HealthyLine SHL-G800 User Manual

Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Enlarged version
Technical Specification
Product Name
Healthy Line Blood Glucose Meter
SHL-G800
Meter Type
Fresh capillary whole blood
Blood Sample
0.5 ul
Blood Volume
SHL-GS50 , SHL-GS25
Test Strip Type
1 1 33 3 mmol/L
. -
.
Measuring Range
5 seconds
Measuring Time
One 3V Lithium Battery type (CR2032)
Power
Approximately 1000 tests
Battery Life
300 test results (include time and date)
Memory Capacity
10 ~ 40
Operating Temp.
10% ~ 90 %
Operating Humidity
Storage Temperature
4
~ 30
Dimensions
15 mm x 54 mm x 86 mm
Weight
45g (with battery)
Va multumim ca ati ales un produs din gama
TM
Produsele
sunt create special pentru dumneavoastra, avand ca principal
ealthy
ine
swiss health corporation
scop, dorinta de a va oferi prin intermediul tehnologiilor de inalta calitate,
SOLUTII PENTRU O SANATATE PERFECTA
Sistem digital de monitorizare
a glucozei in sange
Model SHL-G800
TM
ealthy
ine
swiss health corporation
TM
, ati facut o alegere inspirata.
ealthy
ine
swiss health corporation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHL-G800 and is the answer not in the manual?

Questions and answers

Summary of Contents for HealthyLine SHL-G800

  • Page 1 1 1 33 3 mmol/L Measuring Range 5 seconds Measuring Time One 3V Lithium Battery type (CR2032) Power Model SHL-G800 Approximately 1000 tests Battery Life 300 test results (include time and date) Memory Capacity 10 ~ 40 Operating Temp.
  • Page 2 Folosire si pastrare sau persoanelor care au o deshidratare accentuata. Aparatul este destinat pentru a fi folosit acasa Aparatul SHL-G800 utilizeaza numai teste modelul SHL-GS50 (25) Inaintea utilizarii, aparatul trebuie lasat sa se aclimatizeze cu temperatura mediului ambiant aproximativ 20 minute.
  • Page 3 Introduceti testul in aparat in locul indicat in imaginea de mai sus, iar in scurt timp veti auzi un bip si pe ecran va apare un cod. Testele SHL-GS50(25) se folosesc numai la aparatul SHL-G800. Verificarea codului Notati data deschiderii unei sticlute de test pentru a evita utilizarea acestora dupa expirare.
  • Page 4 Ajustarea codului Metode de testare Dezinfectare Aparatul permite setarea codurilor de la 01 la 70, setarea din fabrica va avea codul 25 . Ajustarea codului se face cu autorul Inainte de a se face testul de glicemie, spalati-va pe maini cu apa calda si butoanelor “M”...
  • Page 5 Adaugarea picaturii de sange 4. Puneti la loc partea superioara a lansetei, prin infiletare in sensul acelor de ceasornic. 5. Tineti ferm cu o mana partea superioara a lansetei si trageti cu cealalta mana de partea glisanta care se afla in capatul Atingeti la baza picaturii de sange cu capatul testului care a ramas in afara celalalt al lansetei.
  • Page 6 Utilizarea memoriei si setarile aparatului 5. In acest moment, daca apasati in mod repetat butonul “C”, pe ecran vor fi afisate pe rand rezultatele ultimelor masuratori Verificarea rezultatelor din memoria aparatului memorate de aparat. BEEP! 6. Dupa verificarea completa a rezultatelor din memorie, puteti parasi operatiunea prin apasarea butonului “M”, astfel aparatul se va inchide.
  • Page 7 Setarea Datei si Orei Setarea lunii Cand cifra care simbolizeaza luna clipeste, apasati pe butonul “C” de cate ori este nevoie pana cand va aparea cifra corespunzatoare lunii dorite. Incepeti cu aparatul inchis. Apoi apasati o data pe butonul “M” pentru mutarea setarii pe o alta cifra care va clipi.
  • Page 8 Setarea orei Stergera rezultatelor Cand cifra care simbolizeaza ora clipeste, apasati pe butonul “C” de cate ori este nevoie pana cand va aparea cifra orei dorite. Apoi apasati o data pe butonul “M” pentru mutarea setarii pe o alta cifra care va clipi. BEEP! Setarea minutului Cand cifra care simbolizeaza minutul clipeste, apasati...
  • Page 9 Memorarea rezultatului testarilor Daca doriti sa pastrati datele in memorie, alegeti simbolul „NO“ si apasati pe butonul „M“ pentru a trece la pasul urmator. Daca vrem sa Toate rezultatele Dupa aparitia Setari la final stergem toate vor fi sterse iar pe cuvantului “del”...
  • Page 10 Marcarea rezultatelor speciale Inlocuirea bateriei Aparatul Healthy Line SHL-800 foloseste o baterie de lithium model CR2032 Marcarea inainte sau dupa masa. Semnalul “Baterie Consumata” Acest marcaj apare cand vreti sa stiti diferenta de rezultate Cand energia aparatului nu mai este suficienta, pe ecran va intre inainte de masa /dupa masa si situatia din prezent.
  • Page 11 Daca mesajele de eroare nu sunt suficiente va rugam accesati Picatura de sange nu a fost Reluati testarea. Healthy Line service la www.healthyline.ro suficienta pentru masuratoare , vascozitatea a fost prea Plaja de masurare a aparatului Healthy Line SHL-G800 este cuprinsa mare sau volumul insuficient intre: 1.1mmol/L si 33.3mmol/L.

