ParaBody 883 User Manual

ParaBody 883 User Manual

Second stack option for 880 gym system
Hide thumbs Also See for 883:

Advertisement

Quick Links

Download this manual
883 SECOND STACK OPTION
FOR 880 GYM SYSTEM
CLASS H
PART # 7168901
REV. C
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 883102
Revision: 3/08/02

Advertisement

loading
Need help?

Need help?

Do you have a question about the 883 and is the answer not in the manual?

Questions and answers

Related Manuals for ParaBody 883

Summary of Contents for ParaBody 883

  • Page 1 883 SECOND STACK OPTION FOR 880 GYM SYSTEM USER’S GUIDE CLASS H PART # 7168901 REV. C WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 883102 Revision: 3/08/02...

  • Page 2: Important Safety Information

    7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use.

  • Page 3: Important Notes

    Please note: * Thank you for purchasing the ParaBody 880 Second Stack Option. Please read these instructions thoroughly and keep them for future reference. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.

  • Page 4: Parts List

    PART # DESCRIPTION 7160208 STACK BASE 7167908 LEFT BOOM BRACKET 6523401 GUIDE ROD 7095701 WEIGHT STACK SHAFT 7012102 WEIGHT STACK SPACER 6957302 HEAD PLATE 7165701 PRESS STACK CABLE 7156101 LEG CABLE 3116201 3-1/2” PULLEY 6972201 WEIGHT STACK PIN 3108002 WEIGHT STACK CUSHION 6978101 WEIGHT STACK LABEL •...
  • Page 5 PRESS/LEG CABLE FIGURE 1 STEP 1: • NOTE: Follow these steps if assembling the SECOND STACK OPTION to a completely assembled (including cables) 880 GYM SYSTEM without LEG PRESS OPTION, otherwise please refer to PAGE 4. • REMOVE the PRESS/LEG CABLE from the 880 GYM SYSTEM . Discard the PRESS/LEG CABLE . See FIGURE 1. (NOTE: Remove pulleys for ease of removal.)

