KAC-819
Audio Section
General
KENWOOD
follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.

SPECIFICATIONS

Max Power Ouput (4Ω) .................................................................................... 300W
Max Power Ouput (2Ω) .................................................................................... 450W
Rated Power Output (4Ω)
(20Hz ~ 200Hz, 0.08% THD) ....................................................................... 150W
(DIN45324, +B =14.4V) ................................................................................ 150W
Rated Power Output (2Ω)
(100Hz, 0.8% THD) ...................................................................................... 230W
Signal to Noise Ratio ...................................................................................... 100dB
Sensitivity (MAX) (rated output) ......................................................................... 0.2V
Sensitivity (MIN) (rated output) .......................................................................... 5.0V
Input Impedance .............................................................................................. 10kΩ
Low Pass Filter (18dB/oct.) ................................................................ 50Hz ~ 200Hz
Infrasonic Filter (18dB/oct.) .......................................................................... 15/25Hz
Bass Boost Circuit (90Hz) ........................................................................... 0,6,12dB
Damping Factor ........................................................ over 2000 (at Sigma Connect)
Operating Voltage (11V ~ 16V allowable) ....................................................... 14.4V
Current Consumption ................................................................. 21A at rated power
Dimensions (W × H × D) ......................................................... (mm) 290 × 56 × 200
Weight .............................................................................................................. 3.1kg
(in)11-7/16 × 2-3/16 × 7-7/8