  • Page 12: Specificatii Tehnice

    System 1 1 33 3 mmol/L Plaja Masurare 5 secunde Timp masurare 3V Baterie Lithium tip (CR2032) Baterie Model SHL-G800 Aprox. 1000 teste Durata Baterie 300 rezultate (inclusiv data si ora) Capacitate Memorie 10 ~ 40 Temp. Operare Umiditate permisa 10% ~ 90 % Temp.
  • Page 13 Usage and storage dehydration. Medisign MM800 Monitoring System is designed for home usage. SHL-G800 meter is for use only with SHL-GS50, SHL-GS25 Blood Glucose Before using your monitoring system, please place it in the environment of Test Strips. system's normal operating temperature ranging (10 - 40 )for about 20 minutes.

  • Page 14: Check Code

    Validity collection slot Insert Test Strips and Adjust Code SHL-GS50(25) test strips only fit SHL-G800 meter Beep! Insert a test strip into the strip port. You will hear the sound of Please check the validity of test strips before using.
  • Page 15 The Method of Testing Adjust Code Disinfect Before Test Blood glucose monitoring system has set up codes from 01 to Before test, please clean hands with soap and water and then dry well. You 70, and the system's default code is 25. Adjust code using 'M' or can also use an alcoholic cotton cloth to clean finger.
  • Page 16 Add Blood Sample 4. Put the tip of the lancing device back on and turn it clockwise 5. Hold the tip firmly in one hand then pull out the sliding barrel with the other hand. This will cock the lancing device Touch the blood drop to the sample channel at the end of the strip.
  • Page 17 Review & Setting 5. Press 'C' button every time, the screen will show the test result, date and time. Checking Test Results BEEP! 6. After completing the check, press 'M' button, and the meter will turn off. 2. The screen 3.

  • Page 18: Setting The Date And Time

    Setting the “Month” Setting the Date and Time When month mode blinks, press and release 'C' Button until correct month appears. Press 'M' button to set and move To date setting Begin with the meter off, mode. press 'M' button for 3 seconds, you will hear the beep, the screen will show the whole symbol of...

  • Page 19: Delete Test Results

    Delete Test Results Setting the “hour” When hour mode blinks, press and release button until correct hour appears. Press 'M' button to set and move to minute setting mode. BEEP! Setting the “minute” When minute mode blinks, press and release 'C' button until correct minute appears.

  • Page 20: Storing Test Results

    Storing Test Results If you want to store the test result, please choose the symbol 'NO' and press 'M' button again to move the next step. Setting Complete After the word 'del' If you want to delete After deleting, the appears, the screen the test result, press screen will show as...

  • Page 21: Replacing Battery

    Special Results Replacing Battery Blood glucose meter uses a lithium battery (CR2032). The mark of before or after meal Empty Battery Sign ” “ This mark appears when you want to know the different result Blood glucose meter uses a lithium battery (CR2032). between before/after meal and present.

  • Page 22: Troubleshooting

    You may use it after about 20 minutes. If you can not deal with the error messa please access Healthy Line The Blood sample service at www.healthyline.ro did not fill enough during Replace the test strip. measurement because of The test range of Healthy Line blood glucose meter abnormally high viscosity is from 1.1mmol/L to 33.3mmol/L.
