Page 1: Operating Instructions
Operating Instructions High Defi nition Plasma Display TH-50PF10WK Model No. TH-65PF10WK The illustration shown is an image. Please read these instructions before operating your set and retain them for future reference. English TQBC2236... -
Page 2: Table Of Contents
Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference. -
Page 3: Important Safety Notice
Important Safety Notice WARNING 1) To prevent damage which may result in fi re or shock hazard, do not expose this appliance to dripping or splashing. Do not place containers with water (fl ower vase, cups, cosmetics, etc.) above the set. (including on shelves above, etc.) No naked fl... -
Page 4: Safety Precautions
• If water is spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in fi re or electric shock. If any foreign objects get inside the Plasma Display, please consult your local Panasonic dealer. -
Page 5: If Problems Occur During Use
If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damages, disconnect the power supply plug immediately. • A short circuit may occur, which could cause fi re. Contact your local Panasonic dealer for any repairs that need to be made. -
Page 6: Cleaning And Maintenance
Safety Precautions CAUTION When using the Plasma Display Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display. • Heated air comes out from the ventilation holes at the top of Plasma Display will be hot. Do not bring your hands or face, or objects which cannot withstand heat, close to this port, otherwise burns or deformation could result. -
Page 7: Accessories
Accessories Accessories Supply Check that you have the accessories and items shown Operating Instruction book Power supply cord Remote Control Batteries Requires two R6 batteries. 1. Pull and hold the hook, then open the battery cover. Helpful Hint: For frequent remote control users, replace old batteries with Alkaline batteries for longer life. -
Page 8: Connections
Connections TH-50PF10WK When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. Speakers (Optional accessories) Speaker terminal (R) – AC cord fi xing Note: Make sure that the AC cord is locked on both the left and right sides. - Page 9 TH-65PF10WK When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. Speakers (Optional accessories) Speaker terminal (R) – AC cord fi xing Note: Make sure that the AC cord is locked on both the left and right sides.
-
Page 10: Pc Input Terminals Connection
Connections PC Input Terminals connection COMPUTER Notes: • Due to space limitations, occasionally you may have trouble connecting Mini D-sub 15P cable with ferrite core to PC input Terminal. • Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning frequency of 48 to 120 Hz. -
Page 11: Serial Terminals Connection
Slot2 input Slot3 input PC input SL1A Slot1 input (INPUT1A) SL1B Slot1 input (INPUT1B) SL2A Slot2 input (INPUT2A) SL2B Slot2 input (INPUT2B) None Screen mode select (toggle) NORM NORMAL (4 : 3) ZOOM ZOOM FULL FULL JUST JUST SELF Panasonic AUTO... -
Page 12: Hdmi Connection
Connections HDMI connection This unit has terminal boards equivalent to Dual HDMI Terminal Board (TY-FB10HMD) and BNC Component Video Terminal Board (TY-42TM6A) as standard equipment. [Pin assignments and signal names] Pin No. Signal Pin No. Signal T.M.D.S Clock T.M.D.S Data2+ Shield T.M.D.S Data2 T.M.D.S Clock-... -
Page 13: Power On / Off
Connecting the AC cord plug to the Plasma Display. Fix the AC cord plug securely to the Plasma Display with the clamper. (see page 8, 9) TH-50PF10WK Connecting the plug to the Wall Outlet Notes: • Main plug types vary between countries. The power plug shown at right may, therefore, not be the type fi... - Page 14 Power On / Off Press the button on the remote control to turn the Plasma Display off. Power Indicator: Red (standby) Press the button on the remote control to turn the Plasma Display on. Power Indicator: Green Turn the power to the Plasma Display off by pressing the unit, when the Plasma Display is on or in standby mode.
