- Page 1 Digital Copier Operating Instructions (For Copier) Model No. DP-150FP Options DA-DS150 DA-SM16B DA-DS150 (Option) Before operating this copier, please read these instructions completely and keep these operating instructions for future reference. English...
-
Page 2: Common Features Full Size Copying
Operation Chart Common features Full Size Copying Automatic Document Feeder Turn the Power Switch ON. (See page 9) Load the paper (See page 21) How to copy without using ADF (Automatic Document Feeder). Position of the original FLS B4 When manually selecting exposure control: PHOTO AUTO DARKER... -
Page 3: Overview
For example: how to make copies, add paper, replace the toner cartridge, etc.. <2nd bin for C> Use the information provided in the DP-150FP Facimile Operating Instructions manual whenever a fax function requires intervention. For example: how to send/receive a fax, or when a trouble message appears, etc.. -
Page 4: Energy Star
These copiers will automatically “power down” after a specified period of non-use. The use of these Energy Star compliant copiers will reduce energy consumption and ultimately benefit the environment. The default functions can be adjusted depending on your office requirements. Please see your authorised Panasonic copier dealer for more details. -
Page 5: Table Of Contents
Table of Contents Before Operation Overview ... 3 Precautions ... 6 Components External/Internal ... 9 Control Panel ... 10 Mode Functions ... 12 Features ... 13 Making Copies Common features Full Size Copying ... 2 Reduction or Enlargement Copying ... 14 Zoom Copying ... -
Page 6: Precautions
Precautions For your safety Laser Safety LASER SAFETY This unit employs a laser. Only qualified service personnel should attempt to service this device due to possible eye injury. Caution This product utilizes a laser. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. - Page 7 High quality paper of 60 – 90 g/m via sheet bypass) may be used. For optimum copy quality, it is essential that Panasonic Brand Toner is used in the copier. The copier should not be installed in areas with the following conditions: Extremely high or low temperature and humidity.
- Page 8 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR OFFICE THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
-
Page 9: Components External/Internal
Components Using the Sheet Bypass External Exit Tray Control Panel Pull out the tray when copying. Power Switch Paper Tray (See page 21, 22) Internal Knob (See page 26) Toner Cartridge Drum Unit (See page 23) (See page 24) ADF (Automatic Document Feeder) Please push here when closing Right Cover. -
Page 10: Control Panel
Components Control Panel Function keys for making copies. (Function keys for fax, please see fax instruction.) Copy Key Communications Monitor 2 in 1 Copy Mode Indicator (See page 17) Data Indicator ON LINE Indicator Paper Misfeed Indicator (See page 25-28) Sort Key (See page 18) 2SIDED... - Page 11 Message Display REDIAL/ PAUSE FLASH/ SUB-ADDR DIRECTORY abc.. FUNCTION SEARCH MONITOR Set Key By pressing Exposure Control key, the Exposure Indicator will be indicated as follows. Darker Lighter Energy Saver Key ENERGY SAVER CLEAR/STOP START PQRS WXYZ TONE -/() Keypad Start Key Normal DARK...
-
Page 12: Mode Functions
Power consumption will drop and the Energy Saver key indicator will light. $ To cancel this mode. Press Energy Saver key. If you wish to change the above settings or if you need more information, call your Panasonic authorised dealer. Power Consumption... -
Page 13: Features
Features Features List Reduction or Enlargement Copying (See page 14) Zoom Copying Digital skyshot 2 in 1 copy Sorting Copying with preset ratios. (See page 15) Copying with variable zoom ratios. (See page 16) Copying from small originals without dark areas around the image. (See page 17) Copying from two 1-sided originals, side by side, to 1-sided copies. -
Page 14: Reduction Or Enlargement Copying
Common features Reduction or Enlargement Copying There are 3 preset reduction and 1 preset enlargement modes. COPY ON LINE Position Press Copy original SELECT Example: Reduction Original size The correct ratio is automatically selected. To cancel reduction or enlargement copy, press RESET Key. -
Page 15: Zoom Copying
Zoom Copying A zoom ratio can be selected from 50% to 200% in 1% increments. 2SIDED SORT COPY 2 in 1 PHOTO AUTO DATA DARKER ON LINE LIGHTER Paper Tray Key Position Press Copy original ZOOM DIRECTORY abc.. SEARCH (50~200%) When copy size is different from paper size of paper tray, select sheet bypass NOTE by pressing Paper Tray key and place the paper into the sheet bypass. -
Page 16: Creative Features Digital Skyshot
Creative Features Digital skyshot To copy from the platen with ADF open. Making copies from small originals without dark areas around the image. The Digital Skyshot mode is normally set on. If the mode is not set, please use the following procedure. COPY ON LINE Set original... -
Page 17: In 1 Copy
2 in 1 Copy For 2 in 1 copying. 2SIDED SORT COPY 2 in 1 PHOTO AUTO DATA DARKER ON LINE LIGHTER Set originals Press Copy in ADF tray How to set original to ADF Face-Up Press H key to select the 2 Sided Copy mode 2 in 1... -
Page 18: Sorting
Creative Features Sorting Multiple copies to be sorted automatically. COPY ON LINE When using ADF Set originals Press Copy in ADF tray When setting original to the platen Set original Press Copy to the platen When the copy of the first original is finished, set the next original Sorting is. -
