- Page 1 USER MANUAL MODEL 504 & 505 Surge Protected DB-25 to Modular Adapters Part# 07M504/505-C Doc# 074241U, Rev. D Revised 1/21/08 C E R T I F I E D An ISO-9001 Certified Company SALES OFFICE (301) 975-1000 TECHNICAL SUPPORT (301) 975-1007...
-
Page 2: Radio And Tv Interference
1.1 RADIO AND TV INTERFERENCE The Model 504 & 505 Series units generate and use radio frequency energy, and if not installed and used properly—that is, in strict accordance with the manufacturer's instructions—may cause interference to radio and television reception. - Page 3 NOTE: Packages received without an RMA number will not be accepted. Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Patton Model 504 & 505. Technical Service hours: 8AM to 5PM EST, Monday through Friday.
-
Page 4: General Information
“standard” wiring). Up to 1500 Watts of surge protection per modular pin is provided. On the Models 504, an RJ-11 jack is used, and up to 6 pins may be protected. On the Model 505, an RJ-45 jack is used, and up to 8 pins may be protected. - Page 5 3) Plug your modular cable into the jack on the Model 504 or 505. If you have a Model 504, the cable must be terminated with an RJ-11 plug.
- Page 6 PATTON MODEL 504 & 505 SPECIFICATIONS Model 504 Connectors: Pins Wired: Surge Capacity: Response Time (RS-232): Response Time (RS-422): Model 505 Connectors: Pins Wired: Surge Capacity: Response Time (RS-232): Response Time (RS-422): Capacitance: Cable Length Burden: APPENDIX A DB-25 male or female, RJ-11 jack Custom, up to 6 wires 1.5 kW (10 x 1000μSec) in Compliance...
- Page 7 Dear Valued Customer, Thank you for purchasing Patton Electronics products! We do appreciate your business. I trust that you find this user manual helpful. We manufacture one of the widest selections of data communications products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multiplexers, transceivers, hubs, print servers and much more.
