Panasonic SUPER DYNAMIC III WV-NS202A Specifications

Network camera exceeding the human eye featured by Super Dynamic III

Key Features

• Built-in MPEG-4 and JPEG digital signal output at VGA image size with up to 30 ips.
• MPEG-4/JPEG dual stream output for simultaneous live monitoring
and high resolution recording.
• Progressive Output with motion adaptive interlace/progressive conversion
allows every frame to be clear even when the object is moving.
• Super Dynamic III technology delivers 128x wider dynamic range
compared to conventional cameras.
• High sensitivity: Color: 0.7 lux (Sens up OFF), B/W: 0.5 lux (Sens up OFF)
• Simple Day-Night function (No IR cut filter moving)
• Up to 32x automatic electronic sensitivity enhancement.
• Video Motion Detector with 4 programmable detection areas and 3 sensitivity levels.
• 22x zoom lens with 10x digital zoom enabling 220x zoom
• Auto tracking: Pan and tilt automatically controlled to keep moving
objects centered in screen.
• PTZ control can be taken on the user friendly GUI with 16 speeds
pan/tilt and new "Drag and Zoom" operation enabling finer control.
256 speeds available for system with WV-CU950 system controller.
• Up to 64 preset positions
• 360 map shot: 8 thumbnail images at 45 deg. intervals make it
simple to direct the camera easily by clicking on a thumbnail.
• Built-in network interface (10Base-T / 100Base-TX).
• Power over Ethernet (PoE) IEEE 802.3af.
• Multiscreen: Image from 16 cameras can be displayed in 4 different
Quad screens or 16-screen (JPEG only)
• FTP client function enables periodic image data transfer or transfer upon alarm
• Alarm notification via E-mail.
• Max. bit rate/client for MPEG-4 (64 / 128 / 256 / 512 / 1,024 / 2,048 /
4,096 kbps) and Total bit rate control (64 / 128 / 256 / 512 / 1,024 /
2,048 / 4,096 kbps / Unlimited) allowing flexible network management.
• 2-way audio feature (G.726, 32 / 16 kbps)
• Alarm log, Manual REC log, FTP error log saved in the SD card is
displayed on the browser GUI and can be downloaded to the client PC.
Playback or Image data download through the log is also available.
Dome Network Camera
WV-NS202A
WV-NS202A
(12V DC or PoE)
• Multi-language GUI and setup menu: English, French, Italian, Spanish, German, Polish,
Russian (PAL), English, French (NTSC), (Installation required except for English).
• SD Memory card slot for Manual recording, Alarm recording and Backup upon network failure.
• Alarm sources include Terminal 1 ~ 3, VMD and Panasonic alarm command. Selectable
alarm actions include SD memory recording, FTP image transfer, E-mail notification, Alarm
indication, Terminal output, Camera positioning, Auto track and Panasonic protocol output.
• Scheduling function for Alarm / VMD / Access permission, Preset
position call and Position refresh.
• Industrial grade Pan/Tilt/Zoom mechanism for high reliability
• One-touch Fitting Mechanism for easy installation
• Desktop/Ceiling position choice and various optional brackets for versatile installations

Standard Accessories

• CD-ROM* .......................................1 pc.
• Installation Guide ...........................1 pc.
* The IP setup software, the viewer software
and the network operating instructions
(PDF) are included on the CD-ROM.
The following are for installation.
• Mount Bracket (w/safety wire)........ 1 pc.
Optional Accessories
Inner Dome Cover Ceiling Mount Brackets
WV-Q153 WV-Q152C
(Clear)
WV-Q152S
(Smoke)
(Smoke Type)
Wall Mount Brackets
WV-Q150C
(Clear)
WV-Q150S
(Smoke)
(Smoke Type)
Super Dynamic III
WV-NS202A
(12V DC or PoE)
• Fixing Screw
.................... 2 pcs. (incl. a spare screw)
• Decorative Cover .......................... 1 pc.
• DC 12 V Power Cord Plug ............ 1 pc.
• Code Label* .................................. 1 pc.
* It will be needed for network management.
A network administrator should keep this label.
Embedded Ceiling Mount Brackets
WV-Q151C
(Clear)
WV-Q151S
(Smoke)
(Smoke Type)
Direct Ceiling Installation
WV-Q105
