ParaBody 822 User Manual

Adjustable sit-up bench
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
822 ADJUSTABLE SIT-UP BENCH
CLASS H
PART # 7303801
REV. A
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 822108
Revision: 06/18/02

Advertisement

loading

Related Manuals for ParaBody 822

Summary of Contents for ParaBody 822

  • Page 1 822 ADJUSTABLE SIT-UP BENCH USER’S GUIDE CLASS H PART # 7303801 REV. A WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 822108 Revision: 06/18/02...
  • Page 2 7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use.

  • Page 3: Tools Required For Assembly

    Please note: * Thank you for purchasing the ParaBody 822 Adjustable Sit-up Bench. Please read these instructions thoroughly and keep them for future reference. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.

  • Page 4: Parts List

    PART # DESCRIPTION 6522110 FRONT BASE SUPPORT 6666410 6522409 MAIN PAD SUPPORT 6522609 6666521 PAD ASSEMBLY 6125101 3/4 X 16” TUBE 6194601 ROLLER PAD 3114403 3/8” WASHER 3114502 3/8” LOCK WASHER 3/8 X 3” 12 FIGURE 1 STEP 1: • Insert two 2” SQ. END CAPS (16) into the ends of the TUBE (2) as shown in FIGURE 1. •...
  • Page 5 FIGURE 2 STEP 2: • Insert two 2” SQ. END CAPS (16) into the ends of the BASE (4) as shown in FIGURE 2. • SECURELY assemble the PAD (5) to the MAIN PAD SUPPORT (3) and BASE (4) using two 3/8” X 2-3/4” BOLTS (11), two 3/8”...
  • Page 6 FIGURE 4 STEP 4: • Slide the four ROLLER PADS (7) onto the MAIN PAD SUPPORT (3) using two 3/4 X 16” TUBES (6), and four STARLOCK COLLARS (13) as shown in FIGURE 4. FIGURE 5 STEP 5: • Pull back the SPRING PIN and CAREFULLY slide the MAIN PAD SUPPORT (3) over the FRONT BASE SUPPORT (1) as shown in FIGURE 5.
  • Page 7 Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your ParaBody customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.

  • Page 8: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 9 LifeFitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LifeFitness www.parabody.com LifeFitness (UK) Ltd. Queen Adelaide Ely, Cambs CB7 4UB United Kingdom Phone CSS: (01353) 665507 Fax CSS: (01353) 666719 LifeFitness Benelux N.V.
