LSQT0879.book 1 ページ ２００５年２月８日　火曜日　午後５時２８分
Operating Instructions
Video Cassette Recorder
Contents
Before attempting to connect, operate or adjust this product,
please read these instructions completely.
Model No.
NV-MV22GN
Page
2
3
4
4
5
6
7
8
9
10
12
14
16
18
LSQT0879
A

Advertisement

Table of Contents
loading

Related Manuals for Panasonic NV-MV22GN

Summary of Contents for Panasonic NV-MV22GN

  • Page 1: Table Of Contents

    LSQT0879.book 1 ページ ２００５年２月８日　火曜日　午後５時２８分 Operating Instructions Video Cassette Recorder NV-MV22GN Contents Warning and Important Information Controls and Components Connections Tuning the TV to Your VCR Storing TV Broadcasts in Your VCR Setting the Clock of Your VCR Settings Using the On Screen Display...

  • Page 2: Warning And Important Information

    Note: • In any of the above-mentioned conditions, do not operate the VCR for at least 1 hour. This VCR is not equipped with a dew sensor. Press [VCR-ON/OFF] (1) to switch the VCR from ON to standby mode or vice versa. In the standby mode, the VCR is still connected to the mains.

  • Page 3: Controls And Components

    SP SP REMAIN SP SP (42) (45) TV Operation Only Panasonic TVs can be operated with the provided remote control. The settings for operating the TV with the remote control have already been made. No additional settings need to be performed.

  • Page 4: Connections

    (7) RF IN socket (42) LSQT0879 Tuning the TV to Your VCR The VCR supplies a signal to the TV via the RF coaxial cable on channel AU28-69 or NZ21-69. If you have connected the VCR to the TV through the Audio/ Video input sockets, then you do not need to follow the procedure below.

  • Page 5: Storing Tv Broadcasts In Your Vcr

    LSQT0879.book 5 ページ ２００５年１月２６日　水曜日　午後６時１７分 Storing TV Broadcasts in Your VCR The VCR is fitted with its own tuner (just like a normal TV) and can be preset to receive up to 99 TV broadcast stations. Pre-programmed TV Channels (Australia only) The local TV broadcast channels 2, 7, 9, 10 and 28 are factory-preset in this VCR.

  • Page 6: Setting The Clock Of Your Vcr

    3 years. After 3 years, clock back up in the event of a power failure can only be guaranteed for maximum of 1 hour. Preparations • Confirm that the TV is on and the VCR viewing channel is selected. • Turn on the VCR. Operations 1 Press [MENU] (9) to display the Main menu on the TV screen.

  • Page 7: Settings Using The On Screen Display

    LSQT0879.book 7 ページ ２００５年１月２６日　水曜日　午後６時１７分 Settings Using the On Screen Display Preparations • Confirm that the TV is on and the VCR viewing channel is selected. • Turn on the VCR. To Set the Colour TV System 1 Press [MENU] (9) to display the Main menu on the TV screen.

  • Page 8: Option Setting

    • Press [2 1] (28) to select the corresponding video cassette tape length. AUTO: The VCR automatically distinguishes E30, -60, -90, -120, -180 and -240 tapes. E195: For E195 tape E260: For E260 tape E300: For E300 tape •...

  • Page 9: Playback

    LSQT0879.book 9 ページ ２００５年１月２６日　水曜日　午後６時１７分 Playback Preparations • Confirm that the VCR is on. • Confirm that the TV is on and the VCR viewing channel is selected. • Insert a recorded video cassette. For Normal Playback: Press [PLAY] (8). For Cue or Review Playback: During playback, tap [Fast Forward] (27) or [Rewind] (10).

  • Page 10: Recording

    LSQT0879.book 10 ページ ２００５年１月２６日　水曜日　午後６時１７分 Recording Preparations • Confirm that the VCR is on. • Confirm that the TV is on and the VCR viewing channel is selected. Operations 1 Insert a video cassette with an intact erasure prevention tab. • If it has already been inserted, press [VCR-ON/OFF] (1) to turn the VCR on.

  • Page 11: Recording From An External Source

    [STOP] (12) to finish recording. Note: • If you leave the VCR in the recording pause mode for more than 5 minutes in step 3 or 6, the VCR automatically switches over to stop mode to protect the video heads.

  • Page 12: Timer Recording

    Preparations • The VCR must be turned on, or in timer recording standby mode. • Confirm that the TV is on and the VCR viewing channel is selected. • Insert a video cassette with an intact erasure prevention tab. • Check that the clock is set to the correct time. If it has not been set, refer to page 6.

  • Page 13: To Check And Cancel A Timer Programme

    Preparations • The VCR must be turned on, or in timer recording standby mode. • Confirm that the TV is on and the VCR viewing channel is selected. • Insert a video cassette with an intact erasure prevention tab. 1 Press [I-TIMER] (23) to display the menu for Intelligent Timer on the TV screen.

  • Page 14: Search Functions

    • The tape length of the inserted cassette must be set correctly. (See page 8.) • The VCR must not be in the timer recording standby mode. • A programme at least 15 minutes must be recorded on the tape.

  • Page 15: Time Stamp Function

    • When you press [REC] (15) on the remote control during recording. Conditions for correct operation of the Index search function: • The VCR must be in the stop mode or in the playback mode. • Each programme recorded on the tape must be at least 5 minutes long. Preparations •...

  • Page 16: Before Requesting Service

    • The TV has not been tuned to the VCR. #Tune the TV to the VCR. See page 4. • The video heads are clogged or worn. #Consult Panasonic Customer Care Centre for advice on 132600. (For Australia) #Consult your dealer for further advice.

  • Page 17: Adjusting The Playback Picture

    • If you play back a cassette that was recorded on another VCR, the picture quality may be inferior and it may be necessary to adjust the tracking. Also, on some TVs, the picture may shake in the special playback functions.

  • Page 18: Specifications

    LSQT0879.book 18 ページ ２００５年１月２６日　水曜日　午後６時１７分 NV-MV22GN Power Source: Power Consumption: Video Recording System: 2 rotary heads, helical scanning system Video Heads: 2 heads Tape Speed: NTSC SP; 33.3 mm/s Tape Format: VHS tape Record/Playback Time: FF/REW Time: Approx. 60 s with NV-E180 (FF/REW) Approx.
  • Page 19 LSQT0879.book 19 ページ ２００５年１月２６日　水曜日　午後６時１７分 MEMO LSQT0879...
  • Page 20 LSQT0879.book 20 ページ ２００５年２月８日　火曜日　午後５時２８分 LSQT0879 Matsushita Electric Industrial Co., Ltd. F0205Ah0 Web Site: http://www.panasonic.co.jp/global/...
