9109 OCU-DP Application Module (APM)
Installation Instructions
Document Number 9109-A2-GN15-10
May 1999
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following document:
9191-A2-GH30
NextEDGE Multiservices Access System Technical Reference
To request a paper copy of a Paradyne document:
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
Outside the U.S.A., call 1-727-530-8623
Before You Begin
Make sure you have:
The housing, and any associated hardware already installed
A T1 NAM already installed in Slot 01 and connected to the network
Applicable cables
A small Phillips screwdriver (#1 or #2) to install the APM
A small, flat-blade screwdriver to install the I/O card and cable connections
See the Technical Reference for additional information on:
Troubleshooting
Technical Specifications
Cables, Connectors, and Pin Assignments
TM
Technical Manuals
NextEDGE Multiservices Access System .
1
Advertisement
Table of Contents
Related Manuals for Paradyne Application Module 9109 OCU-DP
Summary of Contents for Paradyne Application Module 9109 OCU-DP
-
Page 1: Before You Begin
We provide complete product documentation online. This lets you search the documentation for specific topics and print only what you need, reducing the waste of surplus printing. It also helps us maintain competitive prices for our products. Complete documentation for this product is available at www.paradyne.com. Select Library Technical Manuals... -
Page 2: Package Checklist
Package Checklist Verify that your package contains the following: OCU-DP APM OCU-DP I/O card When your equipment arrives, inspect it for physical damage and tighten any screws that may have worked loose. Contact your sales representative immediately if there are any signs of shipping damage or if anything is missing from your package. -
Page 3: Installing The I/O Card
Installing the I/O Card The I/O card provides the APM with DDS connections. The I/O card inserts directly behind the APM that it supports. Slot numbers are identical to facilitate correct installation. NOTE: For the 2-port OCU-DP APM, only Port 1 and Port 2 on the I/O card are functional. 1. - Page 4 Connecting to the DDS Interface 1. Insert the RJ48S DDS network cable into the 4-wire DDS port. The 2-port version provides two RJ48S, 8-position modular keyed jacks, while the 6-port version provides six. 2. Insert the other end of the cable into the DSU/CSU.
- Page 5 Removing the Housing’s Bezel 1. Depress the latch at the top of the housing to open the bezel. 2. Lift upward to remove the bezel from the two slots at the bottom of the housing. Save the bezel so it can be reattached once the APM has been installed. NOTE: The power supply is visible once the bezel is removed.
- Page 6 Installing the APM The APM can be installed in any slot except Slot 01. CAUTION: You must insert the OCU-DP APM in the correct slot so that it mates with its matching I/O card. APMs are keyed so that they mate only with their matching I/O cards.
- Page 7 Removing/Replacing a Card Card removal procedures differ, depending on whether you are removing the APM or I/O card. NOTE: You can insert or remove the APM and its associated I/O card without powering off the equipment and interrupting data flow through other cards in the network. Removing/Replacing an APM 1.
-
Page 8: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@eng.paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
