Gpi Control - Panasonic BT-LT2600 Menu Information

Main Menu
(continued)
GPI
The "GPI CONTROL" item is used to set enable/disenable of all GPI functions, and assigns functions to each of the
GPI terminal pins ( page 30).
Sub menu

GPI CONTROL

GPI1–GPI8
Note:
Please be aware that the following can not be performed.
• "SD ASPECT" operation when input signal is HD or PC
• "SCAN" operation when the input signal is PC
• "GAMMA SELECT" operation when the input signal is PC
• "RGB SYNC" operation when anything other than "RGB-VIDEO" is selected in "YP
SELECT" menu
• "MONO" operation when input signal is PC
26
Settings
<DISENABLE>
<ENABLE>
<UNDEF>
<MARKER1 ON/OFF>
<MARKER2 ON/OFF>
<MARKER BACKHALF>
<MARKER BACKBLACK >
<CENTER MARKER>
<INPUT SEL. VIDEO>
<INPUT SEL. Y/C>
<INPUT SEL. SDI1>
<INPUT SEL. SDI2>
<INPUT SEL. YP P /RGB>
B R
<SD ASPECT>
<SCAN>
<R-TALLY>
<G-TALLY>
<MONO>
<GAMMA SEL. FILM>
<GAMMA SEL. STDIO/
PST>
<RGB SYNC>
The underlined values are factory preset setting values.
Explanation
GPI functions enable/disenable settings
Used to set the GPI control terminal pin assign.
You can set the same items for each terminal
(refer to page 30 for details).
P /RGB" in the "INPUT
B R
