Patton electronics IPLink 2803 Specifications

Patton IPLink Managed VPN Routers with integrated WAN ports optimize and secure
information flows applying VPN encryption and QoS/CoS traffic management.
T1/E1, V.35 and X.21
Select the integrated serial port of choice.
VPN Tunnels
Standard IPSec with AH and ESP ensures
maximum protection when traversing unse-
cured networks.
Strong Encryption
DES, 3DES, and AES offer standards based
encryption algorithms from 56 to 256 bits.
QoS/CoS Profiles
Configurable burst tolerance, bandwidth guar-
antees plus reduce per flow traffic jitter as
required by the application.
Configurable Security Profiles
Built-in IP address and IP port filtering, ACLs
and DoS attack detection creates a comprehen-
sive security environment.
Enhanced IP Services
DNS resolver and relay, NAT/NAPT, dynamic
DNS, and DHCP server, eases integration.
SNMP/HTTP Management
Easily manage the IPLink VPN Routers via a
simple web browser interface.
IPLink
Managed VPN Routers
Patton IPLink
P atton's IPLink Managed VPN Routers with
integrated serial ports are a family of next
generation appliances that address both the
security and the traffic prioritization needs of enter-
prises. VPN routers enable the secure communica-
tion of remote offices, home offices, and mobile
users across insecure IP networks such as the
Internet. IPLink VPN Routers take it one step fur-
ther and integrate quality of service (QoS) to opti-
mize business traffic flows plus include a serial port
to eliminate the need for external converters.
IPLink VPN Routers implement a comprehensive
security environment. It all starts with IPSec. By
supporting ESP as well as AH, IPLink VPN
Routers provide data integrity, authentication,
anti-replay and data confidentiality to any traffic
flow. DES, 3DES, and AES provide standard
encryption up to 256 bits. Firewall capabilities of
the IPLink VPN Routers include Access Control
Lists (ACLs), IP address and port filtering, and
protection against Denial of Service (DoS) attacks.
Likewise, PPP/PPPoE protocols include support
Internal/external
and AC/DC power
Front panel LEDs
show operational
status at a glance
™ Router Products
™ Models 2803, 2821, & 2835
Proven Patton design
IPLink 2835
for PAP and CHAP authentication.
QoS features include ToS/DiffServ marking and the con-
figuration of eight service class tags per IEEE 802.1p/Q.
With traffic scheduling and shaping, create dedicated
bandwidth guarantees, configurable burst tolerance, and
policing to include excess traffic discard. IP, PPP, and
Frame Relay fragmentation is configurable to help mini-
mize jitter in traffic flows.
Advanced IP features include RIPv1 & RIPv2 rout-
ing and static route configuration. Static and
dynamic NAT, NAPT, DNS resolver and relay,
dynamic DNS, and DHCP server further add to the
capabilities of the IPLink
VPN Router. Frame Relay
support is included stan-
dard. All IPLink VPN routers
can be managed via a web
browser (HTTP), command
line interface (Telnet or
Special Rates Available
Console), or an SNMP man-
agement platform.
Visit www.patton.com for more information.
VPN & QoS software comes standard
Call for Details
Console port
Dual 10/100 Ethernet
with full-duplex and auto
MDI/MDI-X operation
