Parabody leg press adapter kit assembly instructions

Advertisement

441101 440 LEG PRESS ADAPTER KIT

ASSEMBLY INSTRUCTIONS

Part # 7039101
REV. B
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Revision: 07/19/01

Advertisement

Table of Contents
loading

Summary of Contents for ParaBody 441101 440

  • Page 1: Assembly Instructions

    441101 440 LEG PRESS ADAPTER KIT ASSEMBLY INSTRUCTIONS Part # 7039101 REV. B WARNING: Read and follow all directions for each step to insure proper assembly of this product. Revision: 07/19/01...
  • Page 2: Important Notes

    3. Do not allow minors or children to play on or around this equipment. 4. Exercise with care to avoid injury. 5. If unsure of proper use of equipment, call your local Parabody distributor or call the Parabody customer service department at (800) 328-9714.
  • Page 3: Parts List

    3102501 3102802 3102801 3102924 3102904 3102918 7032303 6694401 PARABODY 440 HOME GYM FIGURE 1 STEP 2 • Slide one 2” SQ. END CAP (6) into the BASE CONNECTION (4) as shown in FIGURE 2. FIGURE 3 DESCRIPTION 3/8” WASHER 3/8” LOCKNUT 1/2”...
  • Page 4 FIGURE 4 STEP 4 • Securely fasten the FRONT LEG (1) and the BASE CONNECTION (4) to the 440 HOME GYM using two 1/2 X 3-1/4” BOLTS (15) and two 1/2” LOCKNUTS (12). See FIGURE 4. STEP 5 • Remove one existing 3-1/2” PULLEY and two SPACERS from the ADJUSTMENT TUBE on the 100 LEG PRESS OPTION by unfastening the 3/8 X 4-1/2”...
  • Page 5 STEP 6 • Attach CABLE SWIVEL (3) to the ADJUSTMENT TUBE on the 100 LEG PRESS using the existing previously removed 3/8 X 4-1/2” BOLTS, WASHERS, 2” WHEELS AND NUT. (Note: Securely tighten, then back off 1/4 turn to allow the CABLE SWIVEL &...
  • Page 6: Remove Cable

    FIGURE 8 REMOVE CABLE STEP 8 Remove the existing LAT CABLE using the following steps: • Disconnect LAT BAR from TOP BOOM. • Unscrew the threaded end of CABLE from the HEAD PLATE ASSEMBLY. • Route the LAT CABLE around the PULLEY BLOCK as shown in FIGURE 8. •...
  • Page 7 FIGURE 9 STEP 9 Install the NEW 110-3/4” CABLE ASSY (16) using the following steps: • Route the CABLE (16) through the TOP BOOM as shown in FIGURE 9. The pulleys in TOP BOOM may need to be temporarily removed to perform this step. (Note: Make sure the CABLE is running OVER the BOLTS connecting the FRONT UPRIGHT to the TOP BOOM.
  • Page 8 FIGURE 11 STEP 11 • Attach the hook end of 82-1/2” CABLE (17) to the CABLE SWIVEL (3) with one QUICK DISCONNECT LINK (8). IMPORTANT: Tighten the QUICK DISCONNECT LINK (8) securely. • Route the 82-1/2” CABLE (17) under the WEIGHT STACK as shown in FIGURE 11. IMPORTANT: Tighten QUICK DISCONNECT LINK SECURELY.
  • Page 9 STEP 12 • Screw the threaded end of 82-1/2” CABLE (17) to the PULLEY BRACKET (2) as shown in FIGURE 12. 3/8 X 1-3/4” 13 STEP 13 • Attach one 3-1/2” PULLEY (5) to the FRONT LEG (1) and one 3-1/2” PULLEY (5) to the BASE CONNECTION (4) using two 3/ 8 X 1-3/4”...
  • Page 10 Next, thread the 82-1/2” CABLE (17) into the PULLEY BRACKET (2) until cable is tight , then tighten the jam nut securely. Thank you for purchasing the Parabody 441101 LEG PRESS ADAPTER KIT. If unsure of proper use of equipment, call your local Parabody distributor or call the Parabody customer service department at (800) SPRING PIN ADJUSTMENT 328-9714.