  • Page 6: Rear Upright

    FIGURE 2 STEP 2: • Remove the two 3/8 X 4” BOLTS, four 3/8” WASHERS and two 3/8” LOCK NUTS from the REAR UPRIGHT as shown in FIGURE 2. FIGURE 3 STEP 3: • SECURELY assemble the STACK BASE (1) to the BASE FRAME using two 3/8 X 4-1/4” BOLTS (16), two previously removed 3/8 X 4”...
  • Page 7 FIGURE 4 STEP 4: • Insert two WEIGHT PLATE BUSHINGS (21) into each of the fifteen WEIGHT PLATES (20) as shown in FIGURE 4. FIGURE 5 STEP 5: • Slide the WEIGHT PLATE SHAFT (4) thru the hole in the HEAD PLATE (6), and lock in place using one E-RING (22) as shown in FIGURE 5.
  • Page 8 STEP 6: • Insert two GUIDE RODS (3) into the STACK BASE (1) as shown on FIGURE 6. (NOTE: If the 880 SHROUD OPTION was purchased, place the GUIDE RODS (3) through the BOTTOM SHROUD BRACKET (found in SHROUD OPTION box) and into the STACK BASE (1) as shown in FIGURE 6.
  • Page 9 FIGURE 7 BOOM PLATE 3”NYLON SPACER REAR UPRIGHT STEP 7: • CAREFULLY remove the BOOM PLATE from the the REAR UPRIGHT and the FRAME as shown in FIGURE 7. Discard the BOOM PLATE. FIGURE 8 2”NYLON SPACER STEP 8: • Swing the GUIDE RODS (3) into the guide rod bushings in the LEFT BOOM BRACKET (2) as shown in FIGURE 8. •...
  • Page 10 PULLEY BOOM BRACKET WEIGHT STACK CABLE FIGURE 9 STEP 9: • Unscrew the threaded ends of the WEIGHT STACK CABLE from the WEIGHT STACK SHAFT and remove the two PULLEYS from the BOOM BRACKET. See FIGURE 9.
  • Page 11 FIGURE 10 STEP 10: • Assemble two 3-1/2” PULLEYS (9) to the LEFT BOOM BRACKET (2) using two 3/8 X 1-3/4” BOLTS (13) and two 3/8” LOW HEIGHT LOCK NUTS (14) as shown in FIGURE 10. • Route the WEIGHT STACK CABLE around the pulleys in the LEFT BOOM BRACKET (2) as shown in FIGURE 10. (NOTE: Make sure the cable runs in the grooves of the pulleys.) •...
  • Page 12 FIGURE 11 STEP 10: • Route the new PRESS STACK CABLE (7) thru the PRESS STATION as shown. (NOTE: Remove pulleys for ease of installa- tion.)
  • Page 13 FIGURE 12 STEP 12: • Route the new PRESS STACK CABLE (7) thru the PEC STATION as shown. (NOTE: Remove pulleys for ease of installation.) Slide GUIDE RODS up just enough to get the cable end thru. Push GUIDE RODS down when finished. STEP 13: •...
  • Page 14 PEDESTAL FIGURE 14 STEP 14: • Assemble the LEG CABLE (8) to the PEDESTAL and route the LEG CABLE (8) thru the BASE FRAME as shown in FIGURE 14. (NOTE: Remove pulleys for ease of installation.) • Route the LEG CABLE (8) around the 3-1/2” PULLEY on the PULLEY PLATES using one existing 3/8 X 1-3/4” BOLT and one existing 3/8”...
  • Page 15 • This completes the assembly of the 880 SECOND STACK OPTION. If the 880 SHROUD OPTION was purchased refer to the 880 SHROUD KIT assembly instructions. Thank you for purchasing the ParaBody 880 Gym System. If unsure of proper use of equipment, call your local ParaBody distributor or call the ParaBody customer service department at (800) 328-9714...
  • Page 16 PRESS/LEG CABLE FIGURE 1 STEP 1: • NOTE: Follow these steps if assembling the SECOND STACK OPTION to a completely assembled (including cables) 880 GYM SYSTEM with LEG PRESS OPTION (already assembled to the 880), otherwise please refer to PAGE 5. •...
  • Page 17 FIGURE 2 SHORT LEG PRESS CABLE THREADED HOUSING STEP 2: • Carefully remove and discard the SHORT LEG PRESS CABLE from the LEG PRESS as shown in FIGURE 2. FIGURE 3 3/8 X 4-1/4” BOLTS 3/8 X 3-3/4” BOLTS REAR UPRIGHT PULLEY BRACKET STEP 3:...
  • Page 18 FIGURE 4 3/8 X 4-1/4” BOLTS BASE FRAME 3/8 X 4” 15 STEP 4: • SECURELY assemble the STACK BASE (1) to the BASE FRAME using two 3/8 X 4” BOLTS (15), two previously removed 3/8 X 4-1/4” BOLTS, eight previously removed 3/8” WASHERS and four previously removed 3/8” LOCK NUTS as shown in FIGURE 4. FIGURE 5 SHORT LEG PRESS CABLE...
  • Page 19 BOOM BRACKET SHORT LEG PRESS CABLE FRAME FIGURE 6 STEP 6: • Remove the rest of the SHORT LEG PRESS CABLE from the FRAME as shown in FIGURE 6. (NOTE: Remove pulleys for ease of installation.)
  • Page 20 PULLEY BRACKET 3/8 X 3” FRAME STEP 7: • Remove the PULLEY BRACKET, the PEC STATION PAD and two 3/8 X 3” BOLTS from the FRAME. Discard the PULLEY BRACKET. See FIGURE 7. 3/8 X 3” FRAME STEP 8: • SECURELY assemble the PEC STATION PAD to the FRAME using two previously removed 3/8 X 3”...
  • Page 21 FIGURE 9 STEP 9: • Insert two WEIGHT PLATE BUSHINGS (21) into each of the fifteen WEIGHT PLATES (20) as shown in FIGURE 9. FIGURE 10 STEP 10: • Slide the WEIGHT PLATE SHAFT (4) thru the hole in the HEAD PLATE (6), and lock in place using one E-RING (22) as shown in FIGURE 10.
  • Page 22 STEP 11: • Insert two GUIDE RODS (3) into the STACK BASE (1) as shown on FIGURE 11. (NOTE: If the 880 SHROUD OPTION was purchased, place the GUIDE RODS (3) through the BOTTOM SHROUD BRACKET (found in SHROUD OPTION box) and into the STACK BASE (1) as shown in FIGURE 11.
  • Page 23 FIGURE 12 BOOM PLATE 3”NYLON SPACER REAR UPRIGHT STEP 12: • CAREFULLY remove the BOOM PLATE (10) from the the REAR UPRIGHT and the FRAME as shown in FIGURE 12. Discard the BOOM PLATE. FIGURE 13 2”NYLON SPACER STEP 13: •...
  • Page 24 PULLEY BOOM BRACKET WEIGHT STACK CABLE FIGURE 14 STEP 14: • Unscrew the threaded ends of the WEIGHT STACK CABLE from the WEIGHT STACK SHAFT and remove the two PULLEYS from the BOOM BRACKET. See FIGURE 14.
  • Page 25 FIGURE 15 STEP 15: • Assemble two 3-1/2” PULLEYS (9) to the LEFT BOOM BRACKET (2) using two 3/8 X 1-3/4” BOLTS (13) and two 3/8” LOW HEIGHT LOCK NUTS (14) as shown in FIGURE 15. • Route the WEIGHT STACK CABLE around the pulleys in the LEFT BOOM BRACKET (2) as shown in FIGURE 15. (NOTE: Make sure the cable runs in the grooves of the pulleys.) •...

