781 SWIVEL CABLE KIT
CLASS H
PART # 7123201
REV. A
USER'S GUIDE
1
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 781101
Revision: 05/23/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 781 and is the answer not in the manual?

Questions and answers

Related Manuals for ParaBody 781

Summary of Contents for ParaBody 781

  • Page 1 781 SWIVEL CABLE KIT USER’S GUIDE CLASS H PART # 7123201 REV. A WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 781101 Revision: 05/23/01...

  • Page 2: Parts List

    PART # DESCRIPTION 7118508 GUIDE BRACKET 7122101 CABLE WEIGHT STACK CABLE 3/8 X 1-3/4” BOLT FIGURE 1 STEP 1: • Remove PULLEY and PULLEY BRACKET from the 777 GYM SYSTEM. Discard the PULLEY BRACKET. See FIGURE 1. PARTS LIST PULLEY BRACKET 3/8”...
  • Page 3 FIGURE 2 3/8 X 3-3/4” BOLT 3/8” LOCK NUT 3/8 X 3-3/4” BOLT 3/8” LOCK NUT STEP 2: • Remove one 3/8” LOCK NUT and one 3/8 X 3-3/4” BOLT from the TOP and BOTTOM PLATES as shown in FIGURE 2. Discard the 3/8 X 3-3/4”...
  • Page 4 FIGURE 3 3/8 X 4-1/4” 4 SHORT CABLE STEP 3: • Assemble the CABLES (2) to the TOP PLATES using one 3/8 X 4-1/4” BOLT (4), two 3/8” SAE WASHERS (3) and one previ- ously removed 3/8” LOCK NUT as shown in STEP 3. •...
  • Page 5 STEP 4: • CAREFULLY slide the GUIDE BRACKET (1) through the CABLES (2) as shown in FIGURE 4. • Assemble the SHORT CABLE and the turnbuckle to each CABLE (2) as shown in FIGURE 4. SHORT CABLE FIGURE 4...
  • Page 6 WEIGHT STACK CABLE 3/8 X 1-3/4” BOLT FIGURE 5 STEP 5: • Slide the GUIDE BRACKET (1) up and reattach the WEIGHT STACK CABLE as shown in FIGURE 5. • Loop the ARM CABLE around the previously removed pulley and assemble it to the GUIDE BRACKET (1) with the previously removed hardware as shown in FIGURE 5.
  • Page 7 FIGURE 6 3/8 X 4-1/4” 4 3/8” LOCK STEP 6: • Assemble the CABLES (2) to the BOTTOM PLATES using one 3/8 X 4-1/4” BOLT (4), two 3/8” SAE WASHERS (3) and one previously removed 3/8” LOCK NUT as shown in STEP 6.
  • Page 8 TURN- BUCKLE JAM NUT FIGURE 7 STEP 7: • Adjust the turnbuckle on each CABLE (2) to add tension to the CABLES (2). Secure turnbuckle with the JAM NUTS as shown in FIGURE 7. • Refer to the 777 USER GUIDE to adjust tension in the systems cables and tighten all jam nuts securely.
