Summary of Contents for Patton electronics IM2RC/F
- Page 1 USER MANUAL MODEL IM2RC/F 64k Co-Directional Rack Mount Modem Rear Card Part# 07MIM2RC/F-A SALES OFFICE Doc# 078411UA (301) 975-1000 Revised 5/4/98 TECHNICAL SUPPORT (301) 975-1007 An ISO-9001 http://www.patton.com Certified Company...
-
Page 2: Table Of Contents
The Model IM2RC/F has been tested and found to comply with the limits for a Class A computing device in accordance... -
Page 3: Ce Notice
LAN access,...the possibilites are endless! Supporting 64 kbps clear channel or 128 kbps octet mode data streams, the IM2RC/F can set its own clock or it take clocking from the G.703 network. -
Page 4: Configuring The Im2Rc/F Hardware Switches
Mode. sense of frame synchronization by inserting bi-polar violations in the AMI conding structure. When the IM2RC/F is set to Octet Timing Mode (On position), all communications equipment in the channel must be configured to communicate at 128 kbps (64 kbps data plus 64 kbps octet framing pattern) Additionally, all terminal equipment must support octet timing. -
Page 5: Connecting The Interface Driver Board
AMI structure when operating in Clear Channel (64 kbps) mode. This necessity is determined by communications or terminal equipment external to the the IM2RC/F. Use Switch S6 to configure the unit to transmit G.703 data to the network with or without BPVs. -
Page 6: Installation
Failure to ground yourself during installation may result in damage to the IM2RC/F card or the front function card. Slide the IM2RC/F rear card into the back of the chassis along the metal rails provided. Secure the IM2RC/F rear card using the metal screws provided. -
Page 7: Making Interface Connections
4.3 MAKING INTERFACE CONNECTIONS The Model IM2RC/F is designed to provide access to a 64 kbps co-directional G.703 PCM network. Figure 5 shows the position of the G.703 interface and the line interface of the IM2RC/F. This section describes how to connect the G.703 interface and the line interface. -
Page 8: Operation
Patton 16 port rack or a 2, 4, or 8 port ClusterBox™ chassis. A front function card, such as a baseband modem, CSU/DSU, or HDSL modem meets the IM2RC/F rear card in the mid-plane of the chassis. The IM2RC/F also requires a G.703 connection to the 64 kbps co- directional PCM network and a line connection to a remote Patton transmssion device. -
Page 9: Appendix A - Specifications
CTR 14, (Type Approval) - The symbol indicates that the Model IM2RC/F is in compliance with the applicable Telecom Directive of the EU. If your IM2RC/F is marked with this symbol, it is EU Telecom Type Approved and may be connected to the public network. -
Page 10: Appendix B - Factory Replacement Parts And Accessories
0805DEN ...Denmark Power Cord 0805FR ...France/Belgium Power Cord 0805IN ...India Power Cord 0805IS ...Israel Power Cord 0805JAP ...Japan Power Cord 0805SW ...Switzerland Power Cord IM2RC/F ...G.703 Rear Card APPENDIX D PATTON IM2RC/F 120 OHM G.703 INTERFACE PIN ASSIGNMENT (RJ45 Female Connector) Pin Number Signal 1... - Page 11 Signal 1..4-Wire RX+ 2 ...4-Wire RX- 3 ...no connection 4..2-Wire TIP/4-Wire TX+ 5 ...2-Wire RING/4-Wire TX- 6 ...no connection 7 ...no connection 8 ...no connection APPENDIX F PATTON IM2RC/F ARCHITECTURE Copyright 1998 Patton Electronics Company All Rights Reserved...
