Cleanup Using
the Quick-
Flush Lid*
Start You will need:
• A garden hose
• A waste bucket
* Latex materials only
You will need a garden hose to complete
these steps. If you do not have a garden
hose available, or if you used oil-based
materials, follow the Cleanup for oil-Based
materials instructions on page 12.
English English
1
1. Remove the battery pack.
Pour the remaining material
back into the original container.
4
4. Using the spray tip, turn the
locking nut counterclockwise
until it is removed.
10
2
2. Remove the suction tube.
5
5. Slide the pump housing
assembly off the sprayer.
Remove the piston and spring
from the pump housing. Place
all removed parts (except the
pump housing) into the material
container (see inset).
3
3. Turn the spray tip counter-
clockwise until it is removed.
Pull out the atomizer valve,
being careful not to lose it.
6
6. Snap Quick Flush lid into
place on the pump housing
ring as shown.
