Zavio P5110 Quick Installation Manual

Day/night pan/tilt ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Steps
Please follow the installation steps below to set up your P5110 / P5115 Day/Night Pan/Tilt IP Camera.
Check the package contents against the list below. See P.1
Use the software CD to install Intelligent IP Installer.
Change lighting environment setting. See P.7
Access to Internet via Static IP, Dynamic IP or both. See P.10
For more information, please check the User Manual available in the Software CD or you can download the latest
software from
http://www.zavio.com
Package Contents
Camera
Quick Installation Guide
Software CD
Component Pack
Adaptor
Quick Installation Guide
Camera
TAZavio P5110 / P5115 Quick Installation Guide
P5110 / P5115 Day/Night Pan/Tilt IP Camera
Brief product information and quick installation
IP Surveillance Software
Intelligent IP Installer
User Manuals
Language Packs
Bracket, two packs of screws , Antenna (P5115 model)
12V DC, max 12W
See P.4
1
Software CD
Component Pack

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P5110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zavio P5110

Summary of Contents for Zavio P5110

  • Page 1: Table Of Contents

    TAZavio P5110 / P5115 Quick Installation Guide Installation Steps Please follow the installation steps below to set up your P5110 / P5115 Day/Night Pan/Tilt IP Camera. Check the package contents against the list below. See P.1 Physical Overview. See P.2 Install the hardware and connect all cables.

  • Page 2: Physical Overview. See

    Physical overview  Focus Adjustment Ring - Adjust focus manually to achieve the best image quality  Infrared LEDs - Infrared LEDs for night use up to 15 working distance  Wireless Antenna (for P5115) - For connection of IEEE 802.11 b / g wireless network. ...

  • Page 3: Install The Hardware And Connect All Cables. See

    - Using a standard RJ-45 network cable, connect the IP Camera to a normal Hub / Switch / Router. b2. Power over Ethernet (PoE) (P5110 Model ) - Using a standard RJ-45 network cable, connect the IP Camera to a PoE-enabled Hub / Switch / Router.

  • Page 4: Microsoft Os

    Use the software CD to install Intelligent IP Installer Microsoft OS: Power on your PC and insert the CD-ROM. The setup page will show up automatically. Please follow those steps to install the firmware. Select “Intelligent IP Installer” and follow Access the IP Camera using Intelligent IP Installer 1.
  • Page 5 4. When accessing the IP Camera for the first time, a yellow information bar appears below the address bar: This website wants to install the following add-on: ‘AxvideoView.cab from ‘Zavio Inc’. 5. Click the information bar, and select Install ActiveX control.

  • Page 6: Mac Os Using Safari Browser. See

    Mac OS using Safari Browser 1. Select Safari icon 2. Click Bonjour function and select the camera you wish to access. 3. Enter name and password to login t o the IP camera. (Default is admin / admin) 4. The monitor image will be displayed in your browser.

  • Page 7: Change The Web Interface Into Your Preferred Language. See

    Select Safari function → Enter IP address in the web link → enter username and password (default value dmin/admin) → The Zavio user interface and Live Image will show up in the middle of the screen. 2. Mobile phone viewing a.

  • Page 8: Wireless Setting.( P5115 Model ). See

    b2. Browser viewing For 2.5G mobile phone browser viewing, type “http:// <IP>/mobile.htm ” into your 2.5G web browser. Wireless Setting (P5115 Model) Power the IP Camera and connect an Ethernet network cable to the IP Camera’s LAN port. Using Intelligent IP Installer and entering the camera’s setting page.
  • Page 9 3. Under the IP Notification Option, Click “On” to enable IP notification to the users. 4. Under the Privacy Option, Click “On” to create an allow list. 5. Use your existing account to login to MSN Messenger. 6. Add the new MSN Messenger account for IP Camera (e.g.: Camera at home@hotmail.com) to your contact 7.
  • Page 10 Access to the Internet a. Internet connectivity of the IP camera can be established by inputting the cameras IP information within the Information section. (Please go to Setting → Basic → Network→ Information) Internet Connectivity of the IP Camera can be established through PPPoE (Point-to-Point Protocol over the Ethernet) by inputting the username and password from your Internet Service Provider (ISP) within the PPPoE (Please go to Setting →...
  • Page 11 c. Internet Connectivity of the IP Camera can be established if your router is UPnP (Universal Plug and Play) enabled The IP camera is automatically detected and added to “My Network P laces” on your computer. Please note that only Home Routers manufactur ed after 2006 support the UPnP function.

  • Page 12: Application Of Ip Camera See

    Application of IP Camera...
  • Page 13 Memo ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. ………………………………………………………………………………….. …………………………………………………………………………………..