  • Page 26: Lat Cable

    FIGURE 16 STEP 16: • Route the previously removed original LAT CABLE through the FRAME (1) and assemble one 3-1/2” PULLEY to the PULLEY PLATES using one existing 3/8 X 1-3/4” BOLT and one exsisting 3/8” LOCK NUT. See FIGURE 16. FIGURE 17 STEP 17: •...
  • Page 27 FIGURE 18 STEP 18: • Route the new PRESS STACK CABLE (7) thru the PRESS STATION as shown. (NOTE: Remove pulleys for ease of installa- tion.)
  • Page 28 FIGURE 19 STEP 19: • Route the new PRESS STACK CABLE (7) thru the REAR UPRIGHT as shown. (NOTE: Remove pulleys for ease of installa- tion.) Slide GUIDE RODS up just enough to get the cable end thru. Push GUIDE RODS down when finished. STEP 20: •...
  • Page 29 STEP 21: • Assemble the LONG LEG PRESS CABLE (from the 883 LEG PRESS OPTION box) to the PEDESTAL and route the LONG LEG PRESS CABLE thru the BASE FRAME as shown in FIGURE 21. (NOTE: Remove pulleys for ease of installation.) •...

  • Page 30: Cable Routing Diagram

    FIGURE 22 LONG LEG PRESS CABLE THREADED HOUSING STEP 22: • Carefully route the LONG LEG PRESS CABLE thru the LEG PRESS as shown in FIGURE 22 and assemble the LONG LEG PRESS CABLE to the existing THREADED HOUSING. CABLE ROUTING DIAGRAM...
  • Page 31 • This completes the assembly of the 880 SECOND STACK OPTION. If the 880 SHROUD OPTION was purchased refer to the 880 SHROUD KIT assembly instructions. Thank you for purchasing the ParaBody 880 Gym System. If unsure of proper use of equipment, call your local ParaBody distributor or call the ParaBody customer service department at (800) 328-9714...