-
Page 15: Initial Selections
Initial selections Selecting the input signal Select the input signals to be connected by installing the optional Terminal Boards. Press to select the input signal to be played back from the equipment which has been connected to the Plasma Display. Input signals will change as follows: Press the INPUT “1”, “2”, “3”... -
Page 16: Basic Controls
Basic Controls Main Unit Remote control sensor Main Power On / Off Switch Power Indicator The Power Indicator will light. • Power-OFF ... Indicator not illuminated (The unit will still consume some power as long as the power cord is still inserted into the wall outlet.) •... -
Page 17: Remote Control Transmitter
Remote Control Transmitter R button (see page 19) Press the R button to return to previous menu screen. Standby (ON / OFF) button The Plasma Display must fi rst be plugged into the wall outlet and turned on at the power switch (see page 13, 14). -
Page 18: On-Screen Menu Displays
On-Screen Menu Displays To Picture adjust menu (see page 25) Picture Normalise Normal Normal Picture Mode Contrast Brightness Colour Sharpness Picture Normal White balance Colour Management Advanced settings Press to select “On”. Press to enter Advanced settings. To Advanced settings (see page 25, 26) Advanced settings Normalise... - Page 19 3D Y/C Filter (NTSC) Cinema reality Colour system Auto P-NR Cinema reality Block NR Panasonic Auto (4:3) Mosquito NR P-NR Block NR Mosquito NR Note : “Signal” setup menu displays different setting condition for each input signals. (see page 15) To setup Screensaver...
-
Page 20: Aspect Controls
60p · 50p signal input, the mode is set to “16 : 9” mode, and switching is not possible. • Panasonic Auto can be selected only during Video signal input. • The aspect mode is memorized separately for each input terminal. -
Page 21: Adjusting Pos. /Size
This picture position movement cannot be controlled by the Picture Pos./Size function. • If adjusting the Picture V-Pos/V-Size in Panasonic Auto with 16:9 mode, the adjustment is not memorized. When exiting the mode, the screen will return to a former adjustment. - Page 22 Adjusting Pos. /Size Auto Setup Automatically adjust H-Pos / V-Pos / Clock Phase / Dot Clock and set H-Size / V-Size the standard value when RGB signal is input. Notes: • If the dot clock frequency is 162 MHz or higher, Dot Clock cannot be made. •...
-
Page 23: Multi Pip
MULTI PIP Press repeatedly. Each time pressing this button main picture and sub picture will be displayed as follows below. Normal Viewing Press to swap main picture and sub picture. Press to select the input mode. Under main Picture and sub picture display, select the picture which you would like to change input modes. -
Page 24: Advanced Pip
Advanced PIP Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select Advanced PIP. Press to adjust the menu. Off : Sets normal two screen display mode On : Sets Advanced PIP mode. -
Page 25: Picture Adjustments
Picture Adjustments Press to display the Picture menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by looking at the picture behind the menu. Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting. -
Page 26: Advanced Settings
Picture Adjustments Item Effect Contrast Less More Brightness Darker Brighter Colour Less More Reddish Greenish Sharpness Less More Advanced settings Item Effect Black extension Less More Input level Less More Gamma Down W/B High Less More W/B High Less More W/B High Less More... -
Page 27: Sound Adjustment
Sound Adjustment Press to display the Sound menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by listening to the sound. Bass Adjusts low pitch sounds Adjusts normal sounds Treble Adjusts high pitch sounds Balance Adjusts left and right volumes Surround... -
Page 28: Sdi Soud Output
Sound Adjustment SDI Sound Output This menu is displayed when HD-SDI Terminal Board with audio (TY-FB10HD) is installed to the unit. SDI Sound Output Left Channel Channel 1 Right Channel Channel 1 Sound Out Level Meter Item Channel 1 to Channel 16 Left Channel Selects left audio channel. -
Page 29: Digital Zoom
Digital Zoom This displays an enlargement of the designated part of the displayed image. Display the operation guide. Press to access Digital Zoom. The operation guide will be displayed. During Digital Zoom, only the following buttons can be operated. [Remote control] Select the area of the image to be enlarged. -
Page 30: Present Time Setup / Set Up Timer
PRESENT TIME Setup / Set up TIMER The timer can switch the Plasma Display On or Off. Before attempting Timer Set, confi rm the PRESENT TIME and adjust if necessary. Then set POWER ON Time / POWER OFF Time. Press to display the Setup menu. Press to select Set up TIMER or PRESENT TIME Setup. -
Page 31: Set Up Timer
