Model shown is KX-TG6431.
Panasonic's environmental declaration labels
This mark is an environmental label
showing that the products are certified
as Panasonic's Green Products.
Standby power consumption
reduced by 59%
Thank you for purchasing a Panasonic product.
This unit is compatible with Caller ID. You must subscribe to the appropriate
service offered by your service provider/telephone company.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save
them for future reference.
For assistance, visit our website:
http://www.panasonic.com/help for customers in the U.S.A. or Puerto
Rico.
Consulte "Guía Rápida Española", página 52.

Operating Instructions

Expandable Digital Cordless Answering System
KX-TG6431
Model No.
KX-TG6441
with 2 Handsets
KX-TG6432
Model No.
KX-TG6442
with 3 Handsets
KX-TG6433
Model No.
KX-TG6443
with 4 Handsets
KX-TG6434
Model No.
KX-TG6444
with 5 Handsets
KX-TG6445
Model No.
