Paradyne 1740 SHDSL User Manual

2/4-wire router
Hide thumbs Also See for 1740 SHDSL:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
1740 SHDSL
2/4-Wire Router
User's Guide
Document Number 1740-A2-GB20-00
July 2004

Advertisement

Table of Contents
loading

Related Manuals for Paradyne 1740 SHDSL

Summary of Contents for Paradyne 1740 SHDSL

  • Page 1 1740 SHDSL 2/4-Wire Router User’s Guide Document Number 1740-A2-GB20-00 July 2004...
  • Page 2 Further, Paradyne Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Paradyne Corporation to notify any person of such revision or changes.
  • Page 3 Preface This manual is designed to provide information to network administrators. It covers the installation, operation and applications of the 1740 SHDSL router. Warning Before servicing or disassembling this equipment, always disconnect all power and telephone lines from the wall outlet.

  • Page 4: Table Of Contents

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 1 OVERVIEW ... 7 Application... 7 LED Indicators... 8 CHAPTER 2 INSTALLATION... 9 Preparing for Hardware Installation ... 9 Rear-panel Connections ... 10 CHAPTER 3 QUICK INSTALLATION ... 11 3.1.1 Login... 11 3.1.2 Web Page Layout ...
  • Page 5 Adding the Static Route (Web) ... 63 CHAPTER 15 PIN ASSIGNMENTS ... 65 CHAPTER 16 CONSOLE ACCESS ... 66 16.1.1 Login ... 66 16.1.2 Keyboard Operations ... 67 16.1.3 Motoring the SHDSL Line Status ... 69 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 6 1740 SHDSL 2/4-Wire Router User’s Guide 16.1.4 Password Setup ... 70 16.1.5 Retrieve the Factory Default Settings ... 70 16.1.6 Disable the Web Browser ... 70 16.1.7 Save the Configurations ... 71 16.1.8 Login ... 71 APPENDIX A: SPECIFICATIONS ... 73...

  • Page 7: Chapter 1 Overview

    CHAPTER 1 Overview The 1740 SHDSL router satisfies the needs of multiple users in small/home offices and remote/branch offices. It provides symmetrical transmission speeds of up to 4.6 Mbps through a SHDSL connection, over a two-wire or four-wire line. In addition, it supports up to 16 virtual concurrent connections to multiple destinations.

  • Page 8: Led Indicators

    1740 SHDSL 2/4-Wire Router User’s Guide LED Indicators There are eight LEDs on the front panel of the router; the functions of the LEDs are described in the table below. Figure 1-1 Faceplate LED Indicators Color Mode POWER Green LAN 1–4...

  • Page 9: Chapter 2 Installation

    To connect to the hub, use a straight-through RJ45 cable. To connect to a PC, use a crossover RJ45 cable. Four-wire (8P8C) straight-through RJ45 cable A four-wire (8P8C) straight through RJ45 cable is needed to connect to the LINE port to the wall outlet. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 10: Rear-Panel Connections

    1740 SHDSL 2/4-Wire Router User’s Guide Rear-panel Connections DSL connection Connect the supplied RJ45 cable to the port marked LINE at the back of the SHDSL router. Connect the other end of the cable to your telephone-line wall outlet. Ensure your computer is turned on before you connect the DSL line to the router.

  • Page 11: Chapter 3 Quick Installation

    STEP 4: You will be prompted to enter your user name and password. Type your password, or if the password was not changed, type the default passwords. The default ADMINISTRATOR user name and password are root. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 12 1740 SHDSL 2/4-Wire Router User’s Guide STEP 5: After successfully logging in, you will reach the main configuration page. The left hand side has a menu and the right side is blank. July 2004 1740-A2-GB20-00...

  • Page 13: Web

    Main Window: The main window in middle of the page displays after clicking a button on the menu bar. It includes the tabs on the top of the window. The tabs lead to other sub-screens. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 14: Monitoring The Shdsl Line

    1740 SHDSL 2/4-Wire Router User’s Guide 3.1.3 Monitoring the SHDSL Line Click Link Status on the Basic menu bar. The Link Status screen has two tabs: SHDSL Status and Performance. SHDSL Status is used to monitor the SHDSL link and the Performance is used to monitor the SHDSL performance.

  • Page 15: Wan Interface Configuration

    1740 SHDSL 2/4-Wire Router User’s Guide WAN Interface Configuration The router supports 16 ATM interfaces. A virtual channel (VC) can be configured for each ATM interface such as ATM1 to VC1, ATM 2 to VC2, and so on. Each VC can be specified with a protocol, which can be RFC 1483 bridged, RFC 1483 Routed, PPPoE, or PPPoA.

