- Page 1 Part# 07M2300M Doc# 077321U Rev. A Revised 4/14/03 An ISO-9001 Certified Company USER MANUAL MODEL 2300M SERIES OpticLink Ethernet Media Converters (2300M, 2310M, 2311M, & 2312M)
-
Page 2: Table Of Contents
CONTENTS Warranty Information ... 3 Radio and TV Interference... 3 CE Notice... 3 Service... 4 General Information... 5 Features... 5 Description... 6 Installation... 8 Installing a media converter... 8 End-to-end connection... 11 Operation... 12 LED indicators ... 12 Specifications ... 14 A.1 Interfaces/Connectors ... -
Page 3: Warranty Information
However, there is no guarantee that interfer- ence will not occur in a particular installation. If a 2300M Series unit does cause interference to radio or television reception, which can be deter-... -
Page 4: Service
and the Low Voltage Directive (LVD) of the Union European (EU). A Cer- tificate of Compliance is available by contacting Technical Support. This device is not intended to be connected to the public telephone network. Caution 1.3 SERVICE All warranty and nonwarranty repairs must be returned freight prepaid and insured to Patton Electronics. -
Page 5: General Information
2.0 GENERAL INFORMATION Thank you for your purchase of this Patton Electronics product. It has been thoroughly inspected and tested and is warranted for parts and labor. If you have any questions about this product, please call Patton Electronics Technical Support at (301) 975-1007. 2.1 FEATURES •... -
Page 6: Description
2.2 DESCRIPTION There are four base models in the Patton Model 2300M Series of stan- dards compliant Ethernet Media Converters (see Table 1) that convert and extend the reach of copper Ethernet over multi-mode fiber. Table 1: Model 2300M configurations... - Page 7 All Patton 2300M Series models are packaged in an ultra-miniature MicroPak chassis and feature power, fiber link and activity, and twisted- pair link and activity LED indicators. The Model 2300M Series of Ether- net Media Converters can be ordered with ST or SC fiber optic connec- tors and with 120VAC, 220VAC, universal interface (UI), -48 VDC, -24 VDC, or -12 VDC power supply adapters.
-
Page 8: Installation
The following sections describe installing and configuring the Model 2300M Series of Ethernet Media Converters 3.1 INSTALLING A MEDIA CONVERTER Do the following to install the Model 2300M Series of Ethernet Media Converters: 1. The MDI/MDI-X switch enables you to connect the 2300M models to different types of network devices using a standard (straight- through) network patch cable. - Page 9 2. The media converter comes equipped with a shielded RJ-45 Jack for Ethernet connections (see Figure 1 on page 8). Connect the Ethernet RJ-45 jack to the appropriate 802.3 compliant network equipment via a standard network patch cable (not pro- vided).
- Page 10 4. Connect the DC power output side of the power supply adapter to the power jack (see Figure 1 on page 8) on the 2300M Series unit. 5. Connect the AC power side/cord of the power supply adapter to the appropriate AC power source.
-
Page 11: End-To-End Connection
3.2 END-TO-END CONNECTION Figure 4 shows an end-to-end connection between a personal computer/ terminal and Ethernet hub using two Patton Model 2300M Series Ether- net Media Converters and a multi-mode fiber connection. Figure 4. End-to-end multi-mode fiber connection... -
Page 12: Operation
Once powered up, LED indicators located on the side of the Model 2300M Series unit will illuminate to indicate the operating status of the unit. Figure 5. Location of 2300M Series LED indicators (Move fiber connectors to the opposite end of the converter) - Page 13 (Not used on Model 2310M.) Blinks yellow to show activity on the twisted-pair/ copper side of the unit. Illuminates green to show that a 10 Mbps signal is present on the twisted-pair/copper side of the unit. (Not used on Model 2300M.)
-
Page 14: Specifications
• 85/125 µm multi-mode fiber • 50/125 µm multi-mode fiber 1.6 FIBER WAVELENGTH • 2300M & 2312M: 1300nm • 2310M & 2311M: 850nm * Physical characteristics of the twisted-pair/copper and fiber optic cable must meet or exceed IEEE 802.3 specifications. -
Page 15: Fiber Optic Link Budget
• 2310M: -28 dBm (typical) • 2311M: -28 dBm (typical) • 2312M: -33.5 dBm (typical) Delay Time • 2300M: 5µs per km (typical) • 2310M: 5µs per km (typical) • 2311M: 5µs per km (typical) • 2312M: 5µs per km (typical) Typical Fiber Max. -
Page 16: Compliance
Less than 1 lb. (0.45 kg) with power supply A.13 DIMENSIONS 3.0L x 1.8W x 0.8H in. (7.6L x 4.4W x 1.9H cm) A.14 ENVIRONMENT Model 2300M and 2312M • Temperature: 32–95°F (0–35°C) • Humidity: up to 90% non-condensing Model 2310M and 2311M •...
