Edgewater Networks EdgeMarc 250W Hardware Installation Manual
Enterprise session border controller
Hide thumbs
Also See for EdgeMarc 250W:
- Hardware installation manual (19 pages) ,
- Quick start manual (7 pages) ,
- Quick start manual (6 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Edgewater Networks EdgeMarc 250W
Summary of Contents for Edgewater Networks EdgeMarc 250W
- Page 1 EdgeMarc 250W Enterprise Session Border Controller Hardware Installation Guide Version 1.1 EWN007-01-B002 Edgewater Networks / 2895 Northwestern Parkway, Santa Clara, CA 95051 Phone: +1 (408) 351-7200 / Email: support@edgewaternetworks.com...
- Page 2 EdgeMarc is a trademark of Edgewater Networks, Inc. in the United States and other countries. Any other trademarks appearing in this manual are owned by their respective companies.
- Page 3 Documentation Feedback Edgewater Networks considers your satisfaction with this documentation a priority. If you would like to provide us with feedback regarding your experience with our documentation or should you have any other quality-related comment concerning its delivery, please visit the following URL: http://www.edgewaternetworks.com/feedback.htm...
-
Page 4: Table Of Contents
Contents Preface......................1 Typographic Conventions ..............1 Contact and Support Information ............2 Overview ......................3 Feature Summary..............4 Front Panel LEDs ................5 Back Panel ..................8 Getting Started ..................... 10 Physical Installation................10 Required Tools and Materials ..........10 Desktop Installation .............. -
Page 5: Preface
Preface Thank you for purchasing the 250W. This Installation Guide describes the 250W and hardware installation procedures. It is intended for network installers, network operators, and security officers. About this Guide The following table briefly describes each chapter and appendix in this guide. Chapter or Appendix Description Chapter 1, Overview... -
Page 6: Contact And Support Information
EdgeMarc 250W Enterprise Session Border Controller Installation Guide Contact and Support Information Edgewater Networks, Inc. 2895 Northwestern Parkway Santa Clara, CA 95051 http://www.edgewaternetworks.com Phone: +1 (408) 351-7200 General Email: info@edgewaternetworks.com Sales Email: sales@edgewaternetworks.com Edgewater Networks, Inc. - Technical Assistance Center Phone: +1 (408) 351-7200 ext. -
Page 7: Overview
Overview The 250W is an intelligent networking solution for enterprises and service providers. The 250W provides the following important functions for converged networks: • Security • A stateful packet inspection firewall is used in combination with a voice over IP (VoIP) application layer gateway to provide comprehensive “media-aware”... -
Page 8: Feature Summary
EdgeMarc 250W Enterprise Session Border Controller Installation Guide • 802.11 g (only) • 802.11 b/g/n Service Set Identifier (SSID) broadcast enable or disable option Authentication WEP (64 and 128 bit key) • • WPA-PSK (TKIP and AES encryptions) • Adjustable time period for broadcast messages •... -
Page 9: Front Panel Leds
EdgeMarc 250W Enterprise Session Border Controller Installation Guide Front Panel LEDs Figure 1: 250W Front Panel LEDs LED Label Activity Description The device is powered. Solid Power Green The device is not powered. Power-On Selt-Test is in Progress Flashing A device malfunction has occurred. - Page 10 EdgeMarc 250W Enterprise Session Border Controller Installation Guide LED Label Activity Description A device that is connected to the port is not powered or connected to the port. Solid DSL Connection is synchronized with actual data Green traffic. The device is not powered.
- Page 11 EdgeMarc 250W Enterprise Session Border Controller Installation Guide LED Label Activity Description Powered device is connected to the associated port. Solid Green Ethernet WAN Flickering LAN activity is occurring with the device that is Green connected to the port. Note: The flickering of the light will be synchronized with actual data traffic.
-
Page 12: Back Panel
EdgeMarc 250W Enterprise Session Border Controller Installation Guide Back Panel Figure 2: 250W Back Panel Name Description Antennas Antennas for the wireless LAN Phone Four FXS ports ADSL WAN/ FXO Connects the 250W to a phone line supporting ADSL/ADSL 2/2+ Port standards. - Page 13 EdgeMarc 250W Enterprise Session Border Controller Installation Guide Name Description from its power source. Ethernet WAN Connects the 250W to a cable or xDSL modem. Port Eight Local Area Network (LAN) ports to connect IP phones or 10/100/1000 data PCs.
-
Page 14: Getting Started
Getting Started Physical Installation The 250W is designed for desktop installation. Observe the following guidelines when installing the system: • Always verify that the AC cord is disconnected from a power source prior to installation. Do not stack multiple units on top of each other, as this can cause overheating. •... -
Page 15: Administration
EdgeMarc 250W Enterprise Session Border Controller Installation Guide Administration You can configure the . using a web browser such as Internet Explorer or Mozilla Firefox. 250W . is shipped with the pre-configured IP address 192.168.1.1 for the LAN port. 250W... - Page 16 EdgeMarc 250W Enterprise Session Border Controller Installation Guide 4. Select Network and start configuring the 250W. Note For secure network management, change the default user name and password as described in the VOS for EdgeMarc User Manual.
-
Page 17: Specifications
Specifications WAN Ports ADSL/ADSL 2/2+ or 10/100 Ethernet, LAN Ports 8x10/100/1000 Ethernet (Managed VLAN Switch) FXS Ports FXO Port 1 (integrated with ADSL WAN port) USB Ports Dimensions Height 40.386 mm Width 180.34 mmDepth 304.8 mm Weight 1.75 lbs. Power 12@ 3, External Warranty 1 Year... -
Page 18: Warranty Information
Warranty Information Hardware Warranty For a period of one (1) year after shipment of the Product, Edgewater warrants that such Hardware will substantially conform to Edgewater’s published specifications for such Hardware on the date of order if properly used in accordance with procedures described in the documentation supplied by Edgewater. -
Page 19: Certification And Compliance
If trouble is experienced with this equipment, Model 250W for repair or warranty information, please contact Edgewater Networks Technical Assistance Center at 408.351.7255 If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved. -
Page 20: Industry Canada (Ic) Notice
EdgeMarc 250W Series Converged Networking Router Installation Guide Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of Model 250W equipment does not disable your alarm equipment. -
Page 21: Fcc Statement
EdgeMarc 250W Series Converged Networking Router Installation Guide FCC Statement This product has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against such interference when operating in a commercial environment. - Page 22 Edgewater Networks, Inc. 2895 Northwestern Parkway Santa Clara, CA 95051 Phone: (408) 351-7200 info@edgewaternetworks.com Converged Networking. Simplified.
