C
Net to Net Technologies strongly recommends the use of proper electrostatic discharge (ESD) precautions when
AUTION
handling this equipment.
1.0 INSTALLATION
1.1 Unpack and Inspect the Equipment
The following components should be included:
1 UIM-1000T
4 #6 Phillips Panhead Nylon Locking Screws
2 #6 Phillips Beige Flathead Screws
If there is visible damage, do not attempt to install the UIM-1000T; contact Customer Support at 1-
877-638-2638 (001-603-427-0600 for international customers) or Support@NetToNet.com.
1.2 Install the UIM-1000T on a Multiplexer Uplink Module (MUM2000-2)
An uplink interface module (UIM) provides the upstream network connection, via a MUM, for Net to
Net Technologies' IP DSLAMs; neither an IP DSLAM nor a MUM can function without a UIM.
N
The MUM2000-2 is currently Net to Net's only multiplexer uplink module capable of supporting the UIM-1000T.
OTE
Select a port on the MUM2000-2 for installation of the UIM-1000T: either port (1 or 2) may be
used. Although not required for operational purposes, if redundancy is desired two UIMs may
be installed on a MUM2000-2, one in each port.
Remove the blanking plate from the selected port.
C
Blanking plates should be stored for possible future use: if a UIM-1000T is removed from the
AUTION
MUM2000-2, it must be replaced with either another UIM or a blanking plate. DO NOT
OPERATE THE MUM2000-2 WITH AN OPEN UIM PORT.
Carefully slide the faceplate of the UIM-1000T under the lip of the MUM2000-2 faceplate at
the selected port opening such that the UIM-1000T circuit board is facedown and the label
shows through the MUM2000-2 port opening with the UIM-1000T model name along the right-
hand edge.
220-0000078 rev 01
UIM-1000T
Gigabit Ethernet Uplink Interface Module
Installation Instructions
