Model 25D Manual
Introduction:
The Model 25D drive electronics is a high voltage push-pull power amplifier capable of output
voltage swings in the order of 175v P-P, push-pull. The Model 25D provides output rep rates
from DC-30MHz and typical rise and fall times of 8ns.
ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145
Email: sales@conoptics.com, or visit
www.conoptics.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for conoptics 25D
Summary of Contents for conoptics 25D
- Page 1 The Model 25D drive electronics is a high voltage push-pull power amplifier capable of output voltage swings in the order of 175v P-P, push-pull. The Model 25D provides output rep rates from DC-30MHz and typical rise and fall times of 8ns.
-
Page 2: Specifications
Forced air-cooling. (Total dissipation approx. 350W). Dimensions: The dimensions are 45cm W x 44cm L x 17.5cm H. The weight is 32lbs Environmental Typical lab use. Conditions: ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit www.conoptics.com... -
Page 3: Technical Overview
Technical Overview: The Model 25D has a maximum output of 175v p-p. The output stage is the only saturating part of the amplifier. Although the amplifier accepts standard TTL drive levels as its input, the entire amplifier with the exception of the output stage is linear. At the very input of the amplifier, a switch allows the user to select either TTL or low level Analog as its required input format. -
Page 4: Controls And Indicators
This voltage is not referenced to ground but is to the internal electrodes of the modulator. Bias voltage range is approximately, +/- 400vDC. ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit... -
Page 5: Equipment Installation
Conoptics. Equipment Maintenance and Service: The Model 25D includes a 1-year Warranty on all parts and labor. The unit is not field serviceable. If a fault issue does arise it is important to shut the system down and immediately contact Conoptics service department at support@conoptics.com. - Page 6 Input impedance is 50 ohms. Note: To change the input format switch, remove the top cover on the Model 25D driver electronics while the system is powered off. ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit...
- Page 7 Model 25D Connection Diagram for Pulse Selection System (Analog Setting) ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit www.conoptics.com...
- Page 8 Model 25D Connection Diagram to Pulse Generator (TTL Setting) ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit www.conoptics.com...
- Page 9 CONOPTICS INC. DANBURY, CT. 06810 J4-11, -550V Size Document Number M25DS DRIVE ELECTRONICS J4-12, +/- 15V RETURN FILE # SCHLUM25DS Date: Wednesday, October 08, 2008 Sheet ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit www.conoptics.com...
- Page 10 100K 100PF 6.8K 6.8K 470K 3.3K CONOPTICS INC. DANBURY, CT. 06810 Size Document Number -550VDC BIAS SUPPLY Date: Thursday, April 06, 2006 Sheet ConOptics, Inc. 19 Eagle Road, Danbury, CT 06810 Phone 800-748-3349 Fax 203-790-6145 Email: sales@conoptics.com, or visit www.conoptics.com...
