Table of Contents
Finding the controls ..................................................................... 2
Installations and connections ......................................................... 4
Setting the date and time ............................................................... 7
Setting your facsimile telephone number .......................................... 7
Setting your logo ........................................................................ 8
Character input and command key table .......................................... 9
Voice guide .............................................................................. 10
Automatic dialing on the main unit ................................................ 11
Automatic dialing on the portable handset (KX-FKN514) .................. 13
Intercom ................................................................................. 14
Sending faxes ........................................................................ 15
Receiving faxes ........................................................................ 16
Operating the built-in answering device ....................................... 19
Night mode .............................................................................. 20
Call block .............................................................................. 21
Specifications ........................................................................ 22
This guide explains some basic features and operations, but not all of them.
For further details, see the Japanese operating instructions.
This product is designed for use in Japan.
Panasonic cannot provide service for this product if used outside Japan.
Any details given in this guide are subject to change without notice.
This unit is equipped with the voice guide features. (Japanese only)
For details about voice guide, please see page 10.
Quick Reference Guide
Thank you for purchasing a Panasonic facsimile.
KX-PW606DL
Model No.
KX-PW606DW
KX-PW616DL
KX-PW616D
Portable handset:
Facsimile
KX-PW606
KX-PW616
KX-FKN514
Advertisement
Table of Contents
Related Manuals for Panasonic KX-FKN514
Summary of Contents for Panasonic KX-FKN514
-
Page 1: Table Of Contents
For further details, see the Japanese operating instructions. This product is designed for use in Japan. Panasonic cannot provide service for this product if used outside Japan. Any details given in this guide are subject to change without notice. ... -
Page 2: Finding The Controls
— a call was missed.(For Number Display service users.) — a fax was stored in memory. Auto Answer button & indicator —light on: answering device activated. —light off: used as a regular telephone. 12 13 Replay button plays back recorded messages. Record button records a telephone conversation. - Page 3 Finding the controls Portable handset (KX-FKN514) How to use To use the phonebook. ● To redial the phone ● numbers in the redial list. The last 10 phone numbers dialed are stored in memory. To adjust the volume. ● To change Hiragana into ●...
-
Page 4: Installations And Connections
Installations and connections Installing the ink film Insert the orange gear into the left slot of the main unit. When the unit runs out of ink film, the following message will be displayed. ﾌｨﾙﾑがなくなりました U23 交換してください 品番：ＫＸ−ＦＡＮ190 Install a new ink film. Replacement ink film: KX-FAN190 (15 m) KX-FAN190W (15 m X 2) - Page 5 Installations and connections Installing recording paper (A4 size) Recording paper ● Folding the recording paper tray 1 Remove the recording paper and fold the recording paper stands in. Pull out the front stand first. Printing side is on the back. Open the recording paper tray.
- Page 6 : Pulse (10 PPS) Charge the battery in the charger for 10 hours. Terminals AC adaptor Plug After your Panasonic battery is fully charged, it will last up to about 5 hours of conversation. Power outlet (AC 100 V) Charger...
