Phoenix PH603SBN Owner's/Assembly Manual

82,500 btu outdoor gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

For Models:
PH603SB
PH603SBN
82,500 BTU OUTDOOR GAS GRILL
OWNERS / ASSEMBLY MANUAL
!
For Outdoor Use Only
(do not use under any overhead enclosure)
WARNING
!
For Your Safety:
1. Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
2. Read the installation, operation, and maintenance
instructions thoroughly before installing, using or
servicing this appliance.
3. Failure to follow these instructions could result in
fire or explosion, which could cause property damage,
personal injury, or death.
California Proposition 65:
Chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm are
created by the combustion of propane.
Save these instructions for future reference. If you are
assembling this unit for someone else, give this manual to
him or her to read and save for future reference.
Phoenix Innovations Corp.
103-1540 Cornwall Rd. Oakville, ON Canada L6J 7W5
Made in China / Printed in China
L0019 - Rev. 12/06

Table of Contents

Grease Cup/drawer
1
2
3
9
10
10
11
12
12
13
14
14
15
16
17
19
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH603SBN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phoenix PH603SBN

Summary of Contents for Phoenix PH603SBN

  • Page 1: Table Of Contents

    Warranty him or her to read and save for future reference. Phoenix Innovations Corp. 103-1540 Cornwall Rd. Oakville, ON Canada L6J 7W5 Made in China / Printed in China L0019 - Rev. 12/06...

  • Page 2: Warning

    For Models: PH603SB PH603SBN PAGE # 1 OWNERS MANUAL DANGER WARNING For Your Safety: For Your Safety: If you smell gas: 1. Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any 1.

  • Page 3: Parts / Hardware List

    Tool Caddy Bucket Tool Caddy Wire Support Back Panel Wire Shelf (inside bottom cabinet) Tank Support Wire (not required/supplied for Natural Gas model PH603SBN) P-L / P-R Grease Tray Support Bars (2) Horizontal Front Panel Grease Tray PART # DRAWING...

  • Page 4: Assembly Instructions

    For Models: PH603SB PH603SBN PAGE # 3 ASSEMBLY INSTRUCTIONS: STEP 1: Identify parts & hardware 1. Unpack and identify all parts and hardware pack using the parts list and hardware list provided in this manual. 2. If you are missing any parts, PLEASE DO NOT RETURN THIS PRODUCT TO STORE.
  • Page 5 2 medium bolts. (The tank support wire (O) and the tank support wire bracket (L-1) are not required / not supplied for Natural Gas Model PH603SBN). 3. Attach grease tray face (A-1) to the main grease tray (R) with 2 medium bolts. (See Fig. 6) 4.
  • Page 6 1. Note: 2 people are required for this step. 2. Rest BBQ grill head (S) onto cabinet frame. Ensure that the hose and regulator (or natural gas hose assembly for Model PH603SBN) sits inside the cabinet. (See Fig. 7) LIFT Ensure that the holes in the grill head line up with the “L”...
  • Page 7 For Models: PH603SB PH603SBN PAGE # 6 STEP 8: Attach left side shelf NOTE: PLACE ON CARDBOARD OR CLOTH TO PROTECT PAINT/STEEL FINISH. 1. Insert 2 medium bolts through left side shelf top (T) into left side shelf front (U) and tighten. (See Fig. 10) 2.
  • Page 8 For Models: PH603SB PH603SBN PAGE # 7 STEP 10: Attach bottom trim NOTE: PLACE ON CARDBOARD OR CLOTH TO PROTECT PAINT/STEEL FINISH. 1. Assemble right (F), left (E) and front (D) skirt trim pieces using 4 #1 bolts. (See Fig. 13) 2.
  • Page 9 For Models: PH603SB PH603SBN PAGE # 8 STEP 12: Install cooking components 1. Place heat tents (E-1) into slots located in front of grill head (S) and lower over each burner. 2. Insert cooking grids (F-1), warming rack (H-1) and side burner grate (I-1) 3.

  • Page 10: Use Of Electrical Accessories

    Inspect the hose before each use. If evidence of abrasion, wear, cuts or any other Valve orifice damage exists, replace the hose before using the appliance. ✓ ✓ Use only replacement parts from Phoenix Innovations Corp. Ensure that there are no gas leaks. See “Leak Test” section of this manual. Tube Burner 1/4”...

