ParaBody 777101 User Manual

ParaBody 777101 User Manual

Gym system
Hide thumbs Also See for 777101:

Advertisement

Quick Links

Download this manual
777101 GYM SYSTEM
CLASS H
PART # 7017401
REV. F
USER'S GUIDE
1
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 777101
Revision: 06/11/01

Advertisement

loading
Need help?

Need help?

Do you have a question about the 777101 and is the answer not in the manual?

Questions and answers

Mahendra Defonseka
June 21, 2025

Want to disassemble my para body 777 to move it to my other house do you have any people who can come and dismantle it in Las Vegas?

0

Subscribe to Our Youtube Channel

Related Manuals for ParaBody 777101

Summary of Contents for ParaBody 777101

  • Page 1 777101 GYM SYSTEM USER’S GUIDE CLASS H PART # 7017401 REV. F WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 777101 Revision: 06/11/01...

  • Page 2: Important Safety Information

    7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use.

  • Page 3: Important Notes

    Please note: * Thank you for purchasing the ParaBody 777 Gym System. Please read these instructions thoroughly and keep them for future reference. * This product must be assembled on a flat, level surface to assure its proper function. * Do not securely tighten any frame connections until the entire frame have been assembled unless otherwise specified.
  • Page 4 1’ 2’ 1’ 2’ 3’ 4’ 5’ 6’ 7’ 8’ 9’ 1 Square = 1’ X 1’ Minimum Required Usable Space Length Width Height Dimensions Including Leg Press (optional) Length Width 3’ 4’ 5’ 6’ = 90 inches (229 cm) 7’ 6” = 103 inches (262 cm) 8’...