Set up TIMER Display the Set up TIMER screen. Press to select POWER ON Time / POWER OFF Time. Press to setup POWER ON Time / POWER OFF Time. Notes: • Pressing “ ” or “ ” button once changes POWER ON Time / POWER OFF Time 1 minute. -
Page 32: Screensaver (For Preventing Image Retention)
Screensaver Do not display a still picture, especially in 4:3 mode, for any length of time. If the display must remain on, a Screensaver should be used. Press to display the Setup menu. Press to select Screensaver. Press to display Screensaver screen. Reversal / Scroll selection Press to select Function. -
Page 33: Setup Of Screensaver Time
Setup of Screensaver Time After selecting Time Designation or Interval, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “Mode” is “On” or “Off”.) Screensaver PRESENT TIME 99:99 Start Function White bar scroll... -
Page 34: Side Panel Adjustment
Screensaver (For preventing image retention) Side Panel Adjustment Do not display a picture in 4:3 mode for an extended period, as this can cause an image retention to remain on the side panels either side of the display fi eld. To reduce the risk of such an image retention, illuminate the side panels. -
Page 35: Reduces Power Consumption
Reduces power consumption • Power save: When this function is turned On, luminous level of the Plasma Display is suppressed, so power consumption is reduced. • Standby save: When this function is turned On, power consumption of the microcomputer is reduced during power supply standby (see page 13, 16-17), so standby power of the set is reduced. -
Page 36: Setup For Multi Display
Setup for MULTI DISPLAY By lining up Plasma Displays in groups, for example, as illustrated below, an enlarged picture may be displayed across all screens. For this mode of operation, each plasma display has to be set up with a Display number to determine its location. (Example) group of 4 (2 ×... -
Page 37: For Each Plasma Display
How to set the display location number for each Plasma Display Press to select Horizontal Scale. Press to select “× 1”, “× 2”, “× 3”, “× 4”, “× 5”. Press to select Vertical Scale. Press to select “× 1”, “× 2”, “× 3”, “× 4”, “× 5”. Press to select Seam hides video. -
Page 38: Id Remote Control Function
Setup for MULTI DISPLAY AI-synchronization Adjusts brightness of displays when using MULTI DISPLAY. Press to select AI-synchronization. Press to select “Off” , “On”. Note: If you set AI-synchronization to On, the following menus will be unavailable and these settings will be fi xed to the initial values. -
Page 39: Set Up For Portrait
Set up for Portrait Divide an input image into 3 parts, and display one of them to a plasma display which is set vertically. The image will be enlarged 3 times and rotated 90-degree. (Example) Note: When using the Portrait function with displays set vertically, “V.Installation” in Options menu has to be set to “On” (see page 48). How to setup Portrait Press to display the Setup menu. - Page 40 Set up for Portrait Viewing Area / Location Viewing Area: Set a mode of image division for Portrait function. Location: Set a location of image to be displayed for Portrait function. Press to select Viewing Area or Location. Press to select each functions. Notes: •...
-
Page 41: Setup For Input Signals
Standby save Power management Auto power off OSD Language Signal 3D Y/C Filter (NTSC) Colour system Cinema reality Panasonic Auto (4 : 3) P-NR Setup Signal English ( UK ) Setup Signal English ( UK ) Press ACTION ( ) button... -
Page 42: P-Nr / Block Nr / Mosquito Nr
Press ACTION ( ) button [ AV ] Signal Signal 3D Y/C Filter (NTSC) Sync Auto Colour system Cinema reality Cinema reality P-NR Panasonic Auto (4:3) Block NR P-NR Mosquito NR Block NR Refresh Rate Mosquito NR [ Component ] Signal Signal Cinema reality... -
Page 43: Colour System / Panasonic Auto
To display M.NTSC signal, select “M.NTSC” in Colour system. Panasonic Auto Set to “4 : 3” to view 4:3 images in an unchanged format when Panasonic Auto is selected. (4 : 3) If you would like to view 4:3 images in Just format, set to “Just”. -
Page 44: Sync
Setup for Input Signals Sync Select Signal from the “Setup” menu during RGB input signal. Press to adjust. Press to exit from adjust mode. Setting RGB sync signal: Confi rm that the input is set to RGB input (this setting is valid only for RGB input signal). -
Page 45: Options Adjustments
Options Adjustments Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select your preferred menu. Press to adjust the menu. Press to exit from Options menu. Item Effect Weekly Command... - Page 46 Options Adjustments Item Effect Press Off: Sets normal volume. Initial VOL On: Sets your preferred volume. level Notes: • When “Maximum VOL level” is “On”, the volume can only be adjusted between 0 and your maximum range. • You can hear the changed volume regardless of your volume setting before opening the options menu if you adjust the volume when “Initial VOL level”...