  • Page 16: Bridge Mode: Service For One Fixed Ip Address

    1740 SHDSL 2/4-Wire Router User’s Guide 3.2.1 Bridge Mode: Service for One Fixed IP Address To configure one static IP address, you need to set up the VC in RFC 1483 bridged mode. The router has a default Virtual Channel (VC) of 0/33. It can function without other modifications.
  • Page 17 1740 SHDSL 2/4-Wire Router User’s Guide To modify the VC, click a VC from the Current ATM PVC List to display the parameters of the VC. Change its parameters and click on the Modify button. 1740-A2-GB20-00 July 2004...

  • Page 18: Router Mode: Service For Five Static Ip Addresses

    1740 SHDSL 2/4-Wire Router User’s Guide 3.2.2 Router Mode: Service for Five Static IP Addresses To set up the service for five static IP addresses, you need to set up the VC in RFC 1483 Routed mode. STEP 1: Click WAN Setup on the Basic menu bar.
  • Page 19 1740 SHDSL 2/4-Wire Router User’s Guide STEP 4: Click on the Add button. The new VC is added in the Current ATM PVC List on the bottom screen. To modify the VC, click a VC from the Current ATM PVC List to display the parameters of the VC.
  • Page 20 1740 SHDSL 2/4-Wire Router User’s Guide After creating an RFC 1483 Routed VC, click LAN Setup to set up the router’s Ethernet IP address. After changing the IP address, click Apply to display the following screen. The Change & Reboot button allows you to use the new IP address and reboot the router immediately.
  • Page 21 Note: After the IP address is changed, your PC and the Therefore, you cannot use the web browser to configure the router. You must change your PC’s IP address. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide router are on different network segments. July 2004...

  • Page 22: Pppoe

    1740 SHDSL 2/4-Wire Router User’s Guide STEP 4: Click Save & Reboot on the Basic menu bar to save your settings. 3.2.3 PPPoE When a VC is set in the PPPoA, the router will auto-detect the Authentication code (PAP or CHAP). The NAPT and DHCP server functions will be enabled automatically.
  • Page 23 STEP 4: Click on the Add button. The new VC is added in the Current ATM PVC List on the bottom screen. To modify the VC, click a VC from the Current ATM PVC List to display the parameters of the VC. Change its parameters and click on the Modify button. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 24: Pppoa

    1740 SHDSL 2/4-Wire Router User’s Guide 3.2.4 PPPoA When a VC is configured for PPPoA, the router will auto-detect the Authentication code (PAP or CHAP), and the NAPT function will be enabled automatically. STEP 1: Click WAN Setup on the Basic menu bar.
  • Page 25 1740 SHDSL 2/4-Wire Router User’s Guide To modify the VC, click a VC from the Current ATM PVC List to display the parameters of the VC. Change its parameters and click on the Modify button. 1740-A2-GB20-00 July 2004...

  • Page 26: Password Setup

    1740 SHDSL 2/4-Wire Router User’s Guide 3.2.5 Password Setup There are two types of access privileges. A system ADMINISTRATOR is the only person that can configure, change parameters, monitor, and read the performance and status of the system. A USER can only monitor and read the status of the system.

  • Page 27: Setting The Bridge

    1740 SHDSL 2/4-Wire Router User’s Guide 3.2.6 Setting the Bridge Click on Bridging on the Advanced menu bar to set up the static bridging and Spanning Tree Protocol (STP) functions. Spanning Tree Protocol The STP function is disabled by factory default. To enable it, click Enable in the Spanning Tree field and configure the interfaces on the screen.

  • Page 28: Static Bridging

    1740 SHDSL 2/4-Wire Router User’s Guide Static Bridging Click on the Static tab to configure, modify, and delete the static bridging functions. Add a static bridging entry Delete Delete a static bridging static entry Displays all the static bridging entries...

  • Page 29: Write System Configurations

    1740 SHDSL 2/4-Wire Router User’s Guide 3.4.1 Write System Configurations The new parameters can function immediately without being saved to the flash memory. To use these parameters after you restart the router, you must save them to the flash memory.

  • Page 30: Load Factory Default Values

    1740 SHDSL 2/4-Wire Router User’s Guide 3.4.2 Load Factory Default Values Caution! If you reset your device to the factory defaults, any changes to parameters will be lost and all parameters will revert to their default values. To retrieve the factory default settings: STEP 1: Click Erase &...

