NMB-MAT DC Axial Fans FBA11J10M Specifications

Dc axial fans

Advertisement

FBA11J10M/14L
11
10
FBA
J
M
Allowable Ambient Temperature Range:
-40°C ~ +40°C (65%RH) (Operating)
-40°C ~ +70°C (65%RH) (Storage)
(non-condensing environment)
11
14
FBA
J
L
Allowable Ambient Temperature Range:
-20°C ~ +40°C (65%RH) (Operating)
-40°C ~ +70°C (65%RH) (Storage)
(non-condensing environment)
inch
Units:
(mm)
ROTATION
.374
9.5 (max.)
inlet
3.54
(90)
4.45
(113)
Housing with solid corner type are available.
MODEL
FBA11J10M
FBA11J14L

Rotation: Clockwise

EMINEBEA.COM
1.49
.177
(38)
4 – (f4.5)
1.02
.394
(26)
(10)
NAME PLATE
outlet
FLOW
1-S
2--
3-+
321
.185
4 – (f4.7)
3.54
(90)
4.13
(106)
OUTLET SIDE
Rated
Operating
Current
Voltage
Voltage
(V)
(V)
(A)
*1
9
7.0 ~ 14.0
102
14
7.0 ~ 14.0
63
Airfl ow Outlet: Air Out Over Struts
11
10
FBA
J
M
Failure Rate: 10%
70,000 Hours (-30°C)
11
14
FBA
J
L
Failure Rate: 10%
70,000 Hours (-10°C)
(Pa)
30
20
Ps
10
0
0.5

Bearing: Hydro Wave Bearing

Input
Rated
Max.
Power
Speed
Air
Flow
(W)
*1
(min
-1
)
*1
CFM
*1
(m
3
/min)
0.92
1920
36.0
1.02
0.88
2100
39.5
1.12
(min -
1
)
2000
FBA11J10M
12V
FBA11J14L
12V
1000
N
3
(m
/min)
1.0
1.5

Air Flow

Max. Static
Noise
Mass
Pressure
*1
in H
O
(Pa)
*1
(dB)
*1
(g)
2
.06
17.0
24.0
180
.08
21.0
25.0
185
*1: Average Values in Free Air
