The AHR5 switch with actuating
lever and retainer assembled
CONSTRUCTION
Rotating
shaft
Handle
Pin
plunger
Restoration
spring
Stationary
contact
PRODUCT TYPES
Type
Retainer mounting direction
Standard (Silver alloy)
Low-level circuit type
(Gold clad)
Actuator lever
Remarks: 1. The retainer is provided with the switch body without assembled.
2. Actuating levers are available separately.
(AHR5801, length: 52.3mm 2.059inch)
3. As for International standard, please refer to the "Information".
SPECIFICATIONS
1. Contact rating (Resistive load)
Type
Standard (Silver alloy)
Low-level circuit type (Gold clad)
HIGH CONTACT PRESSURE
WITH LIGHT OPERATING
ACTION
FEATURES
• High contact pressure with light oper-
ating action
• Easy installation of the lever—Tools
or adhesives are unnecessary for at-
taching the actuating lever
• Low-level circuit type is also available
Actuating spring
Movable contact
Operating spring
Operating force (max.)
Counter-clockwise
Clockwise
0.1N•cm {10.2gf•cm}
Counter-clockwise
Clockwise
52.3mm
2.059inch
Solder and
Q.C. (187)
N.O. terminal
Common
terminal
N.C. terminal
Release force (min.)
0.013N•cm {1.3gf•cm}
—
Standard rating
5A 250V AC
1A 250V AC
11/2002
V-ROTARY
ACTION (AHR5)
SWITCHES
TYPICAL
APPLICATIONS
• Vending machines
SPDT .187 Quick-connect/
solder terminal
AHR5401
AHR5411
AHR540161
AHR541161
AHR5801
Low-level rating
6V DC 5mA
12V DC 2mA
24V DC 1mA
AHR5
75
