A C C E S S O R Y I N S T R U C T I O N S

These instructions describe how to use the following

options for carrying the Monarch® Sierra Sport2™ 9460™

and Sierra Sport4™ 9493™ portable printers:

♦ hip strap

♦ clip

♦ shoulder strap

♦ hand strap

Information in this document supercedes information in

previous versions. Check our Web site

(www.monarch.com) for the latest documentation and

release information.

A t t a c h i n g t h e H i p S t r a p a n d C l i p

Put the hip strap on like a normal belt, inserting one

side of the buckle into the other. The adjustment

slide must face out.

To loosen or tighten the hip strap, move the slide

toward or away from the buckle.

TC9460ACPHOI Rev AF 10/07

Adjustment Slide

Table of Contents

Need help?

Do you have a question about the Monarch Sierra Sport4 9493 and is the answer not in the manual?

Page 1 The adjustment slide must face out. To loosen or tighten the hip strap, move the slide toward or away from the buckle. TC9460ACPHOI Rev AF 10/07 Adjustment Slide ©2007 Paxar Americas, Inc. a subsidiary of Avery Dennison Corp. All Rights Reserved.
Page 2 The slot on the clip must face out. Slot Lower the printer and slide the strap button into the slot on the outside of the clip until you feel it click into place.
Page 3 R e m o v i n g t h e H i p S t r a p a n d C l i p Holding the printer with one hand, press the release switch with your other hand and lift the printer up and out of the clip.
Page 4 A t t a c h i n g t h e S h o u l d e r a n d H a n d S t r a p s On both sides of the printer, place the loop over the strap button, and pull up gently.
