohms nominal
3.8 ohms minimum
Input Connections:
One l/4" phone jack
Enclosure Materials & Finish:
corners and an expanded metal grille
Dimensions (H x W x D):
49" x 24.5" x 17.25"
(124.5 cm x 62.2 cm x 43.8 cm)
Net Weight:
148 Ibs. (67.3 kg)
DESCRIPTION
The 81 OTM TX is the newest, biggest,
and badest bass box from Peavey. New
for the 810 TX. To decrease unwanted
distortion, KevlarB impregnated cones
were used in these drivers. Increased
low frequency output is accomplished
by a substantial vent at the bottom of
the enclosure. The upper harmonics
needed to accurately reproduce sharp,
tight transients are handled by a horn
loaded tweeter. An automatic resetting
protection device has been placed in
the signal path of the tweeter. Should
too much power start going to the
tweeter this protection device will trip
resulting in almost no output from the
tweeter. As soon as the power level of
the high frequencies returns to a
nominal level, the device will reset itself
and output from the tweeter will return.
An L-pad attenuator has also been
designed into the crossover so that the
amount of high frequency content can
be custom tailored to any style of
playing or particular sound.
The 810 TX is a 4 ohm enclosure
capable of handling up to 800 watts.
