- Page 1 WEIGHT STACK OPTION PRODUCT ASSEMBLY INSTRUCTIONS SHEETS RF.’~’ISION...
- Page 2 868 WEIGHT STACK OPTION ASSEMBLY PARTS LIST SORT AND COUNT ALL PARTS BEFORE BEGINNING ASSEMBLY HARDWARE: ITEM NAME/DESCRIPTION 3/8 X 3-I/2 IN. BOLT 3/8 X 2-3/4 IN. BOLT 3/8 X I-1/2 IN. BOLT 3/8 IN WASHER 3/8 IN. LOCK WASHER 3/8 IN.
- Page 3 WEI.GHT STACK OPTION ASSEMBLY INSTRUCTIONS TO PREPARE THE 866 STRENGTH BUILDING SYSTEM TO ACCEPT 868 WEIGHT SZ~CK OPTION PLEASE USE THE FOLLOWING STEPS: Detach the HIGH PULLEY CABLE from the CARRIAGE WELDMENT and remove the CABLE from the machine. (THE BOLT IN FRONT OF THE HIGH PULLEY WILL NEED TO BE...
- Page 4 868 WEIGHT STACK OPTION ASSEMBLY INSTRUCTIONS SECURELY assemble one (I) 4-1/2 X 3/8 X 1 IN. PULLEY, and two (2) 3/8 IN. SPACERSIo the SUPPORT WELDMENT as shown on drawing using one (1) 3/8 X 2-3/4 IN. BOLT, two (2~)3/8 WASHERS, and one (1) 3/8 IN.
- Page 5 .WEIGHT STACK OPTION ASSEMBLY INSTRUCTIONS To assemble the WEIGHT STACK CABLE, follow the cable routing diagram on drawing, and use the following steps: Route the threaded end of the WEIGHT STACK CABLE over the HIGH PULLEY between the PULLEY MOUNT FLATS. Then reassemble the one (1) 3/8 X 3-1/4 IN. BOLT and REL?~TED HARDWARE to the hole in front of the HIGH PULLEY (IF NECESSARY).
- Page 6 01 AS SHOWN pULLEY MOUNT FLATS (2~--~ UPRIGHT EXTENSION UPRIGHT FRAME EXISTING 3/8 IN LOCK NUT (2)~ 3/8 IN WASHER (2) 3/8 X 2-3/4 BASE WEIGHT STACK LABELS WEIGHT PLATES (20)- WEIGHT STACK CUSHION (2)- BASE WELDMENT EXISTING 3/...
- Page 7 -4--1/2 X 3/8 X 1 IN PULLEY 5/8 X .3/8 X 3/8 1N SPACER (2) 2 IN SQ END CAP (.3) ~.~-TOP SUPPORT WELDMENT ... EXISTING ,3/8 IN WASHER (4-) EXISTING 3/8 IN LOCK NUT (2) HEAD PLATE IN WASHER IN LOCKWASHER .3/8 X 1-1/2 IN BOLT...
