INSTRUCTION MANUAL
IMPORTANT INFORMATION
GB
sure you understand them before using this unit. Retain these instructions for future
reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS:
FR
atentivement les instructions et assurez- -vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
DE
Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE:
ES
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc-
ciones para la referencia en el futuro.
LIBRETTO D'ISTRUZIONI
INFORMAZIONI IMPORTANTI
IT
istruzioni e prendere dimestichezza con il prodotto prima di usario. Mantenga
queste istruzioni per riferimento futuro.
HANDLEIDING
BELANGRIJKE IMPORTANTS:
NL
zeker van dat uze begrijpt alvorens de blower te gebrulken en bewaar ze voor
toekomstige raadpleging.
: Please read these instructions carefully and make
Avant d'utiliser cet appareil, veuillez lire
Lesen Sie diese Hinweise zur Handhabung des
Lea atentamente las instrucciones y
: Siete pregati di leggere attentamente questo
Lees deze instructies zorgvuldig en wees er
115353827
Rev. 2 2/22/10 BRW
Advertisement
Table of Contents
Related Manuals for Partner GBV 345
Summary of Contents for Partner GBV 345
- Page 1 Mantenga queste istruzioni per riferimento futuro. HANDLEIDING BELANGRIJKE IMPORTANTS: zeker van dat uze begrijpt alvorens de blower te gebrulken en bewaar ze voor toekomstige raadpleging. : Please read these instructions carefully and make Avant d’utiliser cet appareil, veuillez lire...
-
Page 2: Know Your Unit
Use your unit as a blower for: Sweeping debris or grass clippings from driveways, sidewalks, patios, etc. Blowing grass clippings, straw, or leaves into piles, around joints, or between bricks. -
Page 3: Safety Notice
Keep children, bystanders, and animals away from work area a minimum of 15 meters when starting or operating unit. Do not point blower nozzle in the direction of people or pets. HANDLE FUEL WITH CAUTION Eliminate all sources of sparks or flame... -
Page 4: Carton Contents
A standard screwdriver is required for as- sembly. BLOWER ASSEMBLY BLOWER TUBE ASSEMBLY 1. Align the rib on the upper blower tube with the groove in the blower outlet; slide the tube into place. NOTE: The tube clamp bolt must be loose enough to allow blower tube to be inserted in blower outlet. - Page 5 Blower Outlet Groove 2. Secure the tube by turning the bolt clock- wise. 3. Align the slots on the lower blower tube with the tabs on the upper blower tube. Upper Blower Tube Lower Blower Tube Tube clamp bolt and nut Slot 4.
-
Page 6: Shoulder Strap Adjustment
2. Remove the vacuum tubes by turning the tubes clockwise. 3. Close the vacuum inlet cover and make sure it is latched closed. 4. Reinstall the blower tubes (see BLOWER TUBE ASSEMBLY). SHOULDER STRAP ADJUSTMENT 1. Hold the unit as shown with the muffler side facing away from your body and clothes. - Page 7 S Watch out for children, pets, open windows, or freshly washed cars. Blow debris away safely. S Use the full blower nozzle extension so the air stream can work close to the ground. S After using blowers and other equipment, CLEAN UP! Dispose of debris in trash re- ceptacles.
-
Page 8: Starting A Cold Engine
WARNING: When starting engine, hold the unit as illustrated. Do not set unit on any surface except a clean, hard area when starting engine or while engine is running. De- bris such as gravel, sand, dust, grass, etc. could be picked up by the air intake and thrown out through the discharge opening, damaging the unit or property, or causing seri- ous injury to bystanders or the operator. -
Page 9: Carburetor Adjustments
MAINTENANCE WARNING: Avoid touching muffler unless engine and muffler are cold. A hot muffler can cause serious burns. WARNING: Disconnect the spark plug before performing maintenance except for carburetor adjustments. CHECK FOR LOOSE FASTENERS AND PARTS S Muffler S Spark Plug Boot S Air Filter S Housing Screws CHECK FOR DAMAGED OR... -
Page 10: External Surfaces
decrease engine speed. Idle Speed Screw Filter Cover STORAGE WARNING: Prepare unit for storage at end of season or if it will not be used for 30 days or more. S Allow engine to cool, and secure the unit be- fore storing or transporting. - Page 11 We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46- -36- -146500, as authorised representative in the Community, declare that the garden blower/vacuum model Partner GBV 345 with serial numbers dating from 2009 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S...
-
Page 12: Technical Data
TECHNICAL DATA MODEL: GBV 345 ENGINE Engine displacement, cm Maximum Engine Power, according to ISO 8893, kW Idle Speed +/- - 400, rpm Catalytic converter muffler IGNITION SYSTEM Spark plug Electrode gap, mm FUEL AND LIBRICATION SYSTEM Fuel tank capacity, cm...