  • Page 31: Chapter 4 Setting Up Wan And Lan Interfaces

    IP address, but you need to save the new setting before you reset the router. After the IP address is changed, to be able to use the Web browser or Telnet, make sure your PC’s IP address is set to the same network segment. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 32: Configuring The Wan Interface

    1740 SHDSL 2/4-Wire Router User’s Guide Configuring the WAN Interface Click WAN Setup on the Basic menu bar and configure the VC to RFC 1483 Bridged, RFC 1483 Routed, PPPoE, or PPPoA. To set up these services, refer to Section 3.2.

  • Page 33: Vc Data Flow Control

    1740 SHDSL 2/4-Wire Router User’s Guide 4.2.1 VC Data Flow Control To set up the flow control parameters, such as AAL5 encapsulation, QOS, Peak Cell Rate, Sustainable Cell Rate, and Burst Tolerance, follow the steps below. Click WAN Configure on the Advanced menu bar, and click on the VCC tab on the main menu.

  • Page 34: Setting Up An Isp

    1740 SHDSL 2/4-Wire Router User’s Guide 4.2.2 Setting up an ISP The router supports connection to up to 16 ISPs. Each ATM Interface can connect to an ISP.To set up or configure the connection parameters to ISP, click on WAN Configure on the Advanced menu bar. Click on the ISP tab on the main screen.

  • Page 35: Chapter 5 Snmp

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 5 SNMP The default setting of the SNMP function is enabled. SNMP is a software entity that responds to information and action request messages sent by a network management station. The messages exchanged enable you to access and manage objects in an active or inactive (stored) MIB on a particular router.

  • Page 36: Disable Snmp

    1740 SHDSL 2/4-Wire Router User’s Guide Disable SNMP Click SNMP on the Advanced menu bar and click on the Modify button at the bottom of the screen. Choose Disable in the SNMP Service field and click on Apply to submit the setting.

  • Page 37: Chapter 6 Packet Filter

    Select from TCP/UDP/ICMP/IP. Source IP Source IP of a packet you wish to filter. Source Mask Source Mask of a packet. Source Port Source Port of a packet you wish to filter. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 38: Delete A Packet Filter Entry

    1740 SHDSL 2/4-Wire Router User’s Guide Destination IP Destination IP of a packet you wish to filter. Destination Mask Destination Mask of a packet. Destination Port Destination Port of a packet you wish to filter. TCP Flag This field allows you to filter according to a TCP flag.

  • Page 39: Chapter 7 Routing

    STEP 1: Select the entry you wish to modify from the List of Static Routes STEP 2: Change the parameters STEP 3: Click on the Modify button 1740-A2-GB20-00 Next Hop IP 10.0.0.2 July 2004 1740 SHDSL 2/4-Wire Router User’s Guide...

  • Page 40: Set Up The Rip Function

    1740 SHDSL 2/4-Wire Router User’s Guide Delete: STEP 1: Select the entry you wish to delete from the List of Static Routes STEP 2: Change the parameters STEP 3: Click on the Delete button Set Up the RIP function To enable the RIP, complete the following steps: STEP 1: Click Routing Setup from the Basic menu bar STEP 2: Select On in the Rip Status field.
  • Page 41 The RIP function is now enabled. The default RIP parameter for each interface is RIPv2. In this default mode, this router can operate normally without other adjustments. If you want to configure advanced RIP functions, perform the procedures that follow. Enter BASIC/ROUTING/RIP/INTERFACE/LAN to configure the parameters. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 42: Displaying The Routing Table

    1740 SHDSL 2/4-Wire Router User’s Guide Displaying the Routing Table To display the routing table, you can enter either of the following screens: BASIC/ROUTING SETUP/ROUTING TABLE screen Advance/Utilities/Routing Table The following routing table appears after clicking Basic>Routing Setup>Routing Table. July 2004...

  • Page 43: Chapter 8 Nat

    NAT, you must select the Enable NAPT item on the WAN Setup screen. The following pages describe how to set up a virtual server (Redirect port) and different types of NAT. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 44: Multiple To One

    1740 SHDSL 2/4-Wire Router User’s Guide Multiple to One This application requires a series of private IP addresses (such as 192.168.1.140- 192.168.1.150). These private IP address share a public IP address, such as 10.1.1.1. STEP 1: Click on NAPT on the Advanced menu bar.

