Patton DMZ Secure Routers streamline DMZ implementation and secure-firewall configurations
for enterprise networks without sacrificing QoS for critical business traffic.
Triple-Port Power DMZ
Use to configure the 3rd 10/100 Ethernet port as
a physical and logical DMZ to keep traffic off the
local network.
VPN Tunnels
Standard IPSec with AH and ESP ensures maxi-
mum protection when traversing
unsecured networks.
Strong Encryption
DES, 3DES, and AES offer standards based
encryption algorithms from 56 to 256 bits.
QoS/CoS Profiles
Configurable burst tolerance, bandwidth guaran-
tees plus reduce per flow traffic jitter as required
by the application.
Configurable Security Profiles
Built-in IP address and IP port filtering, ACLs and
DoS attack detection creates a comprehensive
security environment.
Enhanced IP Services
DNS resolver and relay, NAT/NAPT, dynamic
DNS, and DHCP server, eases integration.
SNMP/HTTP Management
Easily manage the IPLink VPN Routers via a sim-
ple web browser interface.
IP Access Products
IPLink Managed VPN Routers
Model 2823 DMZ Secure Router
P
atton's IPLink Managed VPN Routers are a
family of next generation appliances that
address both the security and the traffic pri-
oritization needs of enterprises. The Model 2823
Secure DMZ Router with integrated QoS makes it
easy for enterprises to isolate their web servers in a
secure demilitarized zone (DMZ). The three-port
router provides physically and logically separates
connections to a private LAN and a DMZ network,
while still allowing secure business-class Internet
access with traffic-shaping services.
As with all IPLink VPN Router, the Secure DMZ
Router implements a comprehensive security envi-
ronment. It all starts with IPSec. By supporting ESP
as well as AH, IPLink VPN Routers provide data
integrity, authentication, anti-replay and data confi-
dentiality to any traffic flow. DES, 3DES, and AES
provide standard encryption up to 256 bits. Firewall
capabilities of the IPLink VPN Routers include
Access Control Lists (ACLs), IP address and port fil-
tering, and protection against Denial of Service
(DoS) attacks. Likewise, PPPoE protocols include
support for PAP and CHAP authentication.
Proven Patton design
Internal/external and
AC/DC power
Front panel LEDs show
operational status at a glance
QoS features include ToS/DiffServ marking
and the configuration of eight service class
tags per IEEE 802.1p/Q. With traffic schedul-
ing and shaping, create dedicated bandwidth
guarantees, configurable burst tolerance, and polic-
ing to include excess traffic
discard. IP fragmentation is
configurable to help mini-
mize jitter in traffic flows.
Advanced IP features
include RIPv1 & RIPv2
routing and static route
configuration. Static and
dynamic NAT, NAPT, DNS resolver and relay,
dynamic DNS, and DHCP server further add
to the capabilities of the IPLink VPN Router.
All IPLink VPN routers can be managed via a
web browser (HTTP), command line interface
(Telnet), or an SNMP management platform.
For more information, visit us at
ton.com.
VPN & QoS software comes
standard
10/100 Ethernet WAN with full-
duplex and auto MDI/MDI-X
operation
Special Rates
Available
Call for Details
www.pat-
10/100 LAN
Ethernet
switch with
full-duplex and
auto MDI/MDI-
X operation
