Panasonic ESE22 Specifications

2N Detector Switches
ESE22
Type:
■
Features
●
Can be operated with different actuation angles
(horizontally and vertically)
●
Refl ow soldering
●
Light operating force
■
Explanation of Part Numbers
■
Specifi cations
Rating
Contact Resistance
Insulation Resistance
Dielectric Withstanding Voltage
Operating Force
Mounting Height
Poles and Throws
Full Travel (Pushing distance)
Operating Life
Temperature Range
Heat Resistance
Low Temperature Resistance
Humidity Resistance
Minimum Quantity/Packing Unit
Quantity/Carton
Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
1 2 3
E S E 2
Product Code
· Type MV
· Type MH
· Type MV
· Type MH
· Type MV
· Type MH with Frame
· Type MH
· Type MV
· Type MH with Frame
· Type MH
■
Recommended Applications
●
Detection of media in portable electronic equipment
4 5 6 7
2
Type Style
50 µA 3 Vdc to 10 mA 5 Vdc (Resistive load)
500 m
100 M
100 Vac for 1 minute
300 mN max.
4.1 mm
2.85 mm
with Frame
1-pole 1-throw
4.25 mm(2.05 mm) · Type MH 1.2 mm(2.0 mm)
0.6 mm(2.0 mm)
with Frame
50000 cycles min.
–10 °C to +70 °C
+80 °C for 96 hours
–25 °C for 96 hours
+40 °C 90 % to 95 % RH for 96 hours
500 pcs. Polyethylene Bag (Bulk)
1000 pcs. Embossed Taping (Reel Pack)
3000 pcs. Embossed Taping (Reel Pack)
4000 pcs. Embossed Taping (Reel Pack)
10000 pcs. Polyethylene Bag (Bulk)
6000 pcs. Embossed Taping (Reel Pack)
18000 pcs. Embossed Taping (Reel Pack)
24000 pcs. Embossed Taping (Reel Pack)
– ES44 –
Detector Switches/ESE22
8 9
Design No.
max. (Initial)
min. (100 Vdc)
· Type MH 2.1 mm
00 Sep. 2010