  • Page 45: One To One Nat

    1740 SHDSL 2/4-Wire Router User’s Guide One to One NAT One-to-one NAT maps a private IP address to a public IP address, such as 192.168.1.10 to 10.1.1.34. Click NAPT on the Advanced menu bar and click on the NAT/PAT tab to access the NAT/PAT Configuration screen.

  • Page 46: Multi-Nat

    1740 SHDSL 2/4-Wire Router User’s Guide Multi-NAT Multi-NAT maps a set of continuous private IP addresses to a set of continuous public IP addresses. There are two ways Multi-NAT can be used to translate the private IP addresses to public IP addresses.
  • Page 47 End Private IP Address: For example, 192.168.1.22 Start Global IP Address: For example, 10.1.1.3 End Global IP Address: For example, 10.1.1.10 STEP 2: Select Overload and click on the Add button. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 48: Virtual Server

    1740 SHDSL 2/4-Wire Router User’s Guide Virtual Server If you want to set up Internet servers (such as an e-mail server, web server, or FTP server) on the virtual LAN when PAT is enabled, you should register the servers with the router first to allow Internet users to access the service via the WAN interface of router.

  • Page 49: Chapter 9 Dhcp

    To configure the router as a DHCP server, click on DHCP on the Advanced menu bar. Click Enable in the DHCP Server field, and fill out the parameters. Click Apply to submit the settings. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...

  • Page 50: Dhcp Relay

    1740 SHDSL 2/4-Wire Router User’s Guide DHCP Relay Click on DHCP on the Advanced menu bar. On the main screen, click on the BOOTP/DHCP Relay tab and configure the following parameters: BOOTP/DHCP Relay: Enable IP Address: This defines the IP address of the remote DHCP server.

  • Page 51: Chapter 10 Dns Proxy

    Enabled/ Disabled (factory default: disabled) Enter the primary server IP address Enter the secondary server IP address that will be used immediately when the primary server IP address fails or is not available July 2004 1740 SHDSL 2/4-Wire Router User’s Guide...

  • Page 52: Chapter 11 Igmp

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 11 IGMP IGMP (Internet Group Membership Protocol) is a protocol used by IP hosts to report their multicast group memberships to any immediately neighboring multicast routers. STEP 1: Add a VC and set it to RFC 1483 Routed mode.
  • Page 53 1740 SHDSL 2/4-Wire Router User’s Guide STEP 4: Click Apply to submit the settings. 1740-A2-GB20-00 July 2004...

  • Page 54: Chapter 12 Vlan

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 12 VLAN To configure the VLAN function, click on VLAN in the Advanced menu bar. VLAN is disabled by factory default. To enable it, select Enable and click on the Set button. Then you can proceed to create the VLAN groups.

  • Page 55: Chapter 13 Maintenance And Diagnostics

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 13 Maintenance and Diagnostics This chapter describes how to perform a software upgrade, configuration backup, or configuration restoration, and how to use the diagnostic functions of the router. 13.1 Software Upgrade and Configuration Backup /Restoration The router supports TFTP upgrade via the console, Telnet, and Web browser.
  • Page 56 1740 SHDSL 2/4-Wire Router User’s Guide If a wrong format of the file us uploaded, a failure message will display during the upgrade. The following is an example of upgrade failure resulting from an incorrect file format. Before performing the TFTP upgrade, run the TFTP software. Click on Utilities on the Advanced menu bar.
  • Page 57 1740 SHDSL 2/4-Wire Router User’s Guide The following is an example of how to set up the parameters for homepage upgrade. To upload the configurations, check Upload, select Configuration, and click on the Apply button to submit the settings. 1740-A2-GB20-00...

  • Page 58: Oam Loopback

    1740 SHDSL 2/4-Wire Router User’s Guide 13.2 OAM Loopback Click on Utilities on the Advanced menu bar, and click on the Loopback tab on the main screen. After filling out the following parameters, click Start Loopback to perform the loopback.

  • Page 59: Ping

    1740 SHDSL 2/4-Wire Router User’s Guide 13.3 Ping A Ping test is used to verify the status of a network connection after the RIP or static route function is enabled. Ping sends a request message to the host and waits for a return message. This diagnostic function can verify if the remote host is reachable.

