- Page 1 GTm 5250 Installation and Admin Guide 22 March 2016...
-
Page 2: Table Of Contents
Initial configuration Audio configuration Network configuration Allowing users to connect a laptop or other digital sources to the GTm 5250 Near-end camera control for GTm 5250 Typical installation of GTm 5250 Using the audio injector Appendix: LED behavior Network port LED... - Page 3 Legal information Third party software acknowledgments Disclaimers and notices StarLeaf Installation Guide Page 3 of 17...
-
Page 4: About The Codec
About the codec About the codec The connectors The figure below shows the connectors on the rear of the GTm 5250 codec. PTZ camera StarLeaf Microphone control touchscreen controller Power Audio line-out Network PTZ camera Audio line-in PC video-in Telepresence... -
Page 5: Leds
There are Power and Status LEDs on the front of the codec. LED behavior is described in Appendix: LED behavior (p16). Dimensions The GTm 5250 is designed to fit into a 19" communications rack and occupies 1.5U of height. Height Depth... -
Page 6: About The Touchscreen Controller
About the touchscreen controller About the touchscreen controller The GTm 5250 comes with a touchscreen controller: the StarLeaf Touch 2035. You will use the touchscreen controller as the means for making, and controlling video calls with GTm 5250. Through the touchscreen controller, you will access the directory and contacts, recent calls, and also the screen-share controls when in a video call. -
Page 7: Installing Gtm 5250
Installing GTm 5250 Installing GTm 5250 Before installing the StarLeaf GTm 5250, read the safety information at GTm 5250 safety compliance. Pre-requisites Before installing the GTm 5250, ensure you have the following: One or two telepresence screens that support a 1080p60 input format... -
Page 8: Connecting Network Cables To The Codec
> network port speed. Note: By default, the GTm 5250 will use DHCP to acquire an IP address. If necessary, you can configure the GTm 5250 with a static IP address, to do so: On the touchscreen controller that you have connected to the codec, go to settings >... -
Page 9: Creating A User Account
Installing GTm 5250 Creating a user account On your Lync/Skype for Business server, create a new user account for the GTm 5250. Make a note of the authentication details. (You can use an existing account if you prefer.) Configuring the GTm 5250 Initial configuration 1. - Page 10 Installing GTm 5250 4. Go to Upgrade, check that the GTm 5250 is running the most recent GTm 5250 software version. Here you can allow the GTm 5250 to download the latest version from the StarLeaf server if it can (if it has access to the public Internet). Alternatively, you can download the firmware from http://support.starleaf.com/product/room/gtm-5250...
-
Page 11: Audio Configuration
Installing GTm 5250 Audio configuration Go to Audio. You will have connected one of the following: StarLeaf microphones: If you have connected a StarLeaf microphone, ensure StarLeaf XLR microphones is selected. Note that any audio played to Line in connector (PC audio for example) will also be mixed with the microphone and sent to anyone you call. -
Page 12: Network Configuration
Proxy server: If there is a proxy server for your deployment, you will need to configure the details of that for the GTm 5250. Note that this is the same configuration as you would use for a PC running a Skype for Business/Lync client in the same location on your network. -
Page 13: Allowing Users To Connect A Laptop Or Other Digital Sources To The Gtm 5250
GTm 5250 users, leave the other end of the cable on the meeting room table. This allows users to connect a laptop to the GTm 5250 when they need to do so. The GTm 5250 includes a selection of adaptors to be used with the DVI-I to DVI-I cable where the video output of a PC is other than DVI-I (for example, VGA, HDMI, DVI-D). -
Page 14: Typical Installation Of Gtm 5250
Typical installation of GTm 5250 This diagram shows a typical installation of a GTm system. The selector on the rear of the PTZ camera Configuration must be correctly set. Refer to the camera To view settings and IP address, double-press the home documentation, or to the GTm documentation button on the controller. -
Page 15: Using The Audio Injector
Using the audio injector Using the audio injector If you want to send sound over HDMI to the screen of the GTm 5250 room system, you must use the audio injector. The dip switches on the audio injector must be correctly set. All dip switches must be zero except Mode switch 0, which must be set to 1. -
Page 16: Appendix: Led Behavior
On for 1000 Mbit/s link, off for 10/100 Mbit/s link or (On the right when looking at the no link port) StarLeaf Controller Port LED behavior State Link/Activity LED (Yellow) (On the Solid yellow indicates there is a link, flashing when... -
Page 17: Disclaimers And Notices
StarLeaf Limited. StarLeaf Limited reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of StarLeaf Limited to provide notification of such revision or change. StarLeaf Limited provides this documentation without warranty, term, or condition of any...