- Page 47 Item Effect Enable: Enables the “Off-timer function”. Off-timer Disable: Disables the “Off-timer function”. function Enable Disable Note: When “Disable” is set, the Off-timer is cancelled. Normal Sets the power mode of the unit for when the power recovers from failure or after plugging off and in again.
- Page 48 Options Adjustments Item Effect Off: Auto: Power is transmitted to the slot power only when main power is on. Slot Power Note: In some cases, power is transmitted to the slot power when main power is on or in the standby You can set the power-on delay time of the displays to reduce the power load, when you press to turn on the multiple displays that are set together, for example, on MULTI DISPLAY system.
-
Page 49: Weekly Command Timer
Weekly Command Timer You can set 7-day timer programming by setting time and command. Note: Before setting Weekly Command Timer, set PRESENT TIME Setup. (see page 30) Press to select Function. Press to select “On”. Note: • When Function is set to On, Set up TIMER Press to select a day. - Page 50 Options Adjustments Press to select a command number. Press to show the previous / next command pages (1-8) of the selected program. Press to show the command setting screen. Weekly Command Timer Program 8:00 10:30 --:-- --:-- --:-- 12:00 9:12 --:-- Set time of timer(--:-- indicates unset) Command numbers...
-
Page 51: Shipping Condition
Shipping condition This function allows you to reset the unit to the factory setting. Press to display the Setup menu. Press to select “OSD Language”. Press and hold till the SHIPPING menu is displayed. Press to select “YES”. Press to confi rm. [from the unit] 1 Press the MENU button till the Setup menu is displayed. -
Page 52: Troubleshooting
Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Picture Interference Normal Picture No Picture No Picture No Colour No remote control operations can be performed. A cracking sound is sometimes heard from the unit. The top or bottom of the picture on the screen is cut off when I use the zoom function. -
Page 53: Component/Rgb/Pc/Video Input Signals
COMPONENT/RGB/PC/VIDEO input signals Applicable input signals for Component / RGB, Mini D-sub 15P ( Signal name 525 (480) / 60i 525 (480) / 60p 625 (575) / 50i 625 (575) / 50p 625 (576) / 50p 750 (720) / 60p 750 (720) / 50p 1,125 (1,080) / 60p 1,125 (1,080) / 60i... - Page 54 COMPONENT/RGB/PC/VIDEO input signals VIDEO input (HDMI) Vertical Horizontal Signal format frequency (Hz) frequency (kHz) 1 VGA60 59.94 2 525/60p 59.94 3 625/50p 50.00 4 750/60p 60.00 5 750/50p 50.00 6 1125/60i 60.00 7 1125/50i 50.00 8 1125/60p∗ 60.00 9 1125/50p∗ 50.00 10 1125/24p∗...
-
Page 55: Command List Of Weekly Command Timer
Audio Volume (60) DAM:FULL Aspect (16:9) DAM:JUST Aspect (Just) DAM:NORM Aspect (4:3) DAM:SELF Aspect (Panasonic Auto) DAM:ZOOM Aspect (Zoom) DWA:OFF Advanced PIP mode (OFF) DWA:OVL1 Advanced PIP mode (1) (see page 24) DWA:OVL2 Advanced PIP mode (2) (see page 24) -
Page 56: Specifi Cations
• Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate. • This equipment complies with standards listed below. AS/NZS60065, CISPRE22 Class-B TH-50PF10WK 220 - 240 V AC, 50/60 Hz 595 W Save off 0.8 W, Save on 0.6 W 0.3 W... - Page 57 Memo...
- Page 58 Memo...
- Page 59 Memo...
- Page 60 Warranty Service purposes. Model Number Matsushita Electric Industrial Co., Ltd. Web Site : http://panasonic.net © 2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.