  • Page 60: Performance Monitoring

    1740 SHDSL 2/4-Wire Router User’s Guide 13.4 Performance Monitoring System statistics Click System Statistics on the Advanced menu bar to monitor the interface status and collect the statistics of the TCP/IP. July 2004 1740-A2-GB20-00...
  • Page 61 The number of Octets (bytes) transmitted OutUcastPkts The number of unicast packets transmitted Broadcast PktsOut The number of broadcast packets transmitted OutDiscards The number of packets transmitted that were discarded OutErrors The number of outward errors 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 62 1740 SHDSL 2/4-Wire Router User’s Guide To view TCP-IP statistics click on the TCP-IP tab at the top of the System Statistics page. The TCP-IP page displays the IP statistics, UDP statistics, TCP statistics, and ICMP statistics. Interface Click Interface Monitor on the Advanced menu bar to monitor the transmission status.

  • Page 63: Chapter 14 Application Example

    Location B: 10.164.32.10; Netmask: 255.255.255.252 Network of the School: 210.240.117.0; Netmask: 255.255.255.128 In the above example, you would add the following static route to the router. 210.240.117.0; Netmask: 255.255.255.128; Next hop: 10.164.32.9 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 64 1740 SHDSL 2/4-Wire Router User’s Guide Enter the parameters of the static route and click on the Add button. Click LAN Setup on the Basic men bar. After typing LAN IP 10.164.32.10 and Netmask 255.255.255.252, click on Apply to submit the settings.

  • Page 65: Chapter 15 Pin Assignments

    LAN Port (RJ45) Pin number Definition LINE Port (RJ45) Pin number Definition Loop2-1 Loop2-2 Short with 1 Loop1-1 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide Pin number Definition Pin number Definition Pin number Definition Loop1-2 Short with 2 July 2004...

  • Page 66: Chapter 16 Console Access

    1740 SHDSL 2/4-Wire Router User’s Guide CHAPTER 16 Console Access To access the device via the console port the following are required: VT100 Compatible Terminal This terminal is essential to perform the initial configuration of the router. This is normally a terminal with a VT100 emulation program, such as Telix or HyperTerminal Edition 5.

  • Page 67: Keyboard Operations

    Moves the cursor downward [equal to the down arrow key] Return to the previous screen [equal to the left arrow key] Enter the selected item [equal to the right arrow key] 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 68 1740 SHDSL 2/4-Wire Router User’s Guide The backup keys displayed at the bottom of the screen. In addition to the arrow keys to move the cursor in the menu, you can enter the requested screen by entering the number. For example, to enter MAIN/ADVANCE/DHCP/RELAY, follow the steps below: STEP 1: Press the 2 key, to enter the Advance menu, and then press the Enter key。...

  • Page 69: Motoring The Shdsl Line Status

    1740 SHDSL 2/4-Wire Router User’s Guide STEP 3: Press the 2 key, and then press the Enter key in MAIN/ADVANCE/DHCP. STEP 4: Now you have reached MAIN/ADVANCE/DHCP/RELAY. 16.1.3 Motoring the SHDSL Line Status Enter MAIN/BASIC/SHDSL to monitor the SHDSL Line status.

  • Page 70: Password Setup

    1740 SHDSL 2/4-Wire Router User’s Guide 16.1.4 Password Setup Enter MAIN/BASIC/SYSTEM to change the passwords. New Administrator Password and Retype Password: Enter the administrator password in the New Administrator Password and confirm the password by retyping the password in the Retype Password field.

  • Page 71: Save The Configurations

    Press the Y key to reboot the device or press the N key to keep operating the device. 16.1.8 Login STEP 1: Configure your workstation to the same network segment as the router, such as IP address 192.168.1.133 and subnet mask 255.255.255.0. 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide July 2004...
  • Page 72 1740 SHDSL 2/4-Wire Router User’s Guide STEP 2: Click [Start]> [run], type telnet 192.168.1.1 and click OK. (192.168.1.1 is the default IP address. If it was changed, use the new IP address to login.) STEP 3: Enter the user name and password and press Enter to login (The default password and user name are root) STEP 4: The following displays the main menu after login.

  • Page 73: Appendix A: Specifications

    Standard Transparent bridge and learning Routing functions IP static route RIP and RIPv2 IGMP Proxy 1740-A2-GB20-00 1740 SHDSL 2/4-Wire Router User’s Guide ITU-T G991.2 RJ45 TC-PAM Per ITU-T G991.2 (SHDSL) N x 64 Kbps, N=1~36, per Channel (2 channels) RFC 2684 (1483)
  • Page 74 1740 SHDSL 2/4-Wire Router User’s Guide Network functions DNS, NAT/PAT, DHCP/BOOTP PAP, CHAP Automatic IP and DNS Assignment Power Supply External power adapter Frequency Environmental Conditions Operating temperature Relative humidity Note: Specifications are subject to change without notice RFC 1877...