-
Page 7: Setting The Date And Time
呼出音とﾍﾞﾙ回数 音声の設定 電話帳の設定 Press 2007 年 09 月 30 日 15：00 Cursor Enter your facsimile telephone number, up to 20 digits. Example: + 098 7654·· 2007 年 10 月 01 日 15：00 2007 年 10 月 01 日 15：45 Press 登録しました... -
Page 8: Setting Your Logo
Setting your logo Press (Function). 名前（印刷用）？ Press Enter your logo, up to 30 characters, using the dial keypad. To enter English characters easily, press (Character input mode) repeatedly and select “ 英 ” (English and sign input mode). For details, see the table on page 9 for instructions. ... -
Page 9: Character Input And Command Key Table
Pressing the dial keys will select a character as shown below. Character Hiragana Display of the main unit and the ［かな］ portable handset Dial key Portable Main handset unit KX-FKN514 あいうえお ぁぃぅぇぉ かきくけこ さしすせそ たちつてとっ なにぬねの はひふへほ まみむめも やゆよゃゅょ らりるれろ わをんー！？ ( ) ゛°、... -
Page 10: Voice Guide
Voice guide Operation guide The unit starts the following voice guidance in Japanese: Operations Send a fax Copy Add entries to the phonebook Store phonebook entries in the speed dialer Make a call using the phonebook/redial/ speed dialer/call memory Change a ink film Select fax documents from the main unit memory Reading-out dial The unit announces the number dialed in Japanese, when you make a call with the main unit. -
Page 11: Automatic Dialing On The Main Unit
(Set). If you do not need to edit the kana, skip to step 7. (Set). If you do not need to edit the telephone number, skip to step 9. (Set). If you do not need to edit the group number, skip to step 11. -
Page 12: Speed Dialer
Automatic dialing on the main unit Storing names and telephone numbers in the speed dialer You can store up to 9 names and telephone numbers which are stored in the phonebook. The dialing buttons ) function as memory stations. Press (Speed dialer). -
Page 13: Automatic Dialing On The Portable Handset (Kx-Fkn514)
Automatic dialing on the portable handset (KX-FKN514) Storing names and telephone numbers in the phonebook Press (Phonebook). Press “XXX” shows the remaining station numbers you can store. You can program up to 150 stations, including 4 pre-programmed stations. -
Page 14: Intercom
– To call all the portable handsets, press Start talking. Example : Replace the handset to end the intercom call. Using the portable handset (KX-FKN514): For single portable handset users Press 電話番号？ For multiple portable handset users 1 Press 子機1 呼出中... -
Page 15: Sending Faxes
Sending faxes Sending a fax manually Document Document cover Open the document cover, and adjust the width of the document guides to the size of the document. Insert the document (up to 5 pages) FACE UP until a single beep is heard. If necessary, press (Resolution) repeatedly to select the desired setting (see below). -
Page 16: Receiving Faxes
(Fax), then replace the handset. The unit will start fax reception. Using the portable handset (KX-FKN514): When you hear a ring, lift the portable handset from the charger to answer the call. If the portable handset is not set on the charger, ... -
Page 17: Receiving Faxes
Receiving faxes Display when faxes are received in memory When new faxes are received in memory, (Call/Fax list) will be on. The number of faxes stored in memory is displayed. Example : Information about display To scroll display contents (Example) Left Right... - Page 18 Receiving faxes Printing a specific fax stored in memory Press (Call/Fax list) and Press (Search button) to select the desired fax to print, then press (Print). After printing, the following is displayed. Do you delete the printed contents ? If you want to delete the fax, press ...
-
Page 19: Operating The Built-In Answering Device
Operating the built-in answering device Recording your own greeting message You can record your own greeting message. When receiving a call, it will be played to callers instead of the pre-recorded Japanese greeting message. Press (Function). Press Press (Set). Lift the handset. Press (Set) and speak your greeting message after a beep, up to 16 seconds, to the handset. -
Page 20: Night Mode
Operation: Listening to a recorded message from a remote location Turn the (Auto answer) light on before you go out. Remote operations are available only from a touch tone telephone. 1. Call your unit. 2. Enter the remote operation ID during the greeting message. 3. Press or wait 4 seconds. -
Page 21: Call Block
To block the call, press (Yes). To cancel blocking, press (No). When the following is displayed, press cancel. Using the portable handset (KX-FKN514): (Block). (Block), Press an incoming call. Press “ 通話拒否 ” is displayed. Press (Block). -
Page 22: Specifications
*2 Transmission speed is based on an A4-size document of 700 characters sent in standard resolution at 9,600 bps. The actual transmission speed depends upon the contents of the page, resolution, telephone line conditions and capability of the other party’s machine. - Page 24 2007 Panasonic Communications Co., Ltd. All Rights Reserved. PFQX2730ZA FK0207MH0...
