LVP8601 User Manual Chapter 1: Safety precautions Danger! There is high voltage in the processor, to prevent any unexpected hazard, unless you are a maintenance personnel, please do not open the cover of the device. Warning! 1. This device shall not encounter water sprinkle or splash, please do not place anything containing water on this device.
LVP8601 User Manual 2) The device is dropped down or cabinet is damaged. 3) Obvious malpractice is found or performance degrades. Chapter 2: Item list Please unpack the product with care, and then check whether all the following items are included in the package. If anything is found missing, please contact the dealer.
3-2 Rear view Figure 3-1 Rear view 3-3 Port description 1. Input ports LVP8601 maximally supports 4 PCS of input cards (In-A, In-B, In-C, In-D) and each card supports 4 input signals. The port description is as follows: www.videowall.cn...
1 X DVI (HDMI1.3 compatible) 1 X SDI(SDI/HDSDI/3G-SDI) 2. Output ports LVP8601 maximally supports 2 PCS of output cards (Out-K, Out-L) and each card supports 4 DVI outputs. The port description is as follows: Port Description 8X DVI output ports (for connecting to...
LVP8601 User Manual 3-5 Specifications Inputs 4×Video 4×VGA(RGBHV) Type/Number 4×DVI(VESA/CEA-861) 4×SDI (SDI/HD-SDI/3G-SDI) Video Standard PAL/NTSC Composite Video 1V (p_p)/ 75Ω Amplitude / Impendence VGA Format PC (VESA) ≤1920×1200@60Hz Amplitude R、G、B = 0.7 V (p_p) / 75Ω Impendence PC (VESA) ≤1920×1200@60Hz DVI Format HDMI-1.3 (CEA-861)
LVP8601 User Manual Chapter 4: Front Panel 4-1 Button instruction Figure 4-1 1. Input Cards (In-A, In-B, In-C, In-D): stand for 4 input cards accordingly, when pressing a button to select a card, if the red light of the indicator is on, it means the operation of the current input card is valid.
Page 10
LVP8601 User Manual Image output channel (CH), in the system of this device, is also interpreted as “image layer”. The device can maximally offer 4 image layers (CH1, CH2, CH3, CH4) which can be overlapped. 7. CH Sources (In1, In2, In3, In4): input channel select for image layer, the indicator green light is on when a channel is selected.
Chapter 5: Function introduction LVP8601 can maximally support 4 pcs (In-A ,In-B, In-C, In-D) of video input cards (each card includes 1 X SDI, 1 X DVI, 1 X VGA and 1 X Video) or 2 pcs of single DVI straight-through cards and 2 pcs of output cards.
Page 12
LVP8601 User Manual Out1 Out2 Out3 Output Out4 Matrix In-A Output(Out-K) In-B In-C Out1 In-D Out2 Main Out3 Matrix ( MatrixK Output Out4 /MatrixL) Matrix Main Board Output(Out-L) Figure 5-1 As shown in the figure, CH1, CH2, CH3 and CH4 stand for 4 internal image output channels or image layers in the output card.
LVP8601 User Manual 5-1 Configuration mode 1 Out1 Out 2 Out 3 Output Out 4 Matrix Config_Mode1 Figure 5-2 In this mode, Out1=CH1 Out2= CH2 Out3 = CH3 Out4 = CH4 This means: Output port 1 (Out1) outputs image from image layer 1 (CH1)
Page 14
LVP8601 User Manual Out1 Out 2 Out 3 Output Out 4 Matrix Config_Mode1 derivation mode 1 Figure 5-3 Out1 Out 2 Out 3 Output Out 4 Matrix Config_Mode1 derivation mode 2 Figure 5-4 Out1 Out 2 Out 3 Output Out 4...
In this mode, input images can be cropped as output images for Out1, Out2 and Out3. By using this mode, the LVP8601 will be mainly used as a switcher of 4 inputs and 3 outputs with seamless or fade effect.
In this mode, we can also press “Fade” to set the time for switching of image layers so as to realize seamless switching or fade effect. By using this mode, LVP8601 will be used for triple-image display from single output plus single-image preview or as a switcher of single output plus single-image preview.
Out1 and Out2 are blended into a complete one and the display is completely synchronous. By using this mode, LVP8601 will be used for pixel-to-pixel sync image mosaic and the maximal resolution supported is 4K x 2K.
What we need to do is just to start “preview” in advanced settings of output card. By using this mode, LVP8601 will be used as a quad-display processor or a switcher of single output with fade effect. www.videowall.cn...
