BSCKB1-120081
120VAC, 8A Speed Controller with
Integrated Speed Pot and Function
Switches
User's Guide
A N A H E I M
A U T O M A T I O N
910 East Orangefair Lane, Anaheim, CA 92801
(714) 992-6990 fax: (714) 992-0471
e-mail: info@anaheimautomation.com
website: www.anaheimautomation.com
L011088
1
August 2013
Advertisement
Table of Contents
Related Manuals for Anaheim Automation BSCKB1-120081
Summary of Contents for Anaheim Automation BSCKB1-120081
- Page 1 BSCKB1-120081 120VAC, 8A Speed Controller with Integrated Speed Pot and Function Switches User’s Guide A N A H E I M A U T O M A T I O N 910 East Orangefair Lane, Anaheim, CA 92801 (714) 992-6990 fax: (714) 992-0471 e-mail: info@anaheimautomation.com...
-
Page 2: General Description
• Integrated Power, Brake and Direction Switches General Description The BSCKB1-120081 is a speed controller that has the MDCKB1-120081 driver integrated inside and is designed to drive DC Brushless motor at currents of up to 8A (peak) and 160V. The drive is protected against over current (cycle-by-cycle), hall sensor error and under voltage. -
Page 3: Specifications
Specifications Output Current Rating: Adjustable 2.0 - 8.0 amperes per phase maximum operating peak current (1.0 - 4.0 amperes per phase maximum operating continuous current) Power Requirements: 85VAC (min) - 135VAC (max) Operating Temperature: Driver Heat Sink: 0° - 70°C Hall Sensor Power Output: 6.25V @ 30mA maximum. -
Page 4: Motor Connection
Motor Connection Refer to the hookup diagram for typical driver applications. When connecting a motor for the first time, connect the hall sensor wires (5 of them) to the appropriate spot on the terminal block. DO NOT CONNECT THE PHASES YET. Turn on power and rotate the motor by hand, check to see if the red fault light comes on (Be sure to do this while the cover is off so that you can see the red fault light). -
Page 5: Motor Direction
Speed Adjust Setting The maximum speed of the motor is set by adjusting R17. The minimum speed of the motor is set by adjusting R25. The speed potentiometer is used to adjust the motor speed between the set minimum and maximum speed. Motor Run/Brake The motor run/brake switch allows the stopping or braking of a motor by shorting out the bottom drives of the three phases. -
Page 6: Hookup Diagram
Quick Disconnect/Potentiometer Location POT# Description CLADJ RAMP Max Speed Current Limit Min Speed Hook-Up Diagram L011088 August 2013... -
Page 7: Internal Wiring Diagram
Internal Wiring Diagram L011088 August 2013... - Page 8 Anaheim Automation will repair or replace at its’ option, any product which has been found to be defective and is within the warranty period, provided that the item is shipped freight prepaid, with previous authorization (RMA#) to Anaheim Automation’s plant in Anaheim, California.