  • Page 5: Parts List

    PAR T # DESCRIPTION 70077 BASE 70076 UPRIGHT 70058 SEAT ADJUST 70014 RIGHT ARM SUPPORT 70015 LEFT ARM SUPPORT 70017 RIGHT ARM 70019 LEFT ARM 70056 LEG PEDESTAL 70067 PULLEY BRACKET 69408 PULLEY PLATE 69885 BASE PLATE 69954 V-PULLEY PLATE 69957 BOOM PULLEY PLATE 70082...
  • Page 6 57 3/8 X 3-3/4” 3/8 X 3” 67 FIGURE 1 STEP 1: • LOOSELY assemble two BASE PLATES (11) to the BASE (1) and the UPRIGHT (2) using four 3/8 X 3-3/4” BOLTS (57) and four 3/8” LOCK NUTS (63). See FIGURE 1. •...
  • Page 7 FIGURE 2 STEP 2: • Insert two WEIGHT PLATE BUSHINGS (22) into each of the fifteen WEIGHT PLATES (21) as shown in FIGURE 2. FIGURE 3 STEP 3: • Slide the WEIGHT PLATE SHAFT (26) thru the hole in the HEAD PLATE(23), and lock in place using one E-RING (24) as shown in FIGURE 3.
  • Page 8 FIGURE 4 STEP 4: • Insert two GUIDE RODS (18) into the BASE (1) as shown on FIGURE 4. (NOTE: If the 777 SHROUD OPTION was pur- chased, place the GUIDE RODS (18) through the BOTTOM SHROUD BRACKET (71) and into the BASE (1) as shown in FIGURE 4.
  • Page 9 3/8 X 3-3/4” 57 FIGURE 5 STEP 5: • Swing the GUIDE RODS (18) into the guide rod bushings in each of the RIGHT and LEFT UPRIGHT PLATES (14 & 15) as shown in FIGURE 5. • LOOSELY assemble the RIGHT and LEFT UPRIGHT PLATES (14 & 15) to the UPRIGHT (2) using three 3/8 X 3-3/4” BOLTS (57) and three 3/8”...
  • Page 10 3/8 X 4” 60 FIGURE 7 STEP 7: • LOOSELY assemble the RIGHT and LEFT ARMS (6 & 7) to the UPRIGHT (2) and the RIGHT and LEFT ARM SUPPORTS (4 & 5) using two 3/8 X 4” BOLTS (60), four 3/8” FLAT WASHERS (64), and two 3/8” LOW HEIGHT LOCK NUTS (54). See FIGURE 7.
  • Page 11 FIGURE 9 STEP 9: • Securely assemble one SPRING PIN ASSEMBLY (40) and one 3 PRONG KNOB (43) to the FRONT UPRIGHT (2) as shown. • Apply eight PARAGLIDES (42) to the INSIDE of the tube on the UPRIGHT (2) and on the OUTSIDE of the SEAT ADJUST (3) as shown.
  • Page 12 3/8 X 2-3/4” 55 FIGURE 11 STEP 11: • Assemble two V-PULLEY PLATES (12) and two 4-1/2” V-GROOVE PULLEYS (39) to the UPRIGHT (2) using two 3/8 X 2-3/4” BOLTS (55) . See FIGURE 11. 3/8 X 7” 61 FIGURE 12 STEP 12: •...
  • Page 13 3/8 X 3-3/4” 57 FIGURE 13 STEP 13: • Assemble one 3-1/2” PULLEY (37) to the BOOM PLATES (14 & 15) using one 3/8 X 3-3/4” BOLT (57), two 3/8 X 1” SPACERS (51) and one 3/8” LOCK NUT (63). See FIGURE 13. STEP 14: •...
  • Page 14 3/8 X 3-3/4” 57 FIGURE 15 STEP 15: • Assemble one 3-1/2” PULLEY (37) to the BOOM PLATES (14 & 15) using one 3/8 X 3-3/4” BOLT (57), two 3/8 X 1” SPACERS (51) and one 3/8” LOCK NUT (63). See FIGURE 15.(Note: Loop the WEIGHT STACK CABLE around the PULLEY prior to assembling to the BOOM PLATES.) •...
  • Page 15 FIGURE 17 3/8 X 3” 67 3/8 X 3-3/4” 57 STEP 17: • Securely assemble the ball end of the LEG CABLE (30) and one 3-1/2” PULLEY (37) to the LEG PEDESTAL (8) using two 3/8 X 3-3/4” BOLTS (57), two 3/8” X 1-1/16” FLANGE SPACERS (49), two 3/8” WASHERS (64), and two 3/8” LOCKNUTS (63). (NOTE: The LEG CABLE (91) must be routed over the retaining bolt as shown in FIGURE 17.) •...
  • Page 16 STEP 18: • Assemble one 3-1/2” PULLEY (37) to the PULLEY PLATES (10) using one 3/8 X 1- 3/4” BOLT (53) and one 3/8” LOCK NUT (63) as shown in FIGURE 18. (Note: Loop the CABLE around the PULLEY prior to assembling the PULLEY PLATES.) FIGURE 19 3/8 X 3-3/4”...
  • Page 17 3/8 X 2-3/4” 55 STEP 20: • Route the ARM CABLE (31) through the LEFT ARM (7) as shown in FIGURE 20. • Assemble one V-PULLEY (39) to the LEFT ARM SUPPORT (5) using one 3/8 X 2-3/4” BOLT (55) and one 3/8” LOCK NUT (63). See FIGURE 20.
  • Page 18 FIGURE 21 3/8 X 3-3/4” 57 STEP 21: • Assemble two 3-1/2” PULLEYS (37) to the BASE PLATES (11) using two 3/8 X 3-3/4” BOLTS (58), one 3/8 X 1” SPACER (51) and two 3/8” LOCK NUTS (63). See FIGURE 21.(Note: Loop the ARM CABLE (31) around the PULLEYS prior to assem- bling the PULLEYS.
  • Page 19 FIGURE 23 3/8 X 2-3/4” 55 STEP 23: • Route the ARM CABLE (31) through the RIGHT ARM (6) as shown in FIGURE 23. • Assemble one 4-1/2” PULLEY (38) to the RIGHT ARM (6) using one 3/8 X 2-3/4” BOLT (55), two 3/8 X 1/2” SPACERS (50) and one 3/8”...
  • Page 20 TIGHTEN! TIGHTEN! TIGHTEN! TIGHTEN! TIGHTEN! TIGHTEN! FIGURE 24 STEP 24: • SECURELY tighten all loose frame connections as shown in FIGURE 24!
  • Page 21 FIGURE 25 STEP 25: • SECURELY assemble one SEAT PAD (16) to the UPRIGHT (2) using two 3/8 X 2-3/4” BOLTS (55) and two 3/8” WASHERS (64). See FIGURE 25. FIGURE 26 STEP 26: • Assemble two ROLLER PADS (17) to the LEG PEDESTAL (8) using one 3/4 X 17” TUBE (52) and two 3/4” STARLOCK COLLARS (44) as shown in FIGURE 26.
  • Page 22 FIGURE 27 STEP 27: • Assemble two 14-1/2” SEWN HANDLES (19) to the ARM CABLE (31) using two SNAP LINKS (41) as shown in FIGURE 27. • Assemble two 7-1/2” SEWN HANDLES (20) to the BOOM CABLE (32) using two SNAP LINKS (41) as shown in FIGURE 27. •...
  • Page 23 This completes the assembly of the 777 Gym System. If the 777 SHROUD OPTION was purchased proceed to STEP 29. Thank you for purchasing the ParaBody 777101 Gym System. If unsure of proper use of equipment, call your local ParaBody distributor or call the ParaBody customer service department at (800) 328-9714...
  • Page 24 FIGURE 29 74 3/8 X 2-1/2” STEP 29: • SECURELY assemble the TOP SHROUD BRACKET (70) to the RIGHT and LEFT UPRIGHT PLATES (14 & 15) using two 3/8 X 2-1/2” BOLTS (74) and two 3/8” LOCK NUTS (75) as shown in FIGURE 29.
  • Page 25 FIGURE 30 STEP 30: • SECURELY assemble the LEFT SHROUD (68) and RIGHT SHROUD (69) to the TOP (70) and BOTTOM (71) SHROUD BRACKETS using eight 3/8 X 1” BUTTON HEAD BOLTS (72) and eight 3/8” BLACK SAE WASHERS (73) as shown in FIGURE 30.

  • Page 26: Maintenance

    Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your ParaBody customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.

  • Page 27: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 28 Life Fitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 www.parabody.com Life Fitness (UK) Ltd. Queen Adelaide Ely, Cambs CB7 4UB United Kingdom Phone CSS: (01353) 665507 Fax CSS: (01353) 666719 Life Fitness Benelux N.V.