In this mode, we can also press “Fade” to set the time for switching of image layers so as to realize seamless switching or fade effect. By using this mode, LVP8601 will be used as a dual-display processor of dual outputs or a dual-output switcher. It can be also used for matrix (4X2) switching with fade effect or pixel-to-pixel HD background image plus cross-screen PIP display.
LVP8601 User Manual Chapter 6: Basic operation introduction When system starts, it will automatically detect and identify the number and location of input cards and output cards. The LCD panel will display the information accordingly. The introduction of basic operations is based on full...
LVP8601 User Manual 6-5 Overlap mode setup When the indicator for “Overlap” is on and that for “Matrix” is off, press “CH1, CH2, CH3 or CH4” to select one as the top layer, this will change the overlapping relationships. The setup is only available in configuration mode 6.
LVP8601 User Manual modes is “Single Card/Single Card+Input Card/Double Card/Double Card+Input Card” and it is displayed in the second line on the menu. The invocation sequence “Overlap→Matrix→Size/Matrix→Size→Overlap” and it is displayed in the third line on the menu. 6-8 Configuration mode setup Press “Setup”...
LVP8601 User Manual 6-9 Brightness setup The adjusting range of brightness is 0-32 , “0” stands for the lowest brightness, press “Brt+” to increase the brightness or “Brt-” to lower it. To make sure of the complete grey level of the output images, the default is set as “32”...
LVP8601 User Manual are available in case of the conflict between remote control and panel control. When commands are sent from remote, buttons will be automatically locked. The menu is as follows: Button Lock -------------------------------------- Button Invalid LAN Valid RS232 Valid...
LVP8601 User Manual Chapter 7: User settings User settings, which are used to setup the overall system, consist of 3 parts: input card, output card and the system. On the default menu, when system starts, press “Setup” to enter the menu of “User Settings” and “↑,↓” to select settings, press “OK”...
Page 26
LVP8601 User Manual In-A Setup -------------------------------------- 1.Main Setup 2.PIP Setup 3.Image Setup 4.Advanced Setup -------------------------------------- Figure 7-2 Press “↑,↓” to select the setting, turn the knob to adjust and then press “OK” to confirm. Input Card Main Setup In-A -------------------------------------- 1.Hori Width...
Page 27
LVP8601 User Manual Press “↑,↓” to select the setting, turn the knob to adjust and then press “OK” to confirm. Input Card PIP Setup In-A -------------------------------------- 1.Hori Width 666 -> 888 2.Hori Start 3.Vert Height 4.Vert Start -------------------------------------- Figure 7-5 3.
Page 28
LVP8601 User Manual Input Card Image Setup In-A -------------------------------------- 1.Brightness 2.Contrast 3.Color 50 –> 56 4.Reset -------------------------------------- Figure 7-7 The adjusting range of brightness, contrast and color is 0-100. Brightness adjusting is only valid for the selected input card, if the adjusting is wrong, press “Reset”...
Page 29
LVP8601 User Manual Input Card Advance Setup In-A -------------------------------------- 1.Text Mode >Threshold 2.Text R 3.Text G 8 –> 12 4.Text B 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-9 2) Refresh data On the menu of “Input Card Advanced Setup”, press “↑,↓” to select “Refresh data”...
LVP8601 User Manual Input Card Advance Setup In-A -------------------------------------- 1.Text Mode >Threshold 2.Text R 3.Text G 8 –> 12 4.Text B 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-11 When entering the sub menu of “Reset Data”, press “OK” to start to reset.
Page 31
LVP8601 User Manual Setup -------------------------------------- 1.Input Card Setup 2.Output Card Setup 3.System Setup -------------------------------------- Figure 7-13 1. Set the size and location of input image for output card On the menu of “Output Card Setup”, press “↑,↓” to select “Input Image Setup”...
Page 32
LVP8601 User Manual 2. Set the size and location of output image for output card On the menu of “Output Card Setup”, press “↑,↓” to select “Output Image Setup” and then “OK” to enter the sub menu. Out-K Setup -------------------------------------- 1.Input Image Setup...
Page 33
LVP8601 User Manual Out-K Setup -------------------------------------- 1.Input Image Setup 2.Output Image Setup 3.Border Setup 4.Advanced Setup -------------------------------------- Figure 7-18 Press “↑,↓” to select the setting, turn the knob to adjust and then press “OK” to confirm. Output Border Setup Out-K/CH1 -------------------------------------- 1.Border...
Page 34
LVP8601 User Manual “OK” to confirm. Output Card Clock Setup Out-K/CH1 -------------------------------------- 1.Frame Sync 2.System Clock Main Board -------------------------------------- Figure 7-21 Notice: “Clock Setup” is only used in pixel-to-pixel image mosaic (configuration mode 4), when the properties of edge blending are set, if the display is out of sync, please set “Frame Sync”...
