- Page 1 USER MANUAL MODEL 515 DB-15 Surge Protector SALES OFFICE Part# 07M515-A (301) 975-1000 Doc# 074220UA Revised 11/22/96 TECHNICAL SUPPORT (301) 975-1007 http://www.patton.com...
- Page 2 Support: (301) 975-1007; http://www.patton.com; or, support@patton.com. 3.0 PRODUCT DESCRIPTION The Patton Model 515 DB-15 Surge Protector employs a solid state hybrid network to guard DB-15 data ports against data loss and hardware damage due to transient surges. Equipped with one male and one female DB-15 connector, the Model 515 inserts between the data cable and DB-15 port.
- Page 3 1500 Watts of protection to the data port. Note: We recommend that a Patton surge protector be connected to the other end of the data cable as well. APPENDIX A...
- Page 4 Dear Valued Customer, Thank you for purchasing Patton Electronics products! We do appreciate your business. I trust that you find this user manual helpful. We manufacture one of the widest selections of data communications products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multiplexers, transceivers, hubs, print servers and much more.
