- Page 1 VZ-LX SERIES 24", 27", 32" and 42" PROFESSIONAL LED CCTV MONITOR USER MANUAL Please read this manual thoroughly before use, and keep it handy for future reference.
-
Page 2: Table Of Contents
2. Interface ........................................ 3. Remote Control Function ................................Function .......................................... 1. Monitor Button Function ................................2. OSD Control and Function ................................Mounting Guide ......................................Specification ........................................Trouble Shooting ................................................................................Warranty ........................................Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 3: Safety Instruction
The monitor shall not be exposed to dripping or splashing and objects containing liquids, such as vases shall be placed near the monitor. The monitor should have ample distance (e.g. 10cm) from the wall for sufficient ventilation. User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 4: Mark Indication & Substance
If your monitor does not operate normally – in particular, if there is any unusual sound or smell coming from the monitor – unplug it immediately and contact an authorized dealer or the service center. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 5: Caution
While most pixel faults occur in isolated regions, a cluster of dead pixels or sub-pixels can sometimes form for which a separate ruling applies. A cluster is defined as an area of 5x5 pixels. ViewZ’s policy on pixel failure: either as an isolated fault or in the form of a cluster is outlined on the website: www.viewzusa.com User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 6: Fcc Rf Interference Statement
► DOC COMPLIANCE NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the radio interference regulation of Canadian Department of communications. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 7: Installation
User Manual (Qty 1) Monitor Stand Set (Qty 1) Remote Controller (Qty 1) Mounting Option Your ViewZ monitor is compatible with ViewZ monitor mounts. For more information, please contact ViewZ USA at (888)-998-4399. Wall Mount • Part # WM50 • Part # WM71 •... -
Page 8: Interface
8. AV ( BNC ) #3 IN 9. AV ( BNC ) #4 IN 10. AV ( BNC ) #5 IN 11. VGA (15 Pin D-Sub) IN 12. DVI IN 13. HDMI IN 14. AC 110V IN Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 9: Remote Control Function
VGA, YPbPr, HDMI, AV & DVI buttons to select desired input source 10. Press the 'MUTE' button to on / off audio - audio only works with VGA / AV input User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 10: Function
6. Press the MENU button to exit the sub-MENU and go back to the main-MENU 7. Press the MENU button to exit the OSD MENU Visit the ViewZ USA website at https://www.viewzusa.com User Manual... - Page 11 Press◄ / ► buttons to adjust volume on monitor Press◄ / ► buttons to adjust volume on remote controller Detect Source Signal Message If you connect any input source, monitor will display current input source resolution and frequency. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 12 Give the white color a blue-ish tint 3D NR OFF-LOW-MID-HIGH Estimates the amount of noise automatically and applies suitable noise reduction processing MPEG NR OFF-LOW-HIGH Reduces noise on MPEG pictures such as mosquito-noise and block-noise Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 13 Adjust preset sound mode MODE 1 / MODE 2/ MODE 3 / MODE 4 / OFF BASS Adjust the bass level ON /OFF / 1 - 12 MUTE Mute the sound ON / OFF User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 14 HDMI connection to set for DVD & PC DVD MODE HDMI connection to set for DVI Channel DVI MODE RESTORE DEFAULT Reset the monitor settings to the factory default 1) HDMI input support Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 15 0 / 15 / 30 / 45 / 60 sec PREVENT BURN-IN Set periodic image retention 1 HR / 2 HR / 4 HR / TEST / OFF 1) Only available in VGA input User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 16 PIP / PBP input source DVI, YPBPR, HDMI, VGA, AV1, AV2, AV3, AV4, AV5 PIP SIZE SMALL, MEDIUM, LARGE Display small, medium, large size PIP window on main display PIP MODE HDMI YPbPr HDMI YPbPr Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 17 At least two people are recommended to safely install the stands. If you use the wrong size screws, it may cause damage to the monitor. If the monitor is damaged by using wrong size screws, ViewZ will not be held responsible. User Manual...
-
Page 18: Mounting Guide
Please use bolt of correct size and length as instructed. Mounting Safety ! At least two people are recommended to safely install the mount. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 19: Specification
CE / FCC / RoHS Electrical Ratings AC 100-240V, 50/60Hz Power Consumption ≤ 40 W ≤ 40 W ≤ 48 W ≤ 70 W Accessories HDMI cable, AC 110V Power cable, User’s Manual, Remote controller User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 20: Trouble Shooting
At start the current input source. If symptom persists, follow the instructions below. After following the instructions below, please contact us at 1-888-99-VIEWZ. - Make sure the cable is correctly plugged into the outlet - Make sure the power cable is correctly plugged into the monitor No image or - Make sure the cable is correctly connected between monitor &... - Page 21 - The warranty period for this monitor is 3 years. The warranty will be voided for the scenarios listed below. - You can also download the manual and information of VIEWZ web site: VIEWZUSA.COM When power feed to the monitor exceeds capacity and causes damage...
- Page 22 NOTE Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
-
Page 23: Warranty
What ViewZ USA Will Do At the sole discretion of ViewZ USA, ViewZ USA will repair or replace any product or product part that is defective. If ViewZ USA chooses to replace a defective product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor costs.