  • Page 11: Lighting / Operating Instructions

    For Models: PH603SB PH603SBN PAGE # 10 LIGHTING INSTRUCTIONS BURNER AIR SHUTTER ADJUSTMENT Rotate If main or side burner flame is not as indicated in Fig. 2-1, adjust the air shutters to improve flame. To adjust air shutters: 1. Light burners.

  • Page 12: Infrared Rear Burner

    For Models: PH603SB PH603SBN PAGE # 11 INFRARED ROTISSERIE BURNER Your grill comes equipped with an infrared burner and a rotisserie kit for rotisserie cooking. The infrared rotisserie burner is great for cooking roasts and fowl (Max 15 lbs / 6.8 kg). With the heat source located behind the food, there is no chance of a flare up caused by fat dripping on to hot burners below to burn or spoil your meal.

  • Page 13: Lp Gas Supply

    For Models: PH603SB PH603SBN PAGE # 12 LIQUID PROPANE (LP) GAS SUPPLY (FOR LP MODLES ONLY) This appliance is for use with LP gas only. The conversion to or attempted use of natural gas (NG) in this appliance is dangerous and will void your warranty.

  • Page 14: Hose And Regulator Assembly

    For assistance with repair or replacement of the hose, call our customer service line at 1-877-744-3649 or www.phoenixinno.com. Use only replacement parts from Phoenix Innovations Corp. b. Inspect the seal inside the CGA No 791 service valve on the LP gas cylinder when replacing the cylinder or at least once per year.

  • Page 15: Natural Gas Supply Connection

    For Models: PH603SB PH603SBN PAGE # 14 NATURAL GAS SUPPLY CONNECTION (FOR NG MODELS ONLY) This appliance is for use with natural gas only. The conversion to or attempted use of liquid propane gas (LP) in this appliance is dangerous and will void your warranty.

  • Page 16: Maintenance

    For Models: PH603SB PH603SBN PAGE # 15 MAINTENANCE CLEANING AND CARE: All cleaning and maintenance should be done while the grill is cool and with the fuel supply disconnected. During maintenance, a) care must be taken not to obstruct the flow of combustion and ventilation air in your grill.

  • Page 17: Cooking Grids

    For Models: PH603SB PH603SBN PAGE # 16 MAINTENANCE COOKING GRIDS: Clean before/after each use with a stiff wire brush. It is not necessary to fully clean the cooking grids after each use, but a mild soap and water solution can be used as necessary.

  • Page 18: Cooking Guides

    For Models: PH603SB PH603SBN PAGE # 17 GRILLING TIPS When grilling/rotisserie cooking large cuts of meat or extremely fatty meats, place an aluminum foil pan with approximately ½” - 1” of water below the cooking grids and under the food. This will serve to catch grease drippings which will prevent flare ups and also serves to provide moisture to the food being cooked.
  • Page 19 For Models: PH603SB PH603SBN PAGE # 18 COOKING GUIDES COOKING TEMPERATURE GUIDE: Beef/Lamb Rare 130°F (54°C) Medium 150°F (65°C) Well Done 160°F (71°C) Veal Well Done 150°F (65°C) Pork Well Done 170°F (76°C) Poultry Well Done 170°F (76°C) COOKING TIME GUIDE (STANDARD GRILLING):...

  • Page 20: Trouble Shooting Guide

    For Models: PH603SB PH603SBN PAGE # 19 TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION SHUT OFF LP GAS CYLINDER VALVE OR NATURAL GAS Perform leak test. SMELL OF GAS SERVICE VALVE IMMEDIATELY. DO NOT USE THE APPLIANCE (see “Leak Test” section of this manual) UNTIL LEAK IS SEALED.

  • Page 21: Warranty

    Phoenix Innovations Corp. does not accept responsibility for any indirect or consequential damages including, but not limited to replacement of the entire appliance. Always use replacement parts supplied only by Phoenix Innovations Corp. on this appliance. Use of other such replacement parts will void the warranty completely.