Page 19: Using The Sheet Bypass
Using the Sheet Bypass To copy on letterhead, mailing labels, transparencies and odd-size paper, etc., or to use bypass as an additional paper source. Tray Side Guides When using double sided copies, do not set more than 25 (80 g/m NOTE bypass. -
Page 20: Option
Option Option 2nd Paper Feed Module (DA-DS150) Available to add 250-sheet paper tray. For installation, see the Installation Instructions provided. For setting and changing paper size, see page 22. 2nd Paper Feed Module (DA-DS150) The illustration is the main unit with optional 2nd Paper Feed Module. -
Page 21: Handling Adding Paper
Handling Adding Paper Use the following steps to add paper. Special papers, like glossy paper, mailing labels and transparencies cannot be NOTE used in the paper tray. Use bypass for special paper. When making double sided copies, use the sheet bypass. If the paper tray is not closed completely, the Add Paper Indicator in the control panel will light up. -
Page 22: Changing Paper Size
Handling Changing paper size Following is the procedure to change paper size of paper tray from the control panel. This procedure is also same for optional 2nd Paper Feed Module. COPY ON LINE Press Copy Press “3” Key Press “1” or “2” Key Select paper size by Keypad After changing paper size from the control panel, change the paper size... -
Page 23: Changing Toner Cartridge
Button Sheet Bypass Do not stand the toner cartridge on end! Handle For optimum copy quality use the recommended Panasonic toner cartridge. ATTENTION Store toner cartridge in a cool dark place. Install toner cartridge immediately after unsealing. # Open the sheet bypass. -
Page 24: Changing Drum Unit
Message will appear in the message display when needs to change drum unit. For optimum copy quality use the recommended Panasonic drum unit. Store ATTENTION drum unit in a cool dark place. Do not unseal drum unit before use. Use it as fast as possible after unsealing. -
Page 25: Removing A Paper Misfeed (Main Unit)
Removing a Paper Misfeed (Main Unit) Paper transport and paper entry areas 2SIDED SORT 2 in 1 PHOTO AUTO SELECT DATA DARKER PAPER TRAY LIGHTER Right Cover Button Sheet Bypass Make sure that the misfeed indicator goes off after removing a paper misfeed. ATTENTION The misfeed indicator will not go off if the paper is still jammed in the copier. - Page 26 Handling Removing a Paper Misfeed (Main Unit) Paper exit area 2SIDED 2 in 1 Make sure that the misfeed indicator goes off after removing a paper misfeed. ATTENTION The misfeed indicator will not go off if the paper is still jammed in the copier. Check again and remove all misfed paper.
-
Page 27: Removing An Original Misfeed (Adf)
Removing an Original Misfeed (ADF) ADF (Automatic Document Feeder) area 2SIDED SORT 2 in 1 PHOTO SELECT AUTO DATA DARKER LIGHTER Paper Feed Cover Paper Feed Cover Make sure that the misfeed indicator goes off after removing a paper misfeed. ATTENTION The misfeed indicator will not go off if the paper is still jammed in the copier. -
Page 28: Removing A Misfed Paper (2Nd Paper Feed Module)
Handling Removing a Misfed Paper (2nd Paper Feed Module) 2nd Paper Feed Module area ATTENTION 2SIDED SORT 2 in 1 PHOTO ZOOM SELECT AUTO (50~20 DATA DARKER PAPER TRAY LIGHTER Right Cover Button Sheet Bypass Make sure that the misfeed indicator goes off after removing a paper misfeed. - Page 29 Add paper to the sheet bypass and press Start. Turn copier power switch off, then back on. If error code comes back again, call your Panasonic authorised dealer. Refer to the Information Codes of the Operating Instructions (For Facsimile) on page 89.
-
Page 30: Checking Troubleshooting
Checking Troubleshooting Copies are light Does the exposure indicator say “light”? Does the add toner indicator appear? Light image on the front side of copier Copy Image Sample Direction of paper exit If the measures outlined above do not solve the problem, call your Service provider. Cleaning As a rule, clean once a week. - Page 31 When copies become unclear, clean the Corona by following procedure. A B C D E F Right Cover Button Sheet Bypass Correct Wrong Handle Line images in the copy. (Sample) # Open the sheet bypass. $ Push the button. % Open the right cover. &...
-
Page 32: Specifications
Specifications Copier Functions Main unit Type: Copy/Print Process: Process: Resolution: Multi-Copy Speed: Maximum Copy Size: Copy Size: Reduction Ratios: Enlargement Ratios: Paper Feed: Quantity Selector: Paper Weight: Exposure Control: Dimensions: Weight: Electrical Requirements: ADF (Automatic Document Feeder) Original Capacity: Paper Size: Paper Weight: Electrical Requirements: Dimensions:... -
Page 33: Consumables List
Consumables List Consumables List When ordering consumables, please use the correct part number as listed below. Consumable Name Part Number Toner Cartridge DQ-UG15A Drum Unit DQ-UH32A Based on copying a A4 size 6% image area original. Note: To see total count of copies, press and hold % Select key, then press CLEAR/STOP key. To print total count of copies, press and hold % Select key, then press START key. -
Page 34: Important Information
IMPORTANT INFORMATION When requesting information, supplies or service always refer to the model and serial number of your machine. The model and serial number plate (Main Name Plate) is located on the rear side of machine. For your convenience, space is provided below to record information you may need in the future. Model No.
