Summary of Contents for Kelvinator KHG950SS2
- Page 1 Built in Gas Hob KHG950SS2/KHG640SS2 User and Installation Instruction...
-
Page 2: Table Of Contents
Contents For your safety………………………………………………………………… 1 Description of the hob………………………………………………………… Instructions for use …………………………………………………………… 6 Cleaning and maintenance……………………………………………………… 8 For The Installation Technician Technical data………………………………………………………………… Instructions for the installation technician…………………………………… Electrical connection………………………………………………………… Adapting to the different types of gas………………………………………… Building into fitted kitchen units…………………………………………….. - Page 3 Guide to reading the instructions The following symbols will help you When reading the instructions: Safety information “Step by step” instructions Suggestions and Advice Information concerning environmental protection This appliance complies with the following EEC Directives: 73/23 and 90/683 (relating to Low Voltage); 89/336 (relating to Electromagnetic Compatibility);...
-
Page 4: For Your Safety
FOR YOUR SAFETY This appliance is adjusted to operate on LPG only. IF YOU SMELL GAS: Turn off gas supply at bottle Extinguish all naked flames; Do not operate any electrical appliances Ventilate the area Check for leaks as detailed in this manual If odour persists, contact your dealer or gas supplier immediately BURN-BACK (FIRE IN BURNER TUBE OR CHAMBER) In the event of a burn-back, where the flame burns back to the jet, immediately... - Page 5 Note that your invoice is required in the event that you wish make a guarantee claim. IMPORTANT INFORMATION FOR THE INSTALLER. This appliance may only be installed by a LP gas installer registered with the Liquefied Petroleum Gas Association of Southern Africa. The appliance must be installed in accordance with the requirements of SANS 10087-1 and any fire department regulations and/or local bylaws applicable to the area.
- Page 6 These instructions have been drawn up for your safety and that of others. You are therefore requested to read them carefully before installing and using the appliance. Keep this instruction manual for future reference as necessary. If the appliance is sold of moved, make sure that the manual is handed over to the new user .
-
Page 7: During Use
During use · This product is designed to cook foods inside ordinary homes and for non-professional purposes. It should not be used for any other purpose. · After using the appliance, make sure that all controls are in “CLOSED” or “OFF” position. -
Page 8: Description Of The Hob
Environmental protection advice · All the materials used are environmentally compatible and recyclable. Please make your contribution to conserving the environment by using the separate waste collection channels available. Decommissioned appliances · Appliances which are no longer used or usable are not worthless waste. Through environment-friendly disposal, a number of materials used in the production of your appliance can be recovered. -
Page 9: Instructions For Use
Instructions for use The hob control knobs The symbols on the control knobs mean the following: ● no gas flow maximum gas flow Minimum gas flow All operating positions must be set between the maximum and minimum flow settings, and never between the maximum setting and the closed position. -
Page 10: Lighting The Burners
Lighting the burners To obtain a flame more easily, light the burner before placing a cooking utensil on the pan stand To light a burner, proceed as follow: for Version with lighting integrated in control knob push the knob of the burner fully down and turn it anticlockwise to the “maximum flow”... -
Page 11: Cleaning And Maintenance
Cleaning and maintenance Before each operation, disconnect the appliance from the electrical mains and allow it to cool down. General cleaning Wash enameled parts with lukewarm water and detergent: do not use abrasive products which might damage them. Wash the flame caps and burner caps often with boiling water and detergent, taking care to remove all deposits The hob pan stands can also be washed in a dishwasher For stubborn dirt, use ordinary non-abrasive detergents or specific commercial... -
Page 12: Routine Maintenance
Routine maintenance Have the condition and efficiency of the gas pipe and the pressure regulator(if installed) checked periodically. If anomalies are found, do not repairs but have the faulty part replaced. To ensure good performance and safety, the gas regulator taps must be greased periodically. -
Page 13: Technical Data
Technical Data G30/31 OUTPUT OUTPUT 20mbar 20-30/37mbar 50mbar BURNER Nozzle Nozzle Nozzle TYPE Cons Cons Cons Making Making Making Small Auxiliary 1.00 0.30 0.70 0.095 0.50 0.43 burner Medium Semi-rapid 1.75 0.65 0.97 0.157 0.65 0.58 Burner Large rapid 1.15 0.286 0.85 0.75... -
Page 14: Installation Premises
Installation premises For proper operation of a gas appliance, the air necessary for the combustion of the gas must be able to flow into the room naturally. The air must flow into the room directly through openings in the outside walls. These openings must have an unobstructed cross-section must be no less than 2m /hfor each kw of power(see total power in kw on the appliance nameplate). -
Page 15: Connection To The Gas Supply
Connection to the gas supply The gas Connection must be made in accordance with the local standards. When installing fit a safety tap at the end of the pipeline. The appliance leaves the factory tested and set for the type of gas indicated on the plate inside the bottom guard, close to the gas connection pipe. -
Page 16: Electrical Connection
Electrical connection The appliance is profited to operate with a power supply voltage of 230Vsingle-phase. The connection must be made in accordance with the regulations and laws in force. Before making the connection, make sure that: 1) the safety circuit-breaker and the electrical system are able to withstand the load of the appliance(see nameplate). -
Page 17: Adapting To The Different Types Of Gas
Adapting to the different types of gas Changing the nozzles Remove the pan standee. 2) Remove the burner caps and flame caps from the burners. 3) Use a size 7 socket wrench to unscrew and remove the nozzles, replacing them with those corresponding to the type of gas to be used (see the table ). -
Page 18: Building Into Fitted Kitchen Units
Building into fitted kitchen units These hobs are designed for installation in fitted kitchen units up to 600mm deep with suitable characteristics. Any cabinet side panels taller than the height of the hob itself must be at least 150mm away from the opening into which the hob is inserted. The dimensions of the hob and the installation opening are shown in the illustration. -
Page 19: Installation Options
Installation options On base cabinet with door When constructing the cabinet, suitable precautions must be take to prevent contact with the casing of the hob, which becomes very hot during operation. The recommended method for overcoming this problem is illustrated in fig.1 The panel underneath the hob must be easily removable to allow the hob to be lacked in position and released incase of servicing work... - Page 20 Cutting-out size:...
-
Page 21: Customer Care
Physical Address where appliance is located Model and Serial Number of the appliance Clear and concise details of the fault Customer Care For general enquiries or information regarding Kelvinator appliances contact: Customer Care Department Kelvinator P.O. Box 3657 Johannesburg 2000... - Page 22 (b) For the remainder of the guarantee period where the repaired appliance is used or installed more than 50 kilometres from the nearest Kelvinator service agent or elsewhere in South Africa, travel costs to the place of use or installation shall be for the account of the purchaser.
- Page 23 6. Kelvinator shall not be responsible in terms of this guarantee for the replacement or repair of any part of the equipment which may have been damaged in transit if delivery is undertaken by any party other than Kelvinator or an authorised agent.
