INSTALLING THE DVD-ROM DRIVE
5. Attach the rear panel of the Changer.
6. Set the SCSI ID.
For futher details, see A Hardware Tour
(p. 7) and the changer operating manual.
Note:
When setting the SCSI IDs, be careful not
to leave the pointer arrow of the SCSI ID
switch between two figures; be sure to set
the switch so that the arrow points a single
figure.
7. Set the function switches (SCSI
terminator & data block size
switches)
Set the terminator switch of the last drive
in the daisy-chain connection to ON.
For futher details, see A Hardware Tour
(p. 7) and the changer operating manual.
10
En
Data block size
SCSI Terminator