Page 35
LVP8601 User Manual Output Card Edge Blending Setup Out-K/CH1 -------------------------------------- 1.Direct Vert 2.Position Left/Up 3.Start -------------------------------------- Figure 7-23 6. Advanced setup On the menu of “Output Card Setup”, press “↑, ↓” to select “Advanced Setup” and “OK” to enter the sub menu. Press “Out-K” or “Out-L” to select the output card and press “CH1, CH2, CH3 or CH4”...
Page 36
LVP8601 User Manual Output Card Advanced Setup Out-K -------------------------------------- 1.Config Mode 6 –> 7 2.Preview 3.Auto Detect 4.CH Reset 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-25 On the sub menu of “Config Mode”, press “OK” to confirm. Tips -------------------------------------- Data will reset Press <OK>...
Page 37
LVP8601 User Manual Output Card Advanced Setup Out-K -------------------------------------- 1.Config Mode 2.Preview 3.Auto Detect 4.CH Reset 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-27 Notice: when “Preview” is on, only Out1 will output a quad-image preview and there will be no outputs from Out2, Out3 or Out4.
Page 38
LVP8601 User Manual Output Card Advanced Setup Out-K -------------------------------------- 1.ConfigMode 2.Preview 3.AutoDetec 4.CH Reset 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-29 Notice: input signals for output cards will be briefly unstable when using DVI straight-through cards or making changes in “MatrixK Setup”...
LVP8601 User Manual Output Card Advanced Setup Out-K -------------------------------------- 1.Config Mode 2.Preview 3.Auto Detect 4.CH Reset 5.Refresh Data 6.Reset Data -------------------------------------- Figure 7-31 On the sub menu of “Reset Data”, press “OK” to start to reset. Tips -------------------------------------- Data will reset.
Page 40
LVP8601 User Manual Setup -------------------------------------- 1.Input Card Setup 2.Output Card Setup 3.System Setup -------------------------------------- Figure 7-33 1. IP address On the menu of “System Setup”, press “↑,↓” to select “IP Setup” and “OK” to enter the sub menu. System Setup -------------------------------------- 1.IP Setup...
Page 41
LVP8601 User Manual 2. Subnet mask address On the menu of “System Setup”, press “↑,↓” to select “MASK Setup” and “OK” to enter the sub menu. System Setup -------------------------------------- 1.IP Setup 2.MASK Setup 3.GATE Setup 4.MAC Setup 5.MatrixK Setup 6.MatrixL Setup 7.Advanced Setup...
Page 42
LVP8601 User Manual System Setup -------------------------------------- 1.IP Setup 2.MASK Setup 3.GATE Setup 4.MAC Setup 5.MatrixK Setup 6.MatrixL Setup 7.Advanced Setup -------------------------------------- Figure 7-38 Press “↑,↓” to select the setting, turn the knob to adjust and then press “OK” to confirm.
Page 43
LVP8601 User Manual Press “↑,↓” to select the setting, turn the knob to adjust and then press “OK” to confirm. MAC Setup -------------------------------------- 1.Address1 2.Address 2 3.Address 3 4.Address 4 5.Address 5 6.Address 6 -------------------------------------- Figure 7-41 5. Matrix setup for Out-K (MatrixK) On the menu of “System Setup”, press “↑,↓”...
Page 44
LVP8601 User Manual MatrixK Setup -------------------------------------- 1.K-In1 In-A 2.K-In2 In-B 3.K-In3 In-C 4.K-In4 In-D -------------------------------------- Figure 7-43 6. Matrix setup for Out-L (MatrixL) On the menu of “System Setup”, press “↑,↓” to select “MatrixL Setup” and “OK” to enter the sub menu.
Page 45
LVP8601 User Manual Notice: the signal from Out1 of Out-K can be selected as the input for L-IN1, L-IN2, L-IN3 or L-IN4 of Out-L for a 7-picture preview. 7. Advanced setup On the menu of “System Setup”, press “↑,↓” to select “Advanced Setup”...
Page 46
LVP8601 User Manual System Advance Setup -------------------------------------- 1.Language 语言 English 2.Out Format 1920x1080_60Hz 3.Reset Data -------------------------------------- Figure 7-48 On the sub menu of “Out Format”, press “OK” to confirm. Tips -------------------------------------- Data will reset. Press <OK> to reset Press <return> to cancel...
Normally it is not suggested to use. Chapter 8: Copyright information The copyright of this manual is owned by SHENZHEN VDWALL CO., LTD., unless with prior consent of VDWALL, nobody is permitted to copy or use any part or all of the information contained herein.
