Operating Instructions

PLEASE READ BEFORE USE AND
SAVE.
KX-TGA200B is the optional cordless
handset for the KX-TG2000B. These
operating instructions cover most of the
features of this cordless handset.
Please read the KX-TG2000B operating
instructions for further details.
Installation ................................... 1
Location of Controls..................... 2
Making Calls ................................ 3
Answering Calls........................... 4
Intercom....................................... 4
Transferring a Call ....................... 4
in the Directory ......................... 5
Caller ID Service.......................... 6
Viewing the Caller List ................. 7

Installation

Connecting the AC adaptor to the charger
Power Outlet
(AC 120 V, 60 Hz)
AC Adaptor
• USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G).
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to
feel warm during use.)
Printed in Japan
2.4GHz Cordless Handset
Model No.
Accessories (included)
For extra orders,
call 1-800-332-5368
Charger .................one
AC Adaptor............one
Order No. KX-TCA1-G
Belt Clip.................one
Order No. PQKE10101Z1
Contents
Voice Mail System ....................... 7
Listening to Messages................. 9
Tone Phone ..............................10
Wall Mounting..............................11
Using the Belt Clip .......................12
Battery Replacement ...................12
Bottom
of the
charger
Fasten the AC adaptor
cord to prevent it from
being disconnected.
PQQX12632ZA
- 1 -
KX-TGA200B
SS0300NA0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KX-TGA200B and is the answer not in the manual?

Questions and answers

Charles Stone
January 29, 2025

How to set correct time on KX-TGA200B

0

Related Manuals for Panasonic KX-TGA200B

Summary of Contents for Panasonic KX-TGA200B

  • Page 1: Table Of Contents

    Power Outlet (AC 120 V, 60 Hz) AC Adaptor • USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G). • The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) Printed in Japan 2.4GHz Cordless Handset...

  • Page 2: Charging The Battery

    ” flashes on the display, or – the handset beeps intermittently while it is in use. Handset battery information After your Panasonic battery is fully charged: Operation While in use (TALK) While not in use (Standby) • Clean the charge contacts of the handset and the charger with a soft, dry cloth once a month.

  • Page 3: Registering Cordless Handsets

    Registering Cordless Handsets Registration is necessary for cordless handsets. A handset will be assigned the number at registration. The handset number is used as the extension number (p. 4, 8). You can register up to 8 cordless handsets at the KX-TG2000B base unit.

  • Page 4: Answering Calls

    Answering Calls Two calls can be handled simultaneously by the base unit and a cordless handset (or by 2 cordless handsets). Press (TALK) • You can press the called line button instead of pressing TALK • You can also answer a call by pressing any dialing button (0) to (9), (*) or (#).

  • Page 5: Storing Names And Numbers In The Directory

    Storing Names and Numbers in the Directory You can store names and phone numbers in the directory. The cordless handset can store up to 50 items. All directory items are sorted by the first word in alphabetical order. Using the directory, you can make a call by selecting a name on the display.

  • Page 6: Dialing From The Directory

    Dialing from the Directory Press I or H to enter the directory. Press to find the desired item. To search for a name by initial: Press the dialing button for the first letter of the desired name until any name with the same initial is displayed. Press displayed.

  • Page 7: Viewing The Caller List

    Viewing the Caller List If you have received new calls, “Received calls” will be displayed in the standby mode. Caller List information includes the caller’s name and phone number, the time and date the call was received. Make sure that the cordless handset is in the standby mode. Press to enter the list.

  • Page 8: Setting The Mailbox Password

    You can use the Voice Mail System by accessing your mailbox. Each cordless handset user can only access his/her own mailbox. The general delivery mailbox is managed by the base unit user (operator). The cordless handset users can access this mailbox. You can also access the Voice Mail System features remotely from a touch tone phone.

  • Page 9: Setting The Handset Answer Mode

    Setting the Handset Answer Mode If you turn ON the answer mode of your handset, calls will be greeted with a greeting message (see on the right) and callers can leave messages in your mailbox. To take calls, leave this mode OFF (factory preset).

  • Page 10: Delivering Your Own Message

    Delivering Your Own Message You can send an identical message to several mailboxes. Press • If the direct handset access mode is OFF (p. 8), enter the mailbox password and press • If you have new messages, listen to all of them. Press Enter the destination mailbox numbers using the...

  • Page 11: Wall Mounting

    Using an Optional Headset Plugging an optional headset into the cordless handset allows a hands-free phone conversation. Please use only a Panasonic KX-TCA88 headset. To order, call the accessories telephone number on page 1. Connecting the headset to the cordless handset Open the headset jack cover, and connect the headset to the headset jack as shown.

  • Page 12: Using The Belt Clip

    To attach the belt clip Battery Replacement If “Recharge” is displayed and/or “ fully charged, replace the battery with a new Panasonic HHR-P506 (PQHHR150AA21) battery. To order, call the accessories telephone number on page 1. Remove the cover by sliding while pressing the arrow.

  • Page 13: Fcc And Other Information

    — Consult the dealer or an experienced radio/TV technician for help. Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way, Secaucus, New Jersey 07094 Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc.
